Page 1 Valve terminal VTSA / VTSA-F Description of VTSA... pneumatics Valve terminal with VTSA pneumatics Type VTSA-44-FB Type VTSA-44-MP... Type VTSA-44-ASI Type VTSA-FB-03E... Type VTSA-F-45-FB… Type VTSA-F-45-MP Type VTSA-F-45-ASI Description 538923 en 1202g [756742]...
Page 3 ........538923 © (Festo AG & Co. KG, D-73726 Esslingen, 2012) Internet: http://www.festo.com E-Mail: service_international@festo.com...
Page 4 Contents and general instructions ® CAGE CLAMP is a registered trademark of the respective owner in certain countries. Festo P.BE-VTSA-44-EN en 1202g...
Page 5 ......1-46 Connection and display components of the electrical components ..1-49 Festo P.BE-VTSA-44-EN en 1202g...
Page 6 Address assignment of the valves ........3-53 Festo P.BE-VTSA-44-EN en 1202g...
Page 7 ..........5-23 Festo P.BE-VTSA-44-EN en 1202g...
Page 8 ............Festo P.BE-VTSA-44-EN en 1202g...
Page 9: Intended Use
CE marking. Standards and test values, which the product must comply with and fulfill, can be found in the section “Technical data”. The product-relevant EU directive can be found in the declar- ation of conformity. Festo P.BE-VTSA-44-EN en 1202g...
Page 10 – The technical data in this documentation may show val- ues deviating from this. Target group This manual is directed exclusively toward technicians trained in control and automation technology. Service Please consult your local Festo repair service if you have any technical problems. VIII Festo P.BE-VTSA-44-EN en 1202g...
Page 11 M23 round plug, M12 individual connections): For information on the electric/electronic components see the documentation supplied with the product. – Valve terminal with AS-interface: Information about the electric/electronic components is included in the documentation supplied with the product. Festo P.BE-VTSA-44-EN en 1202g...
Page 12 ... means that failure to observe this instruction may result in material damage. In addition, the following pictogram marks passages in the text which describe activities with electrostatically sensitive devices: Electrostatically sensitive devices: Incorrect handling may cause damage to devices. Festo P.BE-VTSA-44-EN en 1202g...
Page 13 Information about environmentally friendly use of products from Festo. Text markings Bullet points indicate activities which may be carried out • in any sequence. 1. Numerals identify activities which must be carried out in the sequence specified. – Arrowheads indicate general lists. Festo P.BE-VTSA-44-EN en 1202g...
Page 14 – Common exhaust port (3/5) FB 21, type 03 – INTERBUS “Rugged Line” optic fibre cable remote bus fieldbus connection – Input/output modules Intermediate solenoid – Plate with solenoid coils, air ducts and electric plug connectors to plate ISO 5599/2 Festo P.BE-VTSA-44-EN en 1202g...
Page 15 – Valve terminal VTSA (type 44) or VTSA-F (type 45) – With CPX terminal – With FB 21 (type 03) – AS-interface – Or with multi-pin node (Sub-D, cage clamp, M23 round plug or IC). XIII Festo P.BE-VTSA-44-EN en 1202g...
Page 16 Vertical pressure shut-off – Plate on a valve location for isolating the valve pressure supply plate Vertical pressure supply – Plate on a valve position for individual compressed air supply plate Tab. 0/1: Product-specific terms and abbreviations Festo P.BE-VTSA-44-EN en 1202g...
Page 17: Overview Of Components
Overview of components Chapter 1 Overview of components Festo P.BE-VTSA-44-EN en 1202g...
Page 18: Table Of Contents
......1-46 Connection and display components of the electrical components ..1-49 Festo P.BE-VTSA-44-EN en 1202g...
Page 19: Overview Of Components
Information on the electronics of the VTSA... valve terminal with multi-pin node can be found in the corresponding pack- age insert. Information on the electronics of the VTSA... valve terminal with AS interface can be found in the corresponding pack- age insert. Festo P.BE-VTSA-44-EN en 1202g...
Page 20: The Vtsa
1. Overview of components The VTSA... valve terminal Festo assists you in solving your automation tasks at machine level with VTSA... valve terminals. The modular structure of the valve terminal enables you to match it optimally in your machine or system.
Page 21 1) The maximum number of valve positions does not apply in the case of mixed components of a valve terminal with manifold sub-bases T1 and T2 or VIGM and VIGI. Tab. 1/2: Number of valve positions for VTSA... with CPX terminal or FB21, type 03 Festo P.BE-VTSA-44-EN en 1202g...
