  • Page 1 Temperature control module for the Velbus system...

  • Page 2: Table Of Contents

    EMBEDDING A TEMPERATURE CONTROLLER TOGETHER WITH A SENSOR ......10 OVERVIEW HEATING INSTALLATION .................... 11 CONNECTION ........................... 12 Connecting the temperature controller VMB1TC ......................12 Connecting the temperature sensor VMB1TS ........................12 Relay cabinet wiring ................................. 13 Terminator ..................................14 Addressing ..................................
  • Page 3 Cooling or heating mode indication ..........................71 Air-conditioner or heater active indication ........................71 Operation ..................................72 OPERATING THE TEMPERATURE CONTROLLER VMB1TC ............73 Select room or zone ................................. 73 Recall and change the desired temperature ........................74 Temporarily switching between comfort, day, night or anti-freeze mode ................. 74 Setting the sleep time (temporary mode) .........................

  • Page 4: Description

    (the program is disabled for an undefined time period) Configurable both locally or via PC (using the serial or USB interface in combination with the Velbus link software) All settings are retained in case of a power cut Relay control through the Velbus e.g.
  • Page 5 Dimensions Module (L x B x H): 66 x 44 x 40mm • Dimensions including cover plate (L x B x H): 118 x 80 x 40mm • Cover plate not included • VMB1TC Temperature controller manual – rev 5.0...

  • Page 6: Velbus Characteristics

    VELBUS CHARACTERISTICS • 2-wire communication for Velbus data and 2 wires for power supply • data transmission: 16.6 Kbit/s • Serial data protocol: CAN (Controller Area Network) • Short circuit proof (towards negative or positive pole of the power supply) •...
  • Page 7 • request the controller name • request the memory content • change the memory content • set the sensor program storage location • set the sensor zone • request a program instruction • change a program instruction VMB1TC Temperature controller manual – rev 5.0...

  • Page 8: Embedding The Temperature Controller

    EMBEDDING THE TEMPERATURE CONTROLLER The temperature controller VMB1TC can be embedded in combination with a Velbus cover plate VMBFDG or VMBFLG. Push the modules from the back into the cover plate. It is also possible to use a 3-module wide frame with cover plate from the BTicino Living series. The module must be pushed into the build-in frame from the front.

  • Page 9: Embedding A Temperature Sensor

    EMBEDDING A TEMPERATURE SENSOR The temperature sensor VMB1TS can be embedded in combination with two blank frames VMBFBI and a Velbus cover plate VMBFDG or VMBFLG. Push the modules from the back into the cover plate. It is also possible to use a 2- or 3-module wide frame with cover plate from the BTicino Living series. The module must be pushed into the build-in frame from the front.

  • Page 10: Embedding A Temperature Controller Together With A Sensor

    EMBEDDING A TEMPERATURE CONTROLLER TOGETHER WITH A SENSOR The controller (VMB1TC) can be embedded together with a sensor (VMB1TS) in a 4-module wide frame with cover plate from the BTicino Living series. The module must be pushed into the build-in frame from the front.

  • Page 11: Overview Heating Installation

    Every room is equipped with a temperature sensor VMB1TS which is controlled by one or multiple temperature controllers VMB1TC. The sensors in turn steer the relay modules VMB4RY (or VMB1RY) that control the valves. As soon as one of the valves is opened, a relay channel can activate the circulation pump and when one of the sensors is in day or comfort mode, a relay channel can put the boiler in day mode.

  • Page 12: Connection

    CONNECTION To interconnect the Velbus modules the use of twisted-pair cable (EIB 2x2x0.8mm2, UTP 8x0.51mm - CAT5 or equivalent) is recommended. Connect the bus to the module (beware of the polarity). Connect the 12V to 18V direct current to the module (beware of the polarity).

  • Page 13: Relay Cabinet Wiring

    Relay cabinet wiring VMB1TC Temperature controller manual – rev 5.0...

  • Page 14: Terminator

    MODE/TIME2 rotary switches of the channel on the relay module must be set to position ‘0’. The easiest way to allocate those relay channels is by using the Velbus link software via a PC connected to a Velbus interface (VMB1USB, VMB1RS or VMBRSUSB).

