- Page 1 Network Application Platforms Hardware platforms for next generation networking infrastructure FW-7571 V0.1 Preliminary User's Manual >> Publication date:2014-03-12...
- Page 2 Resource Website accordance with the instruction manual, may cause harmful interference to radio communications. Operation Lanner http://www.lannerinc.com of this equipment in a residential area is likely to cause harmful interference in which case the user will be required Product http://www.lannerinc.com/download-...
- Page 3 About About Consignes de sécurité LITHIUM BATTERY CAUTION: Risk of Explosion if Battery is replaced by an incorrect type. Suivez ces consignes pour assurer la sécurité générale : Dispose of used batteries according to the instructions • Laissez la zone du châssis propre et sans poussière pendant et après l’installation.
- Page 4 About About Sécurité de fonctionnement Cet appareil de protection doit être branché à la source d’alimentation avant l’alimentation CC. • L’équipement électrique génère de la chaleur. La température ambiante peut ne pas être adéquate pour refroidir l’équipement à une température de fonctionnement acceptable sans circulation adaptée.
-
Page 5: Table Of Contents
Lanner Generation 3 Bypass........ -
Page 6: Chapter 1: Introduction
2 x Intel i210AT, 1 x Controllers also features 6 GbE ports. In addition, the 4 (of all 6) Marvell 88E1543 LAN ports on the front panel are equipped with Lanner Ethernet Modules N/A proprietary Generation 3 bypass. Management Port N/A... -
Page 7: Ordering Information
431 x 44 x 305 mm (WxHxD) Dimensions Your package contains the following items: Weight 4 kg 150W ATX Power Supply • FW-7571 Network Security Platform Type/Watts Power Unit • Power cable Input 100~240V@50~60Hz CE Calss A, FCC Class A, •... -
Page 8: Front Panel Features
BIOS; the default is disabled). Two pairs (LAN1-LAN2, LAN3-LAN4) can be configured as LAN Bypass by using Lanner Gen3 Bypass technology when failure events occur. This feature can be enabled dynamically with a watch dog timer. Refer to your User’s Manual CD for a sample implementation of this feature. -
Page 9: Rear Panel Features
Chapter 1 Introduction Rear Panel Features R1 Reserved for PCIe Expansion Slot R2 CPU Fan This fan has smart fan feature which can be turned on automatically when the temperature exceeds the set threshold. R3 Power-on Switch It is a switch to turn on or off the power. R4 AC Power Socket The system equips an ATX 150W Power Supply. -
Page 10: Chapter 2: Hardware Setup
The system can accommodate two 2.5” Serial-ATA disks. does not completely shut off system power. Follow these steps to install a hard disk into the FW-7571: Portions of the power supply and some internal Unscrew the 4 screws on the hard disk tray to take out circuitry remain active until AC power is removed. - Page 11 2.5” HDD’s. installed in this orientation on the system. Follow these steps to install a hard disk to the FW-7571: Place hard disk on the hard disk tray and align the holes of the hard disk with the mounting holes on the tray.
-
Page 12: Installing The Compactflash Card
Hardware Setup Installing the CompactFlash Card This side is left blank intentionally. FW-7571 provides one CompactFlash slot. Follow the procedures bellow for installing a CompactFlash card. Align CompactFlash card and the card slot with the arrow pointing toward the connector. The card fits only the correct way into the slot;... -
Page 13: Chapter 3: Motherboard Information
Chapter 3 Motherboard Information Chapter 3: Motherboard Information Block Diagram The block diagram depicts the relationships among the interfaces or modules on the motherboard. Please refer to the following figure for your motherboard’s layout design. MB-7571 DDR3 MHz Non-ECC/ 2x SATA DIMM connectors Up to 16GB Maximum... -
Page 14: Motherboard Layout
Chapter 3 Motherboard Information Motherboard Layout The motherboard layout shows the connectors and jumpers on the board. Refer to the following picture as a reference of the pin assignments and the internal connectors. GPIO1 OPEN1 LPC1 JBAT1 COMB1 ATX1 CONN1 CONN2 COM1 USB1... -
Page 15: Jumper Settings
Chapter 3 Motherboard Information Jumper Settings USB Connector(USB2): It is for connecting the USB module cable. It complies with USB2.0 and support Fan Connectors(FAN2 ): The 5-pin connector is for up to 480 Mbps connection speed. connecting the CPU fan. It comes with the smart fan feature by which the fan could be monitored and turned on when the temperature exceed the set USB2... - Page 16 Chapter 3 Motherboard Information Serial Interface Connectors(COMB1): It is for Clear CMOS jumper (JBAT1): It is for clearing the CMOS connecting the RS-232 serial port (COM2) interface memory and system setup parameters by erasing cable. the data stored such as the system passwords in COMB1 the CMOS RAM.