Page 22 1) The maximum number of valve positions does not apply in the case of mixed components of a valve terminal with manifold sub-bases T1 and T2. Tab. 1/4: Number of valve positions for VTSA... with AS-interface Festo P.BE-VTSA-44-EN en 1202g...
Page 23: Pneumatic Components, Width 18
The essential components of width 18 ... 52 mm are shown in Fig. 1/1 and Fig. 1/2. right end plate 90°-connection plate (optional) Pneumatic supply plates Manifold sub-base (optional) Fig. 1/1: Pneumatic base components of the VTSA... valve terminal (1st level) Festo P.BE-VTSA-44-EN en 1202g...
Page 24 Blanking plate for valve position Vertical pressure shut-off plate (optional) (optional) Valves Vertical pressure supply plate (optional) Exhaust port cover Flow control plate (optional) Fig. 1/2: Pneumatic base components of the VTSA... valve terminal (2nd level) Festo P.BE-VTSA-44-EN en 1202g...
Page 25: Main And Additional Supply
The pneumatic supply plate can also be used for additional supply. This is necessary, for example, if the valve terminal is operated with several pressure zones or if many valves simul- taneously are switched to flow or exhausted on the valve ter- minal. Festo P.BE-VTSA-44-EN en 1202g...
Page 26: Valves
VTSA… is provided via ports (3) and (5). The exhaust procedure is effected via port (1) also see section 3.8 and 3.8.1) All 5/2-way valves and 5/3-way mid-position valves can be used in all operating modes. 1-10 Festo P.BE-VTSA-44-EN en 1202g...
Page 27 Two monostable 3/2-way valves, normally closed Two monostable 3/2-way valves, control side 14 normally open, control side 12 normally closed Two monostable 3/2-way valves, normally open Reversible 3/2-way valves: Two monostable reversible 3/2-way valves, normally open 1-11 Festo P.BE-VTSA-44-EN en 1202g...
Page 28 14, the switching position 14 remains as is, since there is no spring return on control side 12. Switching position 12 is non-latching due to the mechanical spring force. Further information on the valves can be found in Appendix B. 1-12 Festo P.BE-VTSA-44-EN en 1202g...
Page 29: Manifold Sub-Bases
The pilot control of the solenoid coils is supplied with internal or external pilot air. This pilot air is made available for the entire valve terminal (also across pressure zones) through the soft-start valve or the various right end plate variants. The following applies: 1-13 Festo P.BE-VTSA-44-EN en 1202g...
Page 30 The valve terminal is always supplied with internal pilot air through the soft-start valve – Through the corresponding right end plate variants, you can choose whether the valve terminal should be supplied with internal or external pilot air. 1-14 Festo P.BE-VTSA-44-EN en 1202g...
Page 31 (12) or at the valve) You can ascertain the end plate with which your VTSA... valve terminal is fitted by means of the following table. Conversion between internal and external pilot air supply is described in section 5.5.2. 1-15 Festo P.BE-VTSA-44-EN en 1202g...
Page 32 3.4.2) Tab. 1/7: Variants of the right end plate for widths 18 ... 52mm Note Instructions for combining the soft-start valve and the right end plate can be found in the assembly instructions VABV-S6-1Q-... 1-16 Festo P.BE-VTSA-44-EN en 1202g...
Page 33: Pressure Zone Separation
A pressure zone separation of pilot ducts (12) and (14) is therefore not possible. You can ascertain the number of pressure zones with which your valve terminal is equipped by the marking on the sealing plate ( Fig.). 1-17 Festo P.BE-VTSA-44-EN en 1202g...
Page 34: Vertical Stacking
You can mount further pneumatic components in each loca- tion between the manifold sub-base and the valve. This ver- tical stacking will enable you to implement certain additional effects as desired. Tab. 1/8 shows the basic design and possible components of vertical stacking. 1-18 Festo P.BE-VTSA-44-EN en 1202g...
Page 35 VABF...A1G2... Working type VABV...T1 or connections (2) and (4) type VABV...T2 turned 90° 1) Instructions on installing the vertical stacking components ( chapter 3) Tab. 1/8: Components of the pneumatic module of the VTSA... valve terminal 1-19 Festo P.BE-VTSA-44-EN en 1202g...