  • Page 15: Allocate A Relay Channel To Control Valve 1

    Turn On Delay 5:1' Trig Release Time1 Time1 Time1 Time1 6:2' Blink 7:5' 8:10' 9:15' A:30' Learn B:1h C:2h x=CH1...4 : ON VMB4RY D:5h 9x : E:1day 1day velleman F:Toggle Toggle Mode1 Mode2 Mode3 Mode4 VMB1TC Temperature controller manual – rev 5.0...

  • Page 16: Allocate A Relay Channel To Control Valve 2

    Turn On Delay 5:1' Trig Release Time1 Time1 Time1 Time1 6:2' Blink 7:5' 8:10' 9:15' A:30' Learn B:1h C:2h x=CH1...4 : ON VMB4RY D:5h 9x : E:1day 1day velleman F:Toggle Toggle Mode1 Mode2 Mode3 Mode4 VMB1TC Temperature controller manual – rev 5.0...

  • Page 17: Allocate A Relay Channel To Control Valve 3

    Turn On Delay 5:1' Trig Release Time1 Time1 Time1 Time1 6:2' Blink 7:5' 8:10' 9:15' A:30' Learn B:1h C:2h x=CH1...4 : ON VMB4RY D:5h 9x : velleman E:1day 1day F:Toggle Toggle Mode1 Mode2 Mode3 Mode4 VMB1TC Temperature controller manual – rev 5.0...

  • Page 18: Allocate A Relay Channel To Control The Fan

    Turn On Delay 5:1' Trig Release Time1 Time1 Time1 Time1 6:2' Blink 7:5' 8:10' 9:15' A:30' Learn B:1h C:2h x=CH1...4 : ON VMB4RY D:5h 9x : E:1day 1day velleman F:Toggle Toggle Mode1 Mode2 Mode3 Mode4 VMB1TC Temperature controller manual – rev 5.0...

  • Page 19: Allocate A Relay Channel For Day Mode Of The Boiler

    Learn B:1h C:2h x=CH1...4 : ON VMB4RY D:5h 9x : velleman E:1day 1day F:Toggle Toggle Mode1 Mode2 Mode3 Mode4 8. Set the address of the first relay module back to its original value. VMB1TC Temperature controller manual – rev 5.0...

  • Page 20: Allocate A Relay Channel For The Circulation Pump

    (HEAT) followed by the push button on the front C:2h x=CH1...4 : ON VMB4RY D:5h panel. 9x : E:1day 1day velleman F:Toggle Toggle Mode1 Mode2 Mode3 Mode4 8. Set the address of the first relay module back to its original value. VMB1TC Temperature controller manual – rev 5.0...

  • Page 21: Screen Indications

    Flashing when sleep timer is on Flashing when low or high temperature alarm Remark: When a menu is active, de LED indication is replaced with flashing LEDs on the ↑ and ↓ buttons that indicate the scrolling direction. VMB1TC Temperature controller manual – rev 5.0...

  • Page 22: Button Functions

    ↑ ↓ ↑ Alter the data entry (flashing item) or scroll through the menu. Location ↑ Li v i ng r oom ↓ M o 14: 23 23 Mode Menu ↓ ← → VMB1TC Temperature controller manual – rev 5.0...

  • Page 23: Menu Structure

    • To cancel or return to the previous item, use the ← button. • Quit the menu using the T button. When a data entry field (flashing item) is still active, changes are discarded when using the T button. VMB1TC Temperature controller manual – rev 5.0...

  • Page 24: Extended Menu

    ↑ Li v i ng r oom Location ↑ Pr ogr am Li v i ng r oom Mode Menu ↓ PI N c ode 1_00 ← → Mode Menu ↓ ← → VMB1TC Temperature controller manual – rev 5.0...
  • Page 25 This menu is not available when ‘all rooms’ is selected. Note: The naming of the menus and sub-menus might differ depending on the controllers’ firmware version. Always make sure to use the latest firmware version. VMB1TC Temperature controller manual – rev 5.0...

  • Page 26: Configuration Of The Temperature Controller

    8. Exit the menu with the T button. ← → 4. Select the configuration menu with the → button. Location ↑ Location ↑ 0: 01 Language Mode Menu ↓ ← → Mode Menu ↓ ← → VMB1TC Temperature controller manual – rev 5.0...