- Page 17 Chapter 3 Motherboard Information DIMM Socket (DIMM1): The 240-pin DDR3 DIMM is for 4-Pin SATA Power Connector (PS4P1, PS4P2) connecting the DDR3 1333/1600 memory. The system can support up to 16 GB in maximum. Pin No. Function +12V 4 3 2 1 Ground AT Mode Power Button Connector (CONN1) It is for SATA Connector (SATA6G_1, SATA6G_2): It is for...
- Page 18 Chapter 3 Motherboard Information PCIe Expansion Connector (PCIEC1): PCIe expansion Digital GPIO (GPIO1) Connector connector (two PCIe x 4) for front Ethernet module or other type of expansion through the back panel. PIN NO. FUNCTION PIN NO. FUNCTION +12V PRSNT1# +12V +12V Pin No.
- Page 19 Chapter 3 Motherboard Information Case open (OPEN1): Case opening detection pin header Pin No. Description SIO_CASEOPEN# Network Application Platforms...
-
Page 20: Chapter 4: Bios Settings
Chapter 4 Bios Settings Chapter 4: keys, and so on. BIOS Settings Accessing the BIOS menu When you are installing a motherboard or when the system prompts “Run Setup” during start-up, you will use the BIOS Setup program to configure the system, . This section explains how to configure your system using this program. -
Page 21: The Main Menu
Chapter 4 Bios Settings The Main Menu The main BIOS setup menu is the first screen that you can navigate. Each main BIOS setup menu option is described in this chapter. The Main BIOS setup menu screen has two main frames. The left frame displays all the options that can be configured. -
Page 22: Advanced Settings
Chapter 4 Bios Settings Advanced Settings Select the Advanced tab from the setup screen to enter the Advanced BIOS Setup screen. You can select any of the items in the left frame of the screen, such as SuperIO Configuration, to go to the sub menu for that item. You can display an Advanced BIOS Setup option by highlighting it using the <Arrow>... - Page 23 Chapter 4 Bios Settings Super IO configuration Serial Port 0/1 Configuration Item Selection Serial Port Enable or disable this serial port Device Shows the serial port base address and IRQ port Settings Parallel port Configuration Item Selection Parallel Port Enable or disable this parallel port Device Shows the parallel port base address and IRQ Settings...
- Page 24 Chapter 4 Bios Settings PC Health Status This menu shows the hardware monitor configuration settings. Select an item then press <Enter> to display the configuration options. SYS/CPU Temperature The onboard hardware monitor automatically detects and displays the CPU and motherboard temperatures. FAN2 Speed (CPU FAN) The onboard hardware monitor automatically detects and displays the CPU fan speeds in rotations per minute (RPM).
- Page 25 Chapter 4 Bios Settings Console Redirection Use this menu to set the settings for BIOS remote access feature. Item Selection Console Redirection Enable or disable BIOS through remote access Console Redirection Set- Enter to view more options tings COM0 Console Redirection Settings Item Selection Terminal Type...
- Page 26 LAN Bypass function, refer to the Front Panel Feature in Chapter 1 Introduction. Note: the Ethernet expansion module may support Lanner Generation 2 or Generation 3 Bypass depending on the module specification. See appendix D Programming Generation 2 and 3...
- Page 27 Chapter 4 Bios Settings USB Configuration Setting You can use this screen to select options for the USB Configuration. Use the up and down <Arrow> keys to select an item. Use the <Plus> and <Minus> keys to change the value of the selected option. The settings are described on the following pages.
- Page 28 Chapter 4 Bios Settings USB Mass Storage Driv In this option, you can enable or disable the attached USB drive to be used as the system’s hard drive. USB Hardware Delays a The menu sets delay time for USB operations. Item Description USB transfer...
