Lanner NCA-5220 User Manual

Nerwork appliance platform
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
NCA-5220 User Manual
Network Appliance
Platform
NCA-5220
User Manual
Version: 1.0
Date of Release:2019-11-18
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NCA-5220 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Lanner NCA-5220

Summary of Contents for Lanner NCA-5220

  • Page 1 NCA-5220 User Manual Network Appliance Platform NCA-5220 User Manual Version: 1.0 Date of Release:2019-11-18...
  • Page 2 - assumed to be qualified in the servicing of computer equipment, such as professional system integrators or service personnel and technicians. The latest version of this document can be found on Lanner’s official website, available either through the product page or through the Lanner Download Center page with a login account and password.
  • Page 3 Lanner Q&A page for a diagnostic procedure and troubleshooting steps. In addition to contacting your distributor or sales representative, you could submit a request to our Lanner Technical Support at http://www.lannerinc.com/technical-support, where you can fill in a support ticket to our technical support department.
  • Page 4 NCA-5220 User Manual Taiwan Corporate Headquarters China Lanner Electronics Inc. Beijing L&S Lancom Platform Tech. Co., Ltd. 7F, No.173, Sec.2, Datong Rd. Xizhi District, Guodong LOFT 9 Layer No. 9 Huinan Road, New Taipei City 22184, Taiwan Huilongguan Town, Changping District, Beijing...
  • Page 5 NCA-5220 User Manual This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instruction, may cause harmful interference to radio communications.
  • Page 6 NCA-5220 User Manual Follow these guidelines to ensure general safety: Keep the chassis area clear and dust-free during and after installation. Do not wear loose clothing or jewelry that could get caught in the chassis. Fasten your tie or scarf and roll up your sleeves.
  • Page 7 NCA-5220 User Manual Leaving a battery in an extremely high temperature environment can result in an explosion or the leakage of flammable liquid or gas. A battery subjected to extremely low air pressure may result in an explosion or the leakage of flammable liquid or gas.
  • Page 8 The installation of this product must be performed by trained specialists; otherwise, a non-specialist might create the risk of the system’s falling to the ground or other damages. Lanner Electronics Inc. shall not be held liable for any losses resulting from insufficient strength for supporting the system or use of inappropriate installation components.
  • Page 9 NCA-5220 User Manual Before turning on the device, ground the grounding cable of the equipment. Proper grounding (grounding) is very important to protect the equipment against the harmful effects of external noise and to reduce the risk of electrocution in the event of a lightning strike. To uninstall the equipment, disconnect the ground wire after turning off the power.
  • Page 10 NCA-5220 User Manual This equipment must be grounded. The power cord for the product should be connected to a socket-outlet with earthing connection. Cet équipement doit être mis à la terre. La fiche d'alimentation doit être connectée à une prise de terre correctement câblée...
  • Page 11 NCA-5220 User Manual Main Features ..........................13 Package Content ......................... 13 Optional Kits ..........................14 Ordering Information ......................... 14 Optional Accessories ........................14 System Specifications ......................... 15 Front Panel ..........................16 Rear Panel ........................... 17 Motherboard Information ......................18 Installing the CPU ........................24 Installing the System Memory ....................
  • Page 12 NCA-5220 User Manual Installing Operating System......................56 BIOS Setup ..........................59 Warranty Policy ........................111 RMA Service ..........................111 RMA Service Request Form ...................... 112...
  • Page 13 NCA-5220 User Manual The NCA-5220, a 1U rackmount network appliance that can be customized with Intel® Xeon® E3-2100 processor and Intel® C246 chipset (codenamed Coffee Lake), comes with generous and flexible configurations for LAN ports, NIC expansion, storage and management, delivering advanced networking prowess for network traffic security, cloud computing and data centers.