  • Page 27: Temperature Read-Out (°Celsius Or °Fahrenheit)

    4. Scroll through the configuration menu using the ↑ or ↓ button until the ‘Temp. Read-out’ item appears. Location ↑ Location ↑ 0: 02 Tem p. r ead- out Mode Menu ↓ ← → Mode Menu ↓ ← → VMB1TC Temperature controller manual – rev 5.0...

  • Page 28: Master Clock

    Master clock When your Velbus installation contains multiple modules with built-in clock (temperature controllers VMB1TC and control panel VMB4PD) it is important that all clocks have the same time setting. This can be achieved by setting the clock of one module as reference (master).

  • Page 29: Global Alarm

    Global alarm This setting only applies when multiple temperature controllers are connected to your Velbus installation. Default the global alarm function is disabled. Changing the alarm time on a module that has the global alarm function enabled will result in changing the alarm time on all temperature controllers that have the global alarm function enabled. For modules that have the global alarm time disabled, changes in alarm time will only apply to that module.

  • Page 30: Battery Backup

    To avoid losing the clock when a power failure occurs, a backup battery (3V Lithium CR2032) can be installed in the battery holder at the back of the module. To avoid premature depletion of the battery, only install it when permanent power is supplied to the Velbus system. The temperature controller can display a message when the battery needs replacement.
  • Page 31 ↑ or ↓ button. Location ↑ Location ↑ 0: 05 Bat t . bac k up On Mode Menu ↓ ← → Mode Menu ↓ ← → VMB1TC Temperature controller manual – rev 5.0...

  • Page 32: Addressing

    Addressing Every module on the Velbus system must have its own unique address. On modules with a rotary switch the address is set using the ‘ADDR’ rotary switch (refer to the manual of the relevant module). On other modules e.g. the temperature controller the address is set via the menu.

  • Page 33: Assign An Action To The Wake-Up Time

    As an example, we will automatically open all roll-down window shutters as soon as the set wake-up time is reached. This can also be configured through the Velbus link software on the computer but here we explain the manual procedure.
  • Page 34 11. Press and hold the ‘Menu’ button for ±4 seconds to open the extended menu. W ak e- up: Location ↑ Mode Menu ↓ ← → Conf i gur at i on Mode Menu ↓ ← → VMB1TC Temperature controller manual – rev 5.0...
  • Page 35 Location ↑ 0: 07 Li nk wak e- up Mode Menu ↓ ← → Mode Menu ↓ ← → 18. Set the addresses of the window shutter modules back to their original value. VMB1TC Temperature controller manual – rev 5.0...

  • Page 36: Assign An Action To The Go-To-Bed Time

    As an example, we will automatically switch on the staircase lighting as soon as the set go-to-bed time is reached. This can also be configured through the Velbus link software on the computer but here we explain the manual procedure.
  • Page 37 Location ↑ 0: 08 Li nk go t o bed Mode Menu ↓ ← → Mode Menu ↓ ← → 10. Set the address of the relay module back to its original value. VMB1TC Temperature controller manual – rev 5.0...

  • Page 38: Searching For Temperature Sensors

    3. Select the configuration menu with the → button. connected temperature sensors is shown on the display. Location ↑ Location ↑ Language Tem p s ens or 01 0: 09 20 Mode Menu ↓ ← → Mode Menu ↓ ← → VMB1TC Temperature controller manual – rev 5.0...

  • Page 39: Setting The Clock

    This module works together with one or more temperature sensoresVMB1TS to form a programmable thermostat. It is important to set the right time for the internal clock. Setting the time on this module will set the clocks of all clock containing modules that are connected to the Velbus simultaneously.
  • Page 40 ↑ Tem p s ens or 01 M o 14: 24 20 Tem p s ens or 01 Cl oc k s et Mode Menu ↓ ← → Mode Menu ↓ ← → VMB1TC Temperature controller manual – rev 5.0...

  • Page 41: Setting The Alarm Clock

    Tem p s ens or 01 Al ar m c l oc k : Tem p s ens or 01 W ak e- up 7: 10 Mode Menu ↓ ← → Mode Menu ↓ ← → VMB1TC Temperature controller manual – rev 5.0...
  • Page 42 M o 14: 25 20 Tem p s ens or 01 Go- t o- bed 23: __ Mode Menu ↓ ← → Mode Menu ↓ ← → symbol indicates that the alarm function is activated. VMB1TC Temperature controller manual – rev 5.0...