Page 36 Identification 10 means the control range of the pressure regulator extends to 10 bar In the sales documentation and in the Festo Configurator, the components are marked with an ID code. You can identify the vertical stacking components with the aid of the following table.
Page 37 Intermediate plate for disconnectable pilot air Mechanical pressure switch for monitoring the disconnectable pilot air supply Electronic pressure switch for monitoring the disconnectable pilot air supply Tab. 1/9: Identification of the vertical stacking components 1-21 Festo P.BE-VTSA-44-EN en 1202g...
Page 38: Pressure Regulator Plates
– The pressure regulator is not affected by exhausting, since the pressure is regulated upstream of the valve. – The pressure regulator can be adjusted at any time, as the operating pressure is always present. 1-22 Festo P.BE-VTSA-44-EN en 1202g...
Page 39 (2) and (4) instead of the operating pressure of the valve terminal. – If the reversible pressure regulating valve cannot be used. For example, when 2x2/2-way valves or 2x3/2-way valves with ducted solenoid exhaust (82/84) or when a flow con- trol plate is used. 1-23 Festo P.BE-VTSA-44-EN en 1202g...
Page 40 A and then via the valve to duct (5). Port (2) (B) Port (4) (A) B-pressure regulator Manifold sub-base Valve Duct (5) (exhaust) A-pressure regulator Duct (1) (air) Intermediate plate Duct (3) (exhaust) Fig. 1/5: AB-pressure regulator 1-24 Festo P.BE-VTSA-44-EN en 1202g...
Page 41 AB-pressure regulator, the valve must switch for this. Disadvantages compared with the AB-pressure regulator: – No use of 2x2/2-way valves (ident. code: CV, VV) and 2x3/2-way valves (ident. code: K, H, N) is possible 1-25 Festo P.BE-VTSA-44-EN en 1202g...
Page 42 When, instead of the operating pressure of the valve ter- minal, two further different pressures are required in ducts (2) and (4). – When fast venting is required. – When the pressure regulator must always be adjustable. 1-26 Festo P.BE-VTSA-44-EN en 1202g...
Page 43 Port (4) (A) B-pressure regulator Manifold sub-base Valve Duct (5) (exhaust) A-pressure regulator Duct (1) (air) Intermediate plate Duct (3) (exhaust) Fig. 1/6: Reversible AB-pressure regulator For instructions on how to install this pressure regulator section 3.8.2 1-27 Festo P.BE-VTSA-44-EN en 1202g...
Page 44: Components For Protective Functions
The purpose of the soft-start valve type VABF-S6-1-P5A4-.. (ident. code SR) is to slowly and securely build up the supply pressure in duct (1) of the valve terminal or to quickly ex- haust duct (1) of the valve terminal. 1-28 Festo P.BE-VTSA-44-EN en 1202g...
Page 45 When the valve terminal is supplied with internal pilot air via the soft-start valve, the full operating pressure is always present at duct (14). This pressure causes the valves on the valve terminal to immediately move to the required switching 1-29 Festo P.BE-VTSA-44-EN en 1202g...
Page 46 – Protection against manipulation, prevention of unexpec- ted start-up (EN 1037) – Safe reversal of a hazardous movement, provided the reversing motion itself will not result in further hazards. 1-30 Festo P.BE-VTSA-44-EN en 1202g...
Page 47 Optional: 90°-connection plate type VABF...A1G2... Working connections (2) and (4) turned 90° Tab. 1/10: Control block The detailed description of the control block can be found in the operating instructions VOFA-..., which accompany the product. 1-31 Festo P.BE-VTSA-44-EN en 1202g...
Page 48: Manifold Sub-Base Vabf-S4
SPBA-B11R-G18-P-M12--0.25X Optional: 90°-connection plate type VABF...A1G2... Working connections (2) and (4) turned 90° Tab. 1/11: Components for switching the pilot air supply Further information appears in the assembly instructions for the vertical stacking plate. 1-32 Festo P.BE-VTSA-44-EN en 1202g...
Page 49: Pneumatic Components, Width 65 Mm
65 mm (ISO 3) consists of the following pneu- matic components: Adapter plate Pressure regulator plate Blanking plate right end plate Flow control plate Intermediate solenoid plate MUH Valve Manifold sub-base Fig. 1/8: Pneumatic components of the VTSA... valve terminal, width 65 mm 1-33 Festo P.BE-VTSA-44-EN en 1202g...