  • Page 14: Main Features

    HDD/SSD NIC Module It is strongly recommended to use Lanner Slim type NIC modules Note: on this system; please consult Lanner for product compatibility if you consider adopting modules manufactured by other vendors. RJ45 cable L=180cm, Cat.5e UTP Cable Grey USB3.0 cable...
  • Page 15 NCA-5220 User Manual Form Factor 1U 19“ Rackmount Processor Options Intel® Coffee Lake-S Processor Family CPU Socket 1x LGA1151 socket Platform Chipset C246 Security Acceleration BIOS AMI SPI Flash BIOS Technology DDR4 2666 MHz ECC or U DIMM System Memory Max.
  • Page 16 NCA-5220 User Manual Slot1 Slot2 Description  Press once to enter software reset Reset Button  Press twice to enter hardware reset Control Panel 1x LCM + 4x control keys USB Ports 2x USB 3.0 port Console Port 1x RJ45 Console Port...
  • Page 17 NCA-5220 User Manual Description Optional FH/HL Size PCIe Slot for 1x PCIex8 or 2x PCIE4 (Slot3) PCIe Expansion Slot Or Reserved 2x 2.5” SSD swappable Cage (By project) Cooling Fan 2x cooling fans with SMART function USB Port USB 3.0 (Optional)
  • Page 18 NCA-5220 User Manual The block diagram indicates how data flows among components on the motherboard. Please refer to the following figure for your motherboard’s layout design. DDR4 Non-ECC (ECC) 2666Mhz Dual Channel, 2x DIMM Sockets from Each Channel Up to 128GB...
  • Page 19 NCA-5220 User Manual The motherboard layout shows the connectors and jumpers on the board. Refer to the following picture as a reference for the pin assignments and the internal connectors. RC Board IO Board...

  • Page 20: Front Panel

    NCA-5220 User Manual The pin headers on the motherboard are often associated with essential functions. With the shunt (Jumper) pushed down on the designated pins (the pin numbers are printed on the circuit board, surrounding the pin header), particular features can be enabled or disabled. While changing the jumpers, make sure your system is turned off.
  • Page 21 NCA-5220 User Manual OPEN1: Enable / Disable CASE OPEN# Pin No. Description INTRUDER_N FAN1~4: FAN Connector Pin No. Description FAN OUT FAN IN GP1: EXT GPIO header Pin No. Description Pin No. Description GPO_B_1 GPI_B_1 GPO_B_2 GPI_B_2 GPO_B_3 GPI_B_3 GPO_B_4...
  • Page 22 NCA-5220 User Manual SATA1~SATA4 Pin No. Description TX_P TX_N RX_N RX_P SATAPW1 & 2 Pin No. Description SPIROM1: Flash BIOS Pin No. Description Pin No. Description SPI_HD1# SPI_CS1#_DUAL SPI_CS0#_DUAL P3V3_SPI SPI_MISO_R SPI_IO3_R SPI_CLK_R SPI_MOSI_R VGA1 Pin No. Description Pin No.
  • Page 23 NCA-5220 User Manual PWRON1: Force Power ON Pin No. Description ATX_PSON_N PMBUS1 Pin No. Description TTL1 TTL2 PMBUS_CLK PMBUS_DATA PWR_ALERT PLD1: Flash CPLD Pin No. Description Pin No. Description JTAG_TCK JTAG_TDO P3V3_STBY CRT_BLUE JTAG_TDI ATX1 Pin No. Description Pin No.
  • Page 24 NCA-5220 User Manual To reduce the risk of personal injury, electric shock, or damage to the system, please remove all power connections to shut down the device completely. Also, please wear ESD protection gloves when conducting the steps in this chapter.
  • Page 25 NCA-5220 User Manual 3. When you extract the processor from its package, carefully hold it by its edges and avoid touching its golden contacts side. Make sure the golden triangular mark is aligned with the white one marked on the motherboard and then insert it into the socket, as indicated in the picture.
  • Page 26 NCA-5220 User Manual The motherboard supports 4 memory slots for DDR4 UDIMM with speeds of up to 2666MHz. The CPU requires at least 2 memory modules to boot and run from. Total Slots Number of Channels 2 (2 DIMMs per channel)
  • Page 27 NCA-5220 User Manual Recommended DIMM Population Scheme The table below shows the recommended schemes for DIMM population. To guarantee balanced system performance, please install identical DIMMs of the same capacity, speed, number of ranks, and from the same manufacturer. SLOT #...
  • Page 28 NCA-5220 User Manual This system supports IPMI module card (IAC-AST2500) through the OPMA1 slot. For instructions on remote server management, please refer to Remote Server Management 1. Locate the OPM1 slot. OPMA1 2. Insert the IPMI module into the slot at 15° angle, vertically press it down on both corners (indicated in...
  • Page 29 NCA-5220 User Manual This system supports the TPM module card (IAC-AST2500) through the TPM slot. 1. Locate the TPM slot. 2. Insert the TPM module into the 12-pin slot. Make sure it is properly seated.
  • Page 30 NCA-5220 User Manual This system supports the M.2 storage module (2242 B+M Key) through the M2_1 slot. 1. Locate the M2_1 slot. M2_1 2. Insert the M.2 module into the slot at 15° angle, align the notch on the module with the corresponding socket key in the slot, and then secure it with a screw.
  • Page 31 RC-52204 1*PCIEx8 1*PCIEx8 2*PCIEx4 +RC-52205 2*PCIEx4 2*PCIEx4 The following list shows Lanner-manufactured Slim type NIC modules that are compatible with this system; please consult your Lanner representative for the availability of these products. Model Ports Connector Speed Chipset PCIE Interface...
  • Page 32 NCA-5220 User Manual 1. Locate the NIC module slot on the front panel. 2. Rotate the two lock-screws counterclockwise and loosen them to remove the door. 3. Insert your NIC Ethernet module. (The module shown in the image below is for reference only)L 4.
  • Page 33 NCA-5220 User Manual The system can accommodate two 2.5” SSD/HDD at its front disk bay. With the optional SSD swappable cage, you can add another two SSD disks for system storage. After you install the hard drives, make sure the SATA data cables and SATA power cables are connected to the designated connectors on the motherboard, as indicated in the picture below.