  • Page 43: Disabling The Alarm Clock Function

    Al ar m c l oc k : ___ Mode Menu ↓ ← → Mode Menu ↓ ← → symbol is no longer visible on the display to indicate that the alarm function is disabled. VMB1TC Temperature controller manual – rev 5.0...

  • Page 44: Setting The Display Contrast

    → Mode Menu ↓ ← → 4. Select the contrast menu with the → button. Location ↑ Tem p s ens or 01 Cont r as t ___% Mode Menu ↓ ← → VMB1TC Temperature controller manual – rev 5.0...

  • Page 45: Setting The Backlight Of The Display

    ↑ Tem p s ens or 01 Tem p s ens or 01 Bac k l i ght <t 2> __: 00> 30% Mode Menu ↓ ← → Mode Menu ↓ ← → VMB1TC Temperature controller manual – rev 5.0...
  • Page 46 ↑ Tem p s ens or 01 M o 14: 28 20 Tem p s ens or 01 <t 1> 21: 30> __% Mode Menu ↓ ← → Mode Menu ↓ ← → VMB1TC Temperature controller manual – rev 5.0...

  • Page 47: Configuration Of The Temperature Sensors

    The cursor moves to the next character. Oper at i ng m ode Location ↑ Mode Menu ↓ ← → K_m p s ens or 01 01 Change nam e Mode Menu ↓ ← → VMB1TC Temperature controller manual – rev 5.0...
  • Page 48 10. Repeat steps 1 through 9 until every sensor has a 8. Exit the menu with the T button. meaningful name. Location ↑ Ki t c hen M a 14: 31 20 Mode Menu ↓ ← → VMB1TC Temperature controller manual – rev 5.0...

  • Page 49: Defining Zones

    8. Confirm with the → button. Location ↑ Location ↑ Bedr oom 1 Oper at i ng m ode Bedr oom 1 Zone num ber Mode Menu ↓ ← → Mode Menu ↓ ← → VMB1TC Temperature controller manual – rev 5.0...
  • Page 50 9. Exit the menu with the T button. 10. Repeat steps 1 through 9 for every sensor that needs to be added to a zone. Location ↑ Bedr oom 1 M o 14: 33 16 Mode Menu ↓ ← → VMB1TC Temperature controller manual – rev 5.0...

  • Page 51: Change The Default Zone Names

    Z1 Change nam e 4. Select the sensor settings menu with the → button. Mode Menu ↓ ← → Location ↑ Zone 1 Oper at i ng m ode Mode Menu ↓ ← → VMB1TC Temperature controller manual – rev 5.0...
  • Page 52 11. Repeat steps 2 through 10 until every zone has a 9. Exit the menu with the T button. meaningful name. Location ↑ Bedr oom s M o 14: 35 Mode Menu ↓ ← → VMB1TC Temperature controller manual – rev 5.0...

  • Page 53: Heating Or Cooling Mode

    ↑ Location ↑ Al l r oom s M o 14: 36 Al l r oom s Oper at i ng m ode Mode Menu ↓ ← → Mode Menu ↓ ← → VMB1TC Temperature controller manual – rev 5.0...

  • Page 54: Lock Or Unlock Local Mode Setting

    Oper at i ng m ode ← → Mode Menu ↓ ← → 9. Exit the menu with the T button. Location ↑ Al l r oom s M o 14: 37 Mode Menu ↓ ← → VMB1TC Temperature controller manual – rev 5.0...

  • Page 55: Default Duration Of Temporary Mode (Default Sleep Time)

    Oper at i ng m ode 9. Exit the menu with the T button. Mode Menu ↓ ← → Location ↑ Al l r oom s M o 14: 38 Mode Menu ↓ ← → VMB1TC Temperature controller manual – rev 5.0...

  • Page 56: Low Temperature Alarm

    Oper at i ng m ode 9. Exit the menu with the T button. Mode Menu ↓ ← → Location ↑ Al l r oom s M o 14: 39 Mode Menu ↓ ← → VMB1TC Temperature controller manual – rev 5.0...

  • Page 57: High Temperature Alarm

    Oper at i ng m ode 9. Exit the menu with the T button. Mode Menu ↓ ← → Location ↑ Al l r oom s M o 14: 40 Mode Menu ↓ ← → VMB1TC Temperature controller manual – rev 5.0...