Page 50: Valves
MUH-5/2-D-3-FR-C-VI means that the valve is a monostable 5/2-way valve with mechanical spring. You can identify the valve function with the aid of the following table. In the sales documentation and in the Festo Configurator the valves are marked with an Ident. code. 1-34...
Page 51: Manifold Sub-Bases
Manifold sub-bases, width 65 mm Identification features for actuating one solenoid for actuating two solenoid coil per valve position coils per valve position Type code VIGM-04-D-3 VIGI-04-D-3 Tab. 1/13: Identification of the manifold sub-bases, width 65 mm 1-35 Festo P.BE-VTSA-44-EN en 1202g...
Page 52: Pilot Control
These vertical stackings enable you to implement certain additional functions as desired. The following diagram shows the avail- able components: Tab. 1/14 shows the basic design and possible components of vertical stacking. 1-36 Festo P.BE-VTSA-44-EN en 1202g...
Page 53 Manifold sub-base type VIGI-04-D-3 which supports the actu- ation of two solenoid coils 1) Instructions on installing the vertical stacking components chapter 3 Tab. 1/14: Components of the pneumatic module of the VTSA... valve terminal Width 65 mm 1-37 Festo P.BE-VTSA-44-EN en 1202g...
Page 54: Connection And Control Elements Of The Pneu. Components, Width 18
LR-ZP-A-D-3 indicates that this component is an A-pres- sure regulator. You can identify the vertical stacking compon- ents with the aid of the following table. In the sales docu- mentation and in the Festo Configurator, the components are marked with an ID code. Label in the Ident.-...
Page 55 Optional manual override cover cap, Working lines (2) and (4), per valve for non-detenting function of manual position override Inscription areas Fig. 1/9: Pneumatic Connection, display and operating elements of the basic compon- ents, width 18 ... 52 mm 1-39 Festo P.BE-VTSA-44-EN en 1202g...
Page 56 18 mm and 26 mm, with free- wheel unit) Port (1) (individual operating pressure for one valve position) Fig. 1/10: Connection and control elements of the vertical stacking components, width 18 ... 52 mm 1-40 Festo P.BE-VTSA-44-EN en 1202g...
Page 57 (non-detenting) “Air supply time” flow control screw Electrical terminal for solenoid coil Soft-start valve Port for optional pressure gauge Sensor for sensing the piston position Fig. 1/11: Connecting and operating elements of the soft-start valve 1-41 Festo P.BE-VTSA-44-EN en 1202g...
Page 58: Connection, Display And Operating Elements Of The Pneu
– ports (14) and (12) for pilot control of the valves of width 65 mm Pilot port (14) for supplying the valves of width 18 … 52 mm Fig. 1/12: Pneumatic Connection, display and control elements of the basic components, width 65 mm 1-42 Festo P.BE-VTSA-44-EN en 1202g...
Page 59 Adjusting screw for throttle flow (3) adjustment: pull knob out of locking Adjusting screw for throttle flow (5) position and turn) Connection for manometer Fig. 1/13: Connection and control elements of the vertical stacking components, width 65 mm 1-43 Festo P.BE-VTSA-44-EN en 1202g...
Page 60: Electrical Components
Per valve posi- tion, one or two solenoid coils (dependent on the manifold sub-base) and within the valve terminal, a maximum of 26 or 32 solenoid coils are controlled via the CPX terminal Tab. 1/2). 1-44 Festo P.BE-VTSA-44-EN en 1202g...
Page 61 Fig. 1/14: Electric components of the VTSA... valve terminal with CPX terminal Left end plate (type 03): FB 20 or FB 21 Further optional CPX modules Pneumatic interface Fig. 1/15: Electric components of the VTSA... valve terminal with CPX-M-FB20 or FB21 1-45 Festo P.BE-VTSA-44-EN en 1202g...
Page 62: Vtsa
The electrical connection of the solenoid coils is made cent- rally via a multi-pin plug connection that is available in differ- ent variants at the VTSA valve terminal ( following images). Dependent on the manifold sub-bases, one or two solenoid 1-46 Festo P.BE-VTSA-44-EN en 1202g...
Page 63 Fig. 1/18: Electric components of the VTSA... valve terminal with multi-pin node sub-D Cover Protective conduit with strain relief Multi-pin node Cage clamp Fig. 1/19: Electric components of the VTSA... valve terminal with multi-pin node cage clamp 1-47 Festo P.BE-VTSA-44-EN en 1202g...