  • Page 34: Rear Panel

    NCA-5220 User Manual 1. On Rear panel, loosen the screws that secure the slot bracket so that you can remove both PCIe slot covers, and then lock the bracket back with the screws. The PCIe slot covers are no longer needed then.
  • Page 35 NCA-5220 User Manual 4. Attach the SATA cables and the SATA Power cable to the cage, and insert the cable ends into the corresponding Power Switch connectors on Motherboard. 5. Make sure the power switch is turned to “ON” position...
  • Page 36 NCA-5220 User Manual The HDD/SSD bay supports 2 x 2.5” SATA HDDs or SSDs as data storage. Please follow the steps below for installation. 1. Locate the disk drive tray at the corner of the system. Loosen the screw indicated in the picture and slide the tray downwards to have it loosened from the four latching spots.
  • Page 37 NCA-5220 User Manual 3. Place the tray with HDD/SSD installed back to its original spot inside the system. Remember to aim at the four latching holes. Then slide the tray upwards to get it locked and secure it with the original screw.
  • Page 38 NCA-5220 User Manual There are various methods to mount this system based on your application and the environment. This system came with two types of mounting kits for a typical rack or enclosure mounting installation or installing this system in a rack:...
  • Page 39 NCA-5220 User Manual The Ear Brackets come with six screws, as shown below. Take an ear bracket, align the holes on it with those on the side of the system, and lock it onto the system with three provided screws. Do the same to the other ear bracket.
  • Page 40 NCA-5220 User Manual The slide rail kit shall include the following items: 1 x pack of FL00IJ0-A screws (for securing the sliding rails on the unit) 2 x Slide-Rails Fully stretched slide rail: Outer Channel Inner Channel Rail Bracket Note...
  • Page 41 NCA-5220 User Manual 1. Unpack a slide rail and slide the inner channel to its end. 2. Slide the rail bracket out to its end. 3. To detach the rail bracket from the Release Tab channel, locate push Release Tab on the rail bracket while sliding it out.
  • Page 42 NCA-5220 User Manual 1. This slide-rail kit does NOT require screw-fixing. Aim at 3 available screw holes on the rack front and lock it by clipping the rail’s front end to the post, as shown in the Use this clamp image below.
  • Page 43 NCA-5220 User Manual 2. Hold the chassis with its front facing you, lift and gently insert it by aligning with the slide-rail assemblies as shown in the image, and then push the unit into the cabinet. 3. Keep sliding the rails in until they stop about halfway.
  • Page 44 NCA-5220 User Manual Cooling fans may wear down eventually. Please refer to the steps below for replacing cooling fans. When using a new cooling fan, just reverse the steps to install the fan back onto the enclosure and the system.
  • Page 45 NCA-5220 User Manual Power supply units may wear down eventually. Please be noted that this system supports 600W PSU. Please prepare the power supply units matching this capacity. 1. On the rear panel, locate the power supply units and disconnect the power cords.