  • Page 58: Anti-Freeze Temperature

    Oper at i ng m ode Mode Menu ↓ 9. Exit the menu with the T button. ← → Location ↑ Al l r oom s M o 14: 41 Mode Menu ↓ ← → VMB1TC Temperature controller manual – rev 5.0...

  • Page 59: Heating Limit

    Oper at i ng m ode 9. Exit the menu with the T button. Mode Menu ↓ ← → Location ↑ Al l r oom s M o 14: 42 Mode Menu ↓ ← → VMB1TC Temperature controller manual – rev 5.0...

  • Page 60: Minimum Cooling Temperature

    Oper at i ng m ode 9. Exit the menu with the T button. Mode Menu ↓ ← → Location ↑ Al l r oom s M o 14: 42 Mode Menu ↓ ← → VMB1TC Temperatuurcontroller handleiding – rev 5.0...

  • Page 61: Maximum Cooling Temperature

    Oper at i ng m ode 9. Exit the menu with the T button. Mode Menu ↓ ← → Location ↑ Al l r oom s M o 14: 42 Mode Menu ↓ ← → VMB1TC Temperature controller manual – rev 5.0...

  • Page 62: Hysteresis Temperature

    Oper at i ng m ode ← → Mode Menu ↓ ← → 9. Exit the menu with the T button. Location ↑ Al l r oom s M o 14: 43 Mode Menu ↓ ← → VMB1TC Temperatuurcontroller handleiding – rev 5.0...

  • Page 63: Temperature Difference

    Oper at i ng m ode ← → Mode Menu ↓ ← → 9. Exit the menu with the T button. Location ↑ Al l r oom s M o 14: 44 Mode Menu ↓ ← → VMB1TC Temperature controller manual – rev 5.0...

  • Page 64: Difference Sensor

    Oper at i ng m ode Cool er r oom Di f f . s ens or Mode Menu ↓ ← → Mode Menu ↓ ← → 9. Exit the menu with the T button. VMB1TC Temperatuurcontroller handleiding – rev 5.0...

  • Page 65: Protecting The Circulation Pump

    Oper at i ng m ode 9. Exit the menu with the T button. Mode Menu ↓ ← → Location ↑ Al l r oom s M o 14: 45 Mode Menu ↓ ← → VMB1TC Temperature controller manual – rev 5.0...

  • Page 66: Protecting The Valves

    Oper at i ng m ode 9. Exit the menu with the T button. Mode Menu ↓ ← → Location ↑ Al l r oom s M o 14: 46 Mode Menu ↓ ← → VMB1TC Temperatuurcontroller handleiding – rev 5.0...

  • Page 67: Calibrating The Sensor

    ← → Mode Menu ↓ ← → 9. Exit the menu with the T button. Location ↑ Li v i ng r oom M o 14: 46 21 Mode Menu ↓ ← → VMB1TC Temperature controller manual – rev 5.0...

  • Page 68: Verify Software Version

    VERIFY SOFTWARE VERSION Verify whether the controller contains the latest firmware by examining the firmware version. If the Velbus installation contains an interface (VMB1USB, VMB1RS or VMBRSUSB) the controller firmware can be updated when necessary. Remark: Upgrading a module is not without risk. Do not interrupt the process! If for any reason the upgrade should fail, the module will cease normal operation.

  • Page 69: Pin Code Protect The Extended Menu

    ↑ Li v i ng r oom Change PI N c ode Li v i ng r oom PI N c ode 123_ Mode Menu ↓ ← → Mode Menu ↓ ← → VMB1TC Temperature controller manual – rev 5.0...
  • Page 70 Change PI N c ode Mode Menu ↓ ← → Mode Menu ↓ ← → When the PIN code is not ‘0000’, the extended menu can only be accesses after enter the correct PIN code. VMB1TC Temperatuurcontroller handleiding – rev 5.0...

  • Page 71: Operating The Temperature Sensor Vmb1Ts

    When the temperature sensor is configured to control an air-conditioning system, the frost flower LED (upper LED) will be lit. Setting the heating or cooling mode can only be done through a temperature controller (VMB1TC) or through the Velbus link program.

  • Page 72: Operation

    • Local operation can be locked or unlocked via a temperature controller VMB1TC or via the Velbus link program. • When the sensor module is set to manual mode via a temperature controller VMB1TC or via the Velbus link program, local operation will be locked.