Page 64 M23 round plug Fig. 1/20: Electric components of the VTSA... valve terminal with multi-pin node M23 round plug IC connections Multi-pin node Fig. 1/21: Electric components of the VTSA... valve terminal with multi-pin node IC 1-48 Festo P.BE-VTSA-44-EN en 1202g...
Page 65: Connection And Display Components Of The Electrical Components
Service interface for handheld, etc. the pilot solenoid coils red LED: common error display of the Power supply connection valves Earth terminal Fig. 1/22: Electrical connecting, display and operating elements of the VTSA... valve ter- minal with CPX terminal 1-49 Festo P.BE-VTSA-44-EN en 1202g...
Page 66 Service interface for handheld, etc. horizontal output of the power supply DIL switch (under the cover) connection (continuing) Fig. 1/23: Electrical connection, display and control elements of the VTSA... valve terminal with CPX-M-FB20 or FB21 1-50 Festo P.BE-VTSA-44-EN en 1202g...
Page 67 Fuse for operating voltage of inputs INTERBUS fibre optic cable interface (continuing) Output of the power supply connec- tion (continuing) Fig. 1/24: Electrical connecting, display and operating elements of the VTSA... valve ter- minal with FB 21, type 03 1-51 Festo P.BE-VTSA-44-EN en 1202g...
Page 68 (AS-i In) Inputs External earth connection yellow LEDs: signal status display of the pilot solenoid coils Inscription field Fig. 1/25: Electrical connection and display components of the VTSA... valve terminal with AS-interface 1-52 Festo P.BE-VTSA-44-EN en 1202g...
Page 69 Sub-D multi-pin socket with cable Sub-D connection Inscription field yellow LEDs: signal status display of the pilot solenoid coils Earth terminal Fig. 1/26: Electrical connection and display components of the VTSA... valve terminal with multi-pin node Sub-D 1-53 Festo P.BE-VTSA-44-EN en 1202g...
Page 70 LEDs: signal status display of the Internal earth terminal for the con- pilot solenoid coils necting cable Cable routing Terminal strip Inscription field Fig. 1/27: Electrical connection and display components of the VTSA... valve terminal with cage clamp multi-pin node 1-54 Festo P.BE-VTSA-44-EN en 1202g...
Page 71 LEDs: signal status display of the Inscription field pilot solenoid coils M23 round plug as per CNOMO E03.62.530.N Fig. 1/28: Electrical connection and display components of the VTSA... valve terminal with multi-pin node M23 round plug 1-55 Festo P.BE-VTSA-44-EN en 1202g...
Page 72 IC: M12 individual connections (IC) External earth connection yellow LEDs: signal status display of the pilot solenoid coils Fig. 1/29: Electrical connection and display components of the VTSA... valve terminal with multi-pin node IC 1-56 Festo P.BE-VTSA-44-EN en 1202g...
Page 73: Mounting
Mounting Chapter 2 Mounting Festo P.BE-VTSA-44-EN en 1202g...
Page 74 ..........2-17 Festo P.BE-VTSA-44-EN en 1202g...
Page 75: Mounting
CPX I/O modules or in the additional description of type 03 I/O modules. – Information on mounting modules and components ordered at a later stage can be found in the package insert. Festo P.BE-VTSA-44-EN en 1202g...
Page 76: General Instructions On Assembly And Dismantling
– Electrostatically sensitive devices. Therefore do not touch any contact areas. – Valve terminals with Sub-D multi-pin node: Protect the multi-pin node from moisture, dirt, dust, etc. until the multi-pin plug socket is fitted with a cable. Festo P.BE-VTSA-44-EN en 1202g...
Page 77: Mounting Variants
Fig. 2/1: Methods of mounting the VTSA... valve terminal Note Mount the VTSA... valve terminal in such a way that en- sures sufficient space for heat dissipation and compliance with the temperature limit values ( Appendix A, Technic- al data). Festo P.BE-VTSA-44-EN en 1202g...
Page 78: Mounting/Dismounting On H-Rails
This set consists of 2 x M4x10 screws and 2 clamping components. – for VTSA... valve terminals with CPX terminal: mounting set type CPX-CPA-BG-NRH This set consists of 3 x M4x10 screws and 3 clamping components. Festo P.BE-VTSA-44-EN en 1202g...
Page 79 35 mm, height 7.5 mm). Make sure there is suffi- cient space for connecting the power supply cables and tubing. 3. Fasten the H-rail to the mounting surface at intervals of approx. every 100 mm. Festo P.BE-VTSA-44-EN en 1202g...
