- Page 1 Network Application Platforms Hardware platforms for next generation networking infrastructure FW-6436 User's Manual Publication date:2012-05-15 >> Version 2.0...
- Page 2 Resource Website accordance with the instruction manual, may cause harmful interference to radio communications. Operation Lanner http://www.lannerinc.com of this equipment in a residential area is likely to cause harmful interference in which case the user will be required Product Resources http://assist.lannerinc.com to correct the interference at his own expense.
-
Page 3: Table Of Contents
TTaTTable of Contentsbeable of Conten Chapter 1: Introduction System Specification ......... . . 1 Package Contents . -
Page 4: Chapter 1: Introduction
Introduction Form Factor Desktop Based on a new generation high-performance VIA VX900 VIA ULV Eden 500 chipset the FW-6436 offers a compact and convenient Processor Options MHz or VIA C7 1.5 Platform system for secured data exchange and media services. -
Page 5: Package Contents
Chapter 1 Introduction Package Contents Your package contains the following items: • FW-6436 Network Security Platform • Power cable • 1 crossover Ethernet cable (1.8 meters) • 1 straight-through Ethernet cable (1.8 meters) • 1 RJ45 to DB-9 console cable •... -
Page 6: Front Panel Features
Chapter 1 Introduction Front Panel Features F1 ATX Power Switch A system power switch. F2 DC-12V DC-in connector for connecting DC power source (60W). Use only the power adaptor included within the package. F3 LED System (Green) Green: when the system is on. Off: when the system is off. -
Page 7: Rear Panel Features
Chapter 1 Introduction Rear Panel Features R1 LED System (Green) Green: when the system is on. Off: when the system is off. Status (Green/Amber) It is a programmable LED to show the operating status of the system. For more details, look for the software utility folder in the Driver and User Manual Hdd (Yellow) Flashing: when there are data access activities or the presence of the Com- pactFlash card or SATA disk (on model FW-6436B only) or both... -
Page 8: Chapter 2: Hardware Setup
Unpower the FW-6436 and remove the power cord. Unscrew 2 screws from the two sides and two screws on the back of the top cover of the FW-6436 System. Slide the cover backwards to open it. Network Application Platforms... -
Page 9: Installing The System Memory
Chapter 2 Hardware Setup Installing a CompactFlash Card FW-6436 provides one CompactFlash slot slot. Follow the procedures bellow too install a CompactFlash card. Align CompactFlash card and the card slot with the arrow pointing toward the connector. Push the card to insert into the connector. -
Page 10: Chapter 3: Mechanical Dimensions
Chapter 3 Mechanical Dimensions Chapter 3: Mechanical Dimensions System Mechanical Dimensions Network Application Platforms... -
Page 11: Chapter 4: Motherboard Information
Chapter 4 Motherboard Information Chapter 4: Motherboard Information Block Diagram The block diagram depicts the relationships among the interfaces or modules on the motherboard. Please refer to the following figure for your motherboard’s layout design. VIA Eden ULV 500MHz/1.5GHz 400/533/800/1066MHz Mini-PCI DDR3 SO-DIMM Slot Connector... -
Page 12: Motherboard Layout
Chapter 4 Motherboard Information Motherboard Layout The motherboard layout shows the connectors and jumpers on the board. Refer to the following picture as a reference of the pin assignments and the internal connectors. 20-Pin AtX Power Connector (AtX1) PCI Golden Finger with Riser Mini-PCI Connector (PCIB1) Card Clear CMOS... -
Page 13: Jumper Settings
Chapter 4 Motherboard Information Jumper Settings Reset Button Connector (JRST_BTN1): a 2-pin header for connecting the reset switch. It can be either a CMOS Jumper (CMOS1): It is for clearing the CMOS hardware or a software reset depending on the BIOS setting. - Page 14 Chapter 4 Motherboard Information Front Panel Reset Switch (SW_RST_BTN1): This switch Pin No. Description Pin No. Description can be a hardware or software reset depending RESERVED AD26 on the BIOS setting. It works the same as the Reset C_BE-3 AD24 AD23 IDSEL Button Connector (JRST_BTN1).
- Page 15 Chapter 4 Motherboard Information Ethernet ports 4~1(LANB1~LANB4) PIN NO. Function BI_DA+ BI_DA- BI_DB+ LED2 LED1 BI_DC+ BI_DC- BI_DB- BI_DD+ BI_DD- LED1 LED2 Status Description Status Description No Link 10 Mb Connection Linked Green 100 Mb Connection Blinking Data Activity Amber 1 Gb Connection Ethernet 1 and Ethernet 2 Port : These RJ45 gigabit Ethernet ports are provided by Realtek RTL8111E GbE...
-
Page 16: Appendix E: Driver Installation
Appendix E Driver Installation Appendix E: Please wait while the installation is in progress. Driver Installation LAN Adapters Driver Installation This section provides the instructions on how to install Realtek® Gigabit LAN adapter drivers. Windows Operating systems To install the Realtek® Gigabit LAN controller driver on a Windows Operating System: Restart the computer, and then log on with Administrator privileges. -
Page 17: Linux
Appendix E Driver Installation Chipset Platform Driver Installation Linux Follow these instructions to install the Realtek® LAN The VIA chipset drivers help increase the stability and controller base driver for the Red Hat® and Linux operating performance of the system with VIA chipsets as well as system. -
Page 18: Appendix A: Terms And Conditions
Appendix A Terms and Conditions Appendix A: RMA Service Terms and Conditions Requesting a RMA# To obtain a RMA number, simply fill out and fax the “RMA Request Form” to your supplier. Warranty Policy The customer is required to fill out the problem code as listed. - Page 19 Appendix A Terms and Conditions RMA Service Request Form When requesting RMA service, please fill out the following form. Without this form enclosed, your RMA cannot be processed. Reasons to Return: Repair(Please include failure details) RMA No: Testing Purpose Company: Contact Person: Phone No.