  • Page 73: Operating The Temperature Controller Vmb1Tc

    The previous/next room or zone can be selected with the “ “ or “ ” button as long as the LED of these buttons blinks. ↑ Location Li v i ng r oom M o 14: 23 22 ↓ Mode Menu ← → VMB1TC Temperature controller manual – rev 5.0...

  • Page 74: Recall And Change The Desired Temperature

    This could be useful e.g. to switch the heating of the bathroom to comfort mode for an hour. Temporarily switching between the different modes is done by pushing the push button on the temperature sensor VMB1TS or via this module. VMB1TC Temperatuurcontroller handleiding – rev 5.0...
  • Page 75 Temporary mode (sleep timer) can be cancelled by pushing and holding the ‘Mode’ button until the hourglass is not longer shown on the display. The chosen mode remains active until the next program instruction. VMB1TC Temperature controller manual – rev 5.0...

  • Page 76: Setting The Sleep Time (Temporary Mode)

    It is also possible to exit the ‘Sleep timer’ menu by pressing the ↑ button until the ‘Exit’ item appears. Location ↑ Select this item with the → button. Bat hr oom Mode Menu ↓ ← → VMB1TC Temperature controller manual – rev 5.0...

  • Page 77: Holiday Setting

    4. Select the sleep timer item with the → button. Location ↑ Al l r oom s Mode Menu ↓ ← → To cancel the holiday program, press and hold the ‘Mode’ button until the hourglass symbol ( ) disappears. VMB1TC Temperature controller manual – rev 5.0...

  • Page 78: Summer Setting

    Select the sleep timer item with the → button. Location ↑ Al l r oom s Mode Menu ↓ ← → To cancel the summer program, press and hold the ‘Mode’ button until the key symbol ( ) disappears. VMB1TC Temperature controller manual – rev 5.0...

  • Page 79: Setting The Comfort, Day And Night Temperature

    Li v i ng r oom Day t em p ___ Location ↑ Mode Menu ↓ ← → Li v i ng r oom Com f or t ___ Mode Menu ↓ ← → VMB1TC Temperature controller manual – rev 5.0...
  • Page 80 Note: In the sensor settings menu, it is possible to button. adjust the temperature limits. Location ↑ Li v i ng r oom Ni ght t em p 16 Mode Menu ↓ ← → VMB1TC Temperature controller manual – rev 5.0...

  • Page 81: Statistics

    Li v i ng r oom St at i s t i c s Li v i ng r oom 2m / 2h30m Mode Menu ↓ ← → Mode Menu ↓ ← → VMB1TC Temperature controller manual – rev 5.0...
  • Page 82 AC was on during comfort mode. The second time indication shows how long comfort mode has been enabled. Location ↑ Li v i ng r oom 15m / 1h30m Mode Menu ↓ ← → VMB1TC Temperature controller manual – rev 5.0...

  • Page 83: Reset Statistics

    M i n t em p 14 Mode Menu ↓ ← → Mode Menu ↓ ← → 9. Repeat steps 5 through 8 to reset the other statistics, or exit the menu using the T button. VMB1TC Temperature controller manual – rev 5.0...

  • Page 84: Program Instructions Location

    PROGRAM INSTRUCTIONS LOCATION This chapter is only applicable when multiple temperature controllers are connected to your Velbus installation. It can be skipped if you have only one controller connected. Prior to start programming it is important to determine which temperature controller will hold the program instructions for the rooms, zones and ‘all rooms’...
  • Page 85 11. Repeat steps 1 through 10 for all other rooms and zones. Remark: If on another controller the location for the living room program instructions would be verified, it would show that the local program on that controller is off. VMB1TC Temperature controller manual – rev 5.0...

  • Page 86: Programming

    • As soon as a program is available for a certain room, a ‘ ‘ will appear on the display behind the mode symbol. Location ↑ Li v i ng r oom p M o 14: 23 23 Mode Menu ↓ ← → VMB1TC Temperature controller manual – rev 5.0...
  • Page 87 When no sensor or zone program is available, but there is an ‘All rooms’ program, an ‘ ‘ will appear on the display • behind the mode symbol. Location ↑ Li v i ng r oom A M o 14: 23 23 Mode Menu ↓ ← → VMB1TC Temperature controller manual – rev 5.0...