Page 80 H-rail clamping unit Fig. 2/1: Mounting the VTSA... valve terminal on an H-rail 7. Secure the VTSA... valve terminal, as with the CPX termin- al, against tilting or sliding by tightening the retaining screw with 1.3 Nm. Festo P.BE-VTSA-44-EN en 1202g...
Page 81 Tab. 2/16). Make sure that the clamping component is horizontal to the H-rail. 2. Swing the VTSA... valve terminal forwards from the H-rail Fig. 2/3, arrow (B)). 3. Lift the valve terminal from the H-rail ( Fig. 2/3, arrow (A)). Festo P.BE-VTSA-44-EN en 1202g...
Page 82: Mounting/Dismounting On Walls
Fig. 2/3: Dismounting the VTSA... valve terminal from the H-rail 2.2.2 Mounting/dismounting on walls Note Mounting on uneven, flexible surfaces can result in dam- age to the VTSA... valve terminal. Mount the VTSA... valve terminal only onto an even, tor- • sionally rigid surface. 2-10 Festo P.BE-VTSA-44-EN en 1202g...
Page 83 Use the mounting holes in at least every second mani- fold sub-base. The following components contain holes for wall mounting Tab. 2/17). – End plates – Pneumatic interface – Multi-pin node – Manifold sub-bases, width 65 mm 2-11 Festo P.BE-VTSA-44-EN en 1202g...
Page 84 Make sure there is sufficient space for connecting the power supply cables and tubing. 2. Drill mounting holes in the mounting surface. 3. Secure the valve terminal to the mounting surface using screws of the appropriate length ( Tab. 2/17). 2-12 Festo P.BE-VTSA-44-EN en 1202g...
Page 85 1 Hole for M6 screw 2 Hole for M10 screw 3 Hole for M4 screw If necessary, use the following additional mounting options: – Holes (blind holes) on the rear of the manifold sub- bases for M8 thread. 2-13 Festo P.BE-VTSA-44-EN en 1202g...
Page 86 (rear mounting). M8 threads need to be cut for this purpose. All of the steps for wall mounting described above are also applicable here. 2-14 Festo P.BE-VTSA-44-EN en 1202g...
Page 87 1. Secure a mounted hanging valve terminal VTSA... from falling down before you loosen it from the mounting sur- face. 2. Loosen the mounting screws ( Tab. 2/17). 3. Remove the valve terminal from the mounting surface. 2-15 Festo P.BE-VTSA-44-EN en 1202g...
Page 88: Mounting/Dismounting The Optional Inscription Label Holder, Width 18
( image) Dismounting Pull the inscription label holder from the manifold sub-base. Fixture for in- scription label holder on the manifold sub- base Inscription label holder Fig. 2/5: Mounting the inscription label holder 2-16 Festo P.BE-VTSA-44-EN en 1202g...
Page 89: Mounting/Dismounting The Optional Manual Override Cover Caps, Width 18
2. Clip the cover caps into the recesses in the manual over- rides ( image) Manual override cover cap (manual override without function) Manual override cover cap (manual override non-detenting only) Manual override (MO) Fig. 2/6: Mounting the manual override cover caps 2-17 Festo P.BE-VTSA-44-EN en 1202g...
Page 90 Dismounting Proceed as follows: Pry the caps from the manual override by using a suitable • screwdriver ( image): Fig. 2/7: Dismounting the manual override caps 2-18 Festo P.BE-VTSA-44-EN en 1202g...
Page 91: Installation
Installation Chapter 3 Installation Festo P.BE-VTSA-44-EN en 1202g...
Page 92 Address assignment of the valves ........3-53 Festo P.BE-VTSA-44-EN en 1202g...
Page 93: Installation
I/O modules, etc.) can be found in the corresponding CPX module descriptions. Detailed instructions for connecting type 03 modules (bus nodes, I/O modules) can be found in the corresponding descriptions for the type 03 module. Festo P.BE-VTSA-44-EN en 1202g...
Page 94: Compressed Air Preparation
3.1.2 Operation with lubricated compressed air Operate system equipment with unlubricated compressed air if possible. This is better for the environment. Festo pneumat- ic valves and actuators have been designed so that, if used as intended, they will not require additional lubrication and will still achieve a long service life.
Page 95 Incorrect additional oil and too much residual oil content in the compressed air will reduce the service life of the valve terminal. – Use Festo special oil OFSW-32 or the alternatives listed in the Festo catalogue (as per DIN 51524-HLP32, basic viscosity 32 CST at 40 °C).