  • Page 46: Power Source

    (each), Tma = 40 degrees C, and the altitude of operation = 5000m. The cable should be 14AWG (12A minimum, 72V minimum). If you need further assistance with purchasing the power source, please contact Lanner Electronics Inc. for further information.
  • Page 47 In addition, Lanner’s BMC firmware runs an embedded web-server for full configuration using Web UI, which has a low learning curve. For detailed instructions on using each function, please refer to the full version of NCA-5220 BMC manuals available on.
  • Page 48 NCA-5220 User Manual System health monitoring The BMC implements system sensor monitoring feature. It could monitor voltage, temperature, and current of critical components. System Power Management The BMC implements chassis power and resets functions for system administrators to control and manage the system power behavior.
  • Page 49 NCA-5220 User Manual Keyboard, Video, Mouse (KVM) Redirection The BMC provides keyboard, video, and mouse (KVM) redirection over LAN. This application is available  remotely from the embedded web server. Support video recording, recorded videos to be downloaded & playable.
  • Page 50 NCA-5220 User Manual IPMI Commands Support List COMMANDS NETFN IPM Device “Global” Commands Get Device ID APP (06h) Cold Reset APP (06h) Warm Reset APP (06h) Get Device GUID APP (06h) BMC Watchdog Timer Commands Reset Watchdog Timer APP (06h)
  • Page 51 NCA-5220 User Manual Set SEL Time UTC Offset Storage (0Ah) LAN Device Commands Set LAN Configuration Parameters Transport (0Ch) Get LAN Configuration Parameters Transport (0Ch) Serial/Modem Device Commands Set User Callback Options Transport (0Ch) Get User Callback Options Transport (0Ch)
  • Page 52 NCA-5220 User Manual In the address bar of your Internet browser, input the IP address of the remote server to access the BMC interface of that server. Initial access of BMC prompts you to enter username and password. A screenshot of the login screen is...
  • Page 53 NCA-5220 User Manual Username: admin Password: admin The default username and password are in lower-case characters. When you log in using the default username and password, you will get full administrative rights, and it will ask you to change the default password once you log in.
  • Page 54 NCA-5220 User Manual After the first time login, you will see first time wizard welcome page as the following picture. Please press the “Next” button and configure your BMC step by step. In the “Configure Network” page, you could specify the hostname and network settings of BMC.
  • Page 55 NCA-5220 User Manual In the final page, please press “Finish” button to complete the first time wizard. BMC will be rebooted and apply new settings. You could reconnect to the Web UI after a few minutes.
  • Page 56 NCA-5220 User Manual If your system is shipped without an operating system, install the supported operating system using the following resources. 1. Download the ISO image and make a bootable DVD from it. 2. Connect a DVD player or other type of readers (floppy disk, or a drive) to a computer.
  • Page 57 NCA-5220 User Manual 5. After a JViewer screen pops up, select “Media” and then “Virtual Media Wizard” from the toolbar. 6. On Virtual Media screen, select your media type to load the image. For example, click on “Browse” of CD/DVD Media 1 and then “Connect CD/DVD.”...
  • Page 58 NCA-5220 User Manual 7. The Status window will display the connection status. 8. The installation process will automatically start. Please follow the onscreen instruction to complete the rest of the steps and restart the target system manually.