  • Page 88: Overview Program Instruction

    Go-to-bed time + or – indicated time Working day program M o- Fr Monday through Friday (incl.) M o- Sa every day except Sunday Weekend program Sa&Su every Saturday and Sunday Week program M o- Su every day VMB1TC Temperature controller manual – rev 5.0...

  • Page 89: Entering A New Program Instruction

    ← → Remark: In case the wake-up or go-to-bed time is selected as reference, the offset can be set per 15 minutes with a limit of 4 hours. Step 9 is not applicable. VMB1TC Temperature controller manual – rev 5.0...
  • Page 90 M o- Fr 6: 45 Mode Menu ↓ ← → Mode Menu ↓ ← → 11. Repeat steps 4 through 10 to add more program instructions or exit the menu using the T button. VMB1TC Temperature controller manual – rev 5.0...

  • Page 91: Changing A Program Instruction

    Li v i ng r oom M o- Fr 6: 45 Location ↑ Mode Menu ↓ Li v i ng r oom ← → M o- Fr - 30m Mode Menu ↓ ← → VMB1TC Temperature controller manual – rev 5.0...
  • Page 92 ↑ or ↓ button and confirm with the →button. The flashing cursor disappears. Location ↑ Li v i ng r oom M o- Fr - 30m Mode Menu ↓ ← → VMB1TC Temperature controller manual – rev 5.0...

  • Page 93: Removing A Program Instruction

    8. Repeat steps 4 through 7 to remove other program instructions or exit the menu using the T button. Location ↑ Li v i ng r oom M o- Fr - 30m Mode Menu ↓ ← → VMB1TC Temperature controller manual – rev 5.0...

  • Page 94: Differential Thermostat

    6 seconds as desired temperature to the second sensor. The settings can be done via a temperature controller VMB1TC or via the Velbus link program Schematic overview differential thermostat (sensor2 in heating mode):...

  • Page 95: The Passage Automatically 3° Cooler Than The Office

    Passage Configuration: The easiest way to configure the system is to use the Velbus link program via a PC connected on the Velbus PC interface (VMB1USB, VMB1RS of VMBRSUSB). However, configuration can also be done without the aid of a computer. Refer to the procedure below.
  • Page 96 9. Remember the address of this relay module to reinstate it later on. 12. Set the address of the relay module back to its original value. Use this relay channel (ex. Channel2) to control the valve of the passage radiator. VMB1TC Temperature controller manual – rev 5.0...
  • Page 97 ↑ Of f i c e Oper at i ng m ode Of f i c e Di f f . s ens or Mode Menu ↓ ← → Mode Menu ↓ ← → VMB1TC Temperatuurcontroller handleiding – rev 5.0...
  • Page 98 • Make sure both sensors are in heating mode (frost flower LED on the sensor is off). • The passage temperature can never be higher than the preferred setting of its selected mode (anti-freeze, night, day or comfort). VMB1TC Temperature controller manual – rev 5.0...

  • Page 99: Passive Cooling Of A Bedroom

    Bedroom Configuration: The easiest way to configure the system is to use the Velbus link program via a PC connected on the Velbus PC interface (VMB1USB, VMB1RS of VMBRSUSB). However, configuration can also be done without the aid of a computer. Refer to the procedure below.
  • Page 100 ‘Sensor settings’ item appears. Location ↑ Location ↑ Cool er r oom - - - Cool er r oom Sens or s et t i ngs Mode Menu ↓ ← → Mode Menu ↓ ← → VMB1TC Temperature controller manual – rev 5.0...
  • Page 101 ← → Mode Menu ↓ ← → 16. Select the temp. difference item with the → button. Location ↑ Cool er r oom Tem p di f f ___ Mode Menu ↓ ← → VMB1TC Temperatuurcontroller handleiding – rev 5.0...
  • Page 102 23. Select the sensor settings menu with the → button. Location ↑ Location ↑ Bedr oom M o 14: 36 25 Bedr oom Oper at i ng m ode Mode Menu ↓ ← → Mode Menu ↓ ← → VMB1TC Temperature controller manual – rev 5.0...
  • Page 103 ← → The configuration is now finished and the differential thermostat is enabled. Remark: The cooling will stop when the bedroom temperature reaches the preferred setting of its selected mode (night, day or comfort). VMB1TC Temperatuurcontroller handleiding – rev 5.0...
  • Page 104 Refer to our website for more information: www.velbus.be VMB1TC Temperature controller manual – rev 5.0...