Page 96 Another indicator of over-lubrication is the coloration or the condition of the exhaust air silencer. A distinctly yellow col- ouring of the filter element or drops of oil on the silencer in- dicate that the lubricator setting is too high. Festo P.BE-VTSA-44-EN en 1202g...
Page 97: General Notes On Connecting The Tubing
The back pressures can lead to pneumatic actuation of other valves, especially with un- switched 3/2-way valves that are normally closed. Festo P.BE-VTSA-44-EN en 1202g...
Page 98: Installing The Tubing
First mount the tubing at port (1) and then at ports (3) and (5). Secure the tubing with a hose clamp 3 3. For a better overview of the system group the tubing to- gether with: - tubing straps or - multi-tube holders Festo P.BE-VTSA-44-EN en 1202g...
Page 99 3. Installation Fig. 3/1: Mounting the tubing connections Festo P.BE-VTSA-44-EN en 1202g...
Page 100 1. Mark all pneumatic tubing. 2. Depending on connection: – Press down the locking ring of the threaded connector 1, e.g. with a Festo QSO releasing tool. Loosen the clamping screw 2 of the threaded con- – nector. Loosen the hose clamp screw 3.
Page 101 3. Installation Fig. 3/2: Removing the tubing 3-11 Festo P.BE-VTSA-44-EN en 1202g...
Page 102: Connecting The Vtsa
As per standard ISO 15407-2 and 5599-2, ports (12) and (14) are intended for supplying the valve terminal with external pilot air. The Festo valves for the VTSA... valve terminal require a pilot air supply exclusively via duct (14). In the case of the reversible 2x3/2-way valves from Festo, additional operating pressure is also required at duct (12) for the pneumatic spring.
Page 103: Pilot Air Supply
(duct (14)) within the valve terminal. Exhaust air cannot be expelled via the soft-start valve. An exhaust plate is required for operation in a pressure zone with separated ducts (1) and (3/5). 3-13 Festo P.BE-VTSA-44-EN en 1202g...
Page 104 Appendix A, Tab. A/6 or in the diagrams Fig. A/1. Check which pilot variant your valve terminal has been de- signed for ( section 1.2.4 “Pilot control (pilot air supply)”). Carry out the necessary installations or settings in accord- ance with the following table: 3-14 Festo P.BE-VTSA-44-EN en 1202g...
Page 105 The valve terminal may only be operated in positions 3 • and 4 of the selector plate. Otherwise, pilot air 12 may escape at the interface to the valve when the valve is replaced and the pilot pressure could break down. 3-15 Festo P.BE-VTSA-44-EN en 1202g...
Page 106 14 to control side 12. This is guaran- teed with Festo valves. Valves from other manufacturers might have to be additionally supplied with external pilot air via port (12).
Page 107 Pilot control with external pilot air supply: Supply the external pilot air via port (14) 3. • Note: Valve terminal with soft-start valve: Observe the information in the as- sembly instructions VABV-S6-1Q-... Tab. 3/1: Variants of the right end plate 3-17 Festo P.BE-VTSA-44-EN en 1202g...
Page 108 – Pilot air supply branched from duct (1) – Pilot exhaust air (82/84) via port (12) 1) Reversible 2x3/2-way valves from Festo (ident. code P, Q and R) require operating pressure at port (12) to ensure the functionality of the pneumatic spring.
Page 109: Pilot Control, Width 65 Mm
P1. Note Internal pilot air is branched centrally from supply chan- • nel 1 for all valve solenoid coils. This also applies when valve terminal type 04-B is operated with several pres- sure zones. 3-19 Festo P.BE-VTSA-44-EN en 1202g...
Page 110 Fig. 3/4: Position of the code seal with internal pilot air External pilot air supply If the operating pressure lies below 3 bar, the pilot control of the valve solenoid coils must be operated with external pilot air. 3-20 Festo P.BE-VTSA-44-EN en 1202g...
Page 111 Fig. 3/5). The flow from P1 to the pilot channels is therefore blocked. Plug pin port P1 Fig. 3/5: Intermediate solenoid plate, positions of the plug pin in air duct P1 3-21 Festo P.BE-VTSA-44-EN en 1202g...
Page 112 3. Installation – the arrow of the code seal points to S on the pneumatic spring side ( Fig. 3/6). Code seal Cover Fig. 3/6: Position of the code seal with external pilot air 3-22 Festo P.BE-VTSA-44-EN en 1202g...