  • Page 59: Bios Setup

    NCA-5220 User Manual BIOS is a firmware embedded on an exclusive chip on the system’s motherboard. Lanner's BIOS firmware offering including market-proven technologies such as Secure Boot and Intel Boot Guard technology deliver solid commitments for the shield protection against malware, uncertified sequences and other named cyber threats.
  • Page 60 NCA-5220 User Manual Setup main page contains BIOS information and project version information. Feature Description BIOS Vendor: American Megatrends Core Version: AMI Kernel version, CRB code base, X64 Compliancy: UEFI version, PI version BIOS Information Project Version: BIOS release version...
  • Page 61 NCA-5220 User Manual Select the Advanced menu item from the BIOS setup screen to enter the “Advanced” setup screen. Users can select any of the items in the left frame of the screen.
  • Page 62 NCA-5220 User Manual CPU Configuration...
  • Page 63 NCA-5220 User Manual Feature Options Description Disabled Enable/Disable moving of DRAM contents to PRM C6DRAM Enabled memory when CPU is in C6 state Software Guard Disabled Enable/Disable Software Guard Extensions (SGX) Extensions (SGX) Enabled CPU Flex Ratio Disabled Enable/Disable CPU Flex Ratio Programming...
  • Page 64 NCA-5220 User Manual Power & Performance Feature Options Description Max Battery Select the performance state that the BIOS will Boot performance Max Non-Turbo set starting from reset vector. mode Performance Turbo Performance" Intel(R) Disabled Allows more than two frequency ranges to be...
  • Page 65 NCA-5220 User Manual PCH-FW Configuration Feature Options Description Disabled When Disabled ME will be put into ME Temporarily ME State Enabled Disabled Mode.
  • Page 66 NCA-5220 User Manual PCH-FW Configuration Feature Options Description Me FW Image Disabled Enable/Disable Me FW Image Re-Flash function. Re-Flash Enabled...
  • Page 67 NCA-5220 User Manual Trusted Computing Feature Options Description Enables or disables BIOS support for security device. Security Device Enabled By disabling this function, OS will not show Security Support Disabled Device. TCG EFI protocol and INT1A interface will not be available.
  • Page 68 NCA-5220 User Manual Trusted Computing (TPM1.2) Feature Options Description Enables or disables BIOS support for security device. Security Device Enabled By disabling this function, OS will not show Security Support Disabled Device. TCG EFI protocol and INT1A interface will not be available.
  • Page 69 NCA-5220 User Manual Trusted Computing (TPM2.0)
  • Page 70 NCA-5220 User Manual Feature Options Description Enables or disables BIOS support for security device. Security Device Enabled By disabling this function, OS will not show Security Support Disabled Device. TCG EFI protocol and INT1A interface will not be available. Enabled SHA-1 PCR Bank Enables or disables SHA-1 PCR Bank.
  • Page 71 NCA-5220 User Manual Super IO Configuration...
  • Page 72 NCA-5220 User Manual Serial port 1 Configuration Feature Options Description Enabled Serial Port Enables or disables Serial Port 1. Disabled Device Settings IO=3F8h; IRQ = 4...
  • Page 73 NCA-5220 User Manual Serial port 2 Configuration Feature Options Description Enabled Serial Port Enables or disables Serial Port 2. Disabled Device Settings IO=2F8h; IRQ = 3...
  • Page 74 NCA-5220 User Manual H/W Monitor Feature Options Description Smart Fan Control None Smart Fan Parameters...
  • Page 75 NCA-5220 User Manual Smart Fan Control Feature Options Description Manual Mode Smart Fan Mode Smart Fan Mode select Smart Fan Mode Target Input Target Temperature (Range:0 - 127) Temperature T1 Target Input Target Temperature (Range:0 - 127) Temperature T2 Target...

  • Page 76: Status Led Configuration

    NCA-5220 User Manual Status LED Configuration Feature Options Description Status LED Green Configures Status LED color...

  • Page 77: Digital I/O Configuration

    NCA-5220 User Manual Digital I/O Configuration Feature Options Description Output Low Digital I/O Output 1 Configure Digital I/O Pin1 Output High Output Low Digital I/O Output 3 Configure Digital I/O Pin3 Output High Output Low Digital I/O Output 5 Configure Digital I/O Pin5...
  • Page 78 NCA-5220 User Manual Case Open Configuration Feature Options Description Enabled Case Open Enables or disables Case Open function Disabled...

  • Page 79: Watchdog Timer Configuration

    NCA-5220 User Manual Watch Dog Timer Configuration Feature Options Description Watch Dog Timer Enabled Enables or disables Watch Dog Timer function Disabled...