-
Page 29: Intel Rcsetup
Chapter 4 Bios Settings Intel RCSetup You can use this screen to view the capabilities and of your CPU. You can also use this menu to enable/disable certain functions of your CPU. Use the up and down <Arrow> keys to select an item. Use the <Plus> and <Minus> keys to change the value of the selected option. -
Page 30: North/South Bridge
Chapter 4 Bios Settings North/South Bridge The chipset menu will let you further configure your Intel CPU and PCH capabilities: SMBUS Controller Select to enable or disable the SMBUS controller. Be cautious that communications or devices that use this controller will be affected when setting this option. Restore on AC Power Loss This option lets you set the state of the system when it has just recovered from a power outage. - Page 31 Chapter 4 Bios Settings SATA Controllers Configuration Settings While entering Setup, the BIOS automatically detects the presence of SATA devices. The SATA Port items show “Empty” if no SATA device is installed to the corresponding SATA port. SATA Mode Selection The system supports various SATA mode.
-
Page 32: Security Settings
Chapter 4 Bios Settings Security Settings Select Security Setup from the Setup main BIOS setup menu. All Security Setup options, such as password protection and virus protection, are described in this section. To access the sub menu for the following items, select the item and press <Enter>: Administrator Password If you have set an administrator password, you should... -
Page 33: Boot Configuration
Chapter 4 Bios Settings Boot Configuration In this screen, you will be able to configure the boot procedures and the related elements. Items Options Setup Prompt Timeout Specify the number of seconds for the boot setup prompt to wait for user’s intervention during the POST. -
Page 34: Save & Exit
Chapter 4 Bios Settings Save & Exit Save and Exit Select the Exit tab from the setup screen to enter the Exit BIOS Setup screen. You can display an Exit BIOS Setup option by highlighting it using the <Arrow> keys. The following table lists the options in this menu. - Page 35 Chapter 4 Bios Settings Item Options Boot Override This section of the Boot Menu allows booting from a specific device immediately. Therefore you should see an entry for all bootable devices. Launch EFI Shell from This option allows you to filesystem device attempt to launch the EFI Shell application (shellx64.
-
Page 36: Appendix A: Programming Watchdog Timer
Appendix A Programming Watchdog Timer Appendix A: Programming Watchdog Timer A watchdog timer is a piece of hardware that can be used to automatically detect system anomalies and reset the processor in case there are any problems. Generally speaking, a watchdog timer is based on a counter that counts down from an initial value to zero. -
Page 37: Appendix B: Programming Generation 3 Lan Bypass
Different from the previous two generations Fro a description of the physical LAN ports equipped with (Gen1 and Gen2), the Lanner Bypass Gen 3 employs a this function, refer to Front Panel Features in Chapter 1 programming method to control the bypass function by Introduction. -
Page 38: Appendix C: Setting Up Console Redirections
Appendix C Setting up Console Redirection Appendix C: Setting up Console Redirections Console redirection lets you monitor and configure a system from a remote terminal computer by re-directing keyboard input and text output through the serial port. This following steps illustrate how to use this feature. The BIOS of the system allows the redirection of console I/O to a serial port. -
Page 39: Appendix D: Programming The Lcm
#Makefile.linux Type make to build source code: Note: The OS supported by Lanner LCM function include platforms based on Linux Kernel series #make Makefile (Note: omit the file extensions) 2.4.x and Linux Kernel series 2.6.x. -
Page 40: Appendix E: Installing Intel Quickassist Software For Linux
Appendix E Intel® QuickAssist Technology Appendix E: Installing Intel QuickAssist Software for Linux The FW-7573 platform incorporates Intel QuickAssist Technology, which includes acceleration modules that are accessed via Intel QuickAssist software. The Intel quickAssist software also enables the acceleration modules to be easily accessed by open source software such as OpenSSL. -
Page 41: Appendix F: Terms And Conditions
Appendix F Terms and Conditions Appendix F: RMA Service Terms and Conditions Requesting a RMA# To obtain a RMA number, simply fill out and fax the “RMA Request Form” to your supplier. Warranty Policy The customer is required to fill out the problem code as listed. - Page 42 Appendix F Terms and Conditions RMA Service Request Form When requesting RMA service, please fill out the following form. Without this form enclosed, your RMA cannot be processed. Reasons to Return: Repair(Please include failure details) RMA No: Testing Purpose Company: Contact Person: Phone No.