  • Page 80: Serial Port Console Redirection

    NCA-5220 User Manual Serial Port Console Redirection Feature Options Description COM0 Enabled Console Enables or disables Console Redirection Disabled Redirection...
  • Page 81 NCA-5220 User Manual Console Redirection Settings Feature Options Description VT100: ASCII char set VT100 VT100+:Extends VT100 to support color, function VT100+ keys, etc. Terminal Type VT-UTF8 VT-UTF8:Uses UTF8 encoding to map Unicode ANSI chars onto 1 or more bytes ANSI: Extended ASCII char set...
  • Page 82 NCA-5220 User Manual RTS/CTS VT-UTF8 Combo Key Disabled Enables VT-UTF8 Combination Key Support for Support Enabled ANSI/VT100 terminals Disabled With this mode enabled, only text will be sent. This Recorder Mode Enabled is to capture Terminal data. Disabled Resolution 100x31...
  • Page 83 NCA-5220 User Manual Console Redirection Settings Feature Options Description Redirection COM COM0 Select a COM port to display redirection of Legacy Port OS and Legacy OPROM Messages. 80x24 On Legacy OS, the Number of Rows and Columns Resolution 80x25 supported redirection.

  • Page 84: Intel Txt Information

    NCA-5220 User Manual Intel TXT Information...

  • Page 85: Pci Subsystem Settings

    NCA-5220 User Manual PCI Subsystem Settings Feature Options Description BME DMA Disabled Re-enable Bus Master Attribute disabled during PCI Mitigation Enabled enumeration for PCI Bridges after SMM Locked Globally Enables or Disables Hot-Plug support for the entire System. If System has Hot-Plug capable...

  • Page 86: Usb Configuration

    NCA-5220 User Manual USB Configuration Feature Options Description Enabled Enables Legacy USB support. Legacy USB Support Disabled Auto option disables legacy support if no Auto USB devices are connected;...
  • Page 87 NCA-5220 User Manual Disabled option will keep USB devices available only for EFI applications. This is a workaround for OSes without Enabled XHCI hand-off support. XHCI XHCI Hand-off Disabled ownership change should be claimed by XHCI driver. USB Mass Storage...

  • Page 88: Network Stack Configuration

    NCA-5220 User Manual Network Stack Configuration Feature Options Description Disabled Network Stack Enables or disables UEFI Network Stack Enabled...

  • Page 89: Csm Configuration

    NCA-5220 User Manual CSM Configuration Feature Options Description Disabled CSM Support Enables or disables CSM Support Enabled Do Not Launch Controls the execution of UEFI and Legacy Network UEFI PXE OpROM Legacy Do Not Launch Controls the execution of UEFI and Legacy...

  • Page 90: Nvme Configuration

    NCA-5220 User Manual NVMe Configuration...
  • Page 91 NCA-5220 User Manual Control Legacy PXE Boot Feature Options Description Control Disabled Legacy PXE MGMT Lan1 Control Legacy PXE Boot from which Lan Boot from MGMT Lan2...
  • Page 92 NCA-5220 User Manual Chipset Select the Chipset menu item from the BIOS setup screen to enter the Platform Setup screen. Users can select any of the items in the left frame of the screen.

  • Page 93: System Agent (Sa) Configuration

    NCA-5220 User Manual System Agent (SA) Configuration Feature Options Description Disabled VT-d VT-d capability Enabled Enable/Disable above 4GB MemoryMappedIO BIOS Above 4GB MMIO Disabled assignment This is enabled automatically when Aperture BIOS assignment Enabled Size is set to 2048MB. Disabled...
  • Page 94 NCA-5220 User Manual Memory Configuration...
  • Page 95 NCA-5220 User Manual Feature Options Description Auto Maximum Memory 1067 Maximum Memory Frequency Selections in Mhz. Valid Frequency values should match the refclk, i.e. divide by 133 or 100 3200 Dynamic Maximum Value of TOLUD. Dynamic assignment would 1 GB...
  • Page 96 NCA-5220 User Manual PEG Port Configuration...
  • Page 97 NCA-5220 User Manual Feature Options Description Disabled Enable Root Port Enabled Enable or Disable the Root Port Auto Auto Gen1 Max Link Speed Configure PEG 0:1:0 Max Speed Gen2 Gen3 Sets the upper limit on power supplied by slot. Power...
  • Page 98 NCA-5220 User Manual PEG Port Feature Configuration Feature Options Description Detect Disabled Non-Compliance Detect Non-Compliance PCI Express Device in PEG Enabled Device...

  • Page 99: Pch-Io Configuration

    NCA-5220 User Manual PCH-IO Configuration Feature Options Description Serial IRQ Quiet Configure Serial IRQ Mode. Mode Continuous Power On Restore AC Specify what state to go to when power is re-applied after a Power Off Power Loss power failure (G3 state).
  • Page 100 NCA-5220 User Manual PCI Express Configuration...
  • Page 101 NCA-5220 User Manual Feature Options Description PCI Express Root Disabled Control the PCI Express Root Port. Port 9 Enabled Disabled Set the ASPM Level: Force L0s - Force all links to L0s ASPM 8 State AUTO - BIOS auto configure DISABLE -...
  • Page 102 NCA-5220 User Manual SATA And RST Configuration Feature Options Description Enabled SATA Controller(s) Enable/Disable SATA Device. Disabled SATA Mode AHCI Determines how SATA controller(s) operate. Selection Intel RST Aggressive LPM Enabled Enable PCH to aggressively enter link power Support Disabled state.
  • Page 103 NCA-5220 User Manual Security Configuration Feature Options Description Disabled Enable will lock bytes 38h-3Fh in the lower/upper RTC Memory Lock Enabled 128-byte bank of RTC RAM Enable/Disable the PCH BIOS Lock Enable Disabled BIOS Lock feature. Required to be enabled to ensure SMM Enabled protection of flash.
  • Page 104 NCA-5220 User Manual Select the Security menu item from the BIOS setup screen to enter the Security Setup screen. Users can select any of the items in the left frame of the screen. Feature Description If ONLY the Administrator's password is set, it only limits access to Setup and is only asked for when entering Setup.

  • Page 105: Secure Boot

    NCA-5220 User Manual Secure Boot Feature Options Description Secure Boot is activated when Platform Key(PK) is Secure Boot Disabled enrolled, System mode is User/Deployed, and CSM Enable Enabled function is disabled. Customizable Secure Boot mode: In Custom mode, Standard Secure Boot Mode...

  • Page 106: Key Management

    NCA-5220 User Manual Key Management Feature Options Description Factory Key Disabled Provision factory default keys on next re-boot only Provision Enabled when System in Setup Mode. Force System to User Mode. Configure NVRAM to Restore Factory None contain OEM-defined factory default Secure Boot keys keys.
  • Page 107 NCA-5220 User Manual Select the Boot menu item from the BIOS setup screen to enter the Boot Setup screen. Users can select any of the items in the left frame of the screen. Feature Options Description The number of seconds to wait for setup Setup Prompt Timeout activation key.
  • Page 108 Select the Save and Exit menu item from the BIOS setup screen to enter the Save and Exit Setup screen. Users can select any of the items in the left frame of the screen. Discard Changes and Exit Select this option to quit Setup without saving any modifications to the system configuration. The following window will appear after the “Discard Changes and Exit”...
  • Page 109 Restore Defaults Restore default values for all setup options. Select “Yes” to load Optimized defaults. Note The items under Boot Override were not same with image. It should depend on devices connect on system.
  • Page 110 The status explanations of LED indicators on the Front Panel are as follows: System Power System Status HDD Activity System Power Solid Green The system is powered on The system is powered off System Status This LED indicator is programmable. You could program it to display the operating status of the behaviors described below: Solid Green Defined by GPIO...

  • Page 111: Rma Service Request Form

    1. All products are under warranty against defects in materials and workmanship for a period of one year from the date of purchase. 2. The buyer will bear the return freight charges for goods returned for repair within the warranty period, whereas the manufacturer will bear the after service freight charges for goods returned to the user.
  • Page 112 When requesting RMA service, please fill out the following form. Without this form enclosed, your RMA cannot be processed.