Page 113: Pressure Zone Separation, Width 18
The pressure zone which is supplied via supply port (1) • of the right end plate must be operated with a pressure that corresponds to the required pilot pressure for the valve terminal at the very least ( Appendix A, Tab. A/6, Fig. A/1). 3-23 Festo P.BE-VTSA-44-EN en 1202g...
Page 114 Ports (12) or (14) on the right end plate are for valve termin- als with pilot control by means of external pilot air supply. By mounting an additional supply plate within a pressure zone you can provide additional supply air or extract exhaust air. 3-24 Festo P.BE-VTSA-44-EN en 1202g...
Page 115 Supply plate of pressure zone 1 Right end plate with port (14) for external pilot air supply Fig. 3/7: Example of VTSA... valve terminal with 3 pressure zones and pilot control via external pilot air supply 3-25 Festo P.BE-VTSA-44-EN en 1202g...
Page 116: Pressure Zone Separation, Width 65 Mm
(1) and, for special cases, in the exhaust ducts (3 or 5) as well. Pressure zone 1 Pressure zone 2 External pilot air Supply air Fig. 3/8: Terminal with pilot control through external pilot air and two pressure zones 3-26 Festo P.BE-VTSA-44-EN en 1202g...
Page 117: Reversibly Operated Vtsa
(12) (venting of pilot exhaust air via port (12)) Note If the valve terminal is equipped with reversible 3/2-way • valves (ident. code P, Q and R), you operate the valve terminal exclusively in position 1 of the selector plate. 3-27 Festo P.BE-VTSA-44-EN en 1202g...
Page 118: Operating The Vtsa
1 or 2 of the selector plate Tab. 3/2). If this pressure zone is operated in a revers- ible manner, however, the valve terminal should only be operated in position 1 of the selector plate ( Tab. 3/2). 3-28 Festo P.BE-VTSA-44-EN en 1202g...
Page 119: Operating The Vtsa
P, Q and R) on reversible pressure regulators (iden- tifier R5) must not be operated in a separate pressure zone. The reversible pressure regulating valves supply pressure via duct (1) and vent the exhaust air via ducts (3) and (5). 3-29 Festo P.BE-VTSA-44-EN en 1202g...
Page 120: Setting The Pressure Regulating Valve
2. Set the control pressure on the corresponding pressure regulator. 3. Place the rotary knob back onto the pressure regulating valve. 4. Press the rotary knob downwards towards the housing. 3-30 Festo P.BE-VTSA-44-EN en 1202g...
Page 121 4. Set the control pressure on the corresponding pressure regulator. 5. Push the rotary knob in the unconnected status down to the regulator head. 6. Tighten the screw in the middle opening of the rotary knob. 3-31 Festo P.BE-VTSA-44-EN en 1202g...
Page 122 In this case, turn the rotary knob clockwise or anti-clockwise a few degrees until it can be noticeably pressed down some millimetres. If necessary, 8. Pull the key out. 3-32 Festo P.BE-VTSA-44-EN en 1202g...
Page 123 1. Rotary knob in safety level Rotary knob in setting level Rotary knob Rotary knob in free-running level Fig. 3/9: Setting the pressure regulator plates (widths 18 mm and 26 mm) using the rotary knob 3-33 Festo P.BE-VTSA-44-EN en 1202g...
Page 124 26 mm), use the socket head screw in the adjusting knob. Proceed as follows: Turn the adjusting screw (position Fig. 3/11) to set the • desired controlled variable ( “Flow diagrams of the pressure regulator plates” in Appendix A). 3-34 Festo P.BE-VTSA-44-EN en 1202g...
Page 125 3. Installation Adjusting screw, internal hexagon socket (A/F 2.0) Fig. 3/11: Setting the pressure regulator plates (widths 18 mm and 26 mm) using the adjusting screw 3-35 Festo P.BE-VTSA-44-EN en 1202g...
Page 126: Vacuum / Low-Pressure Operation
–0.9 ... 3 bar: – The pilot control is operated with an external pilot air supply. – The valve terminal is fitted with the following valve sub- bases and sometimes has additional pressure zones. 3-36 Festo P.BE-VTSA-44-EN en 1202g...
Page 127 – To enable the ejector pulse during vacuum operation a connection is to be established between the suction line and the pressure line via a T-piece. 3-37 Festo P.BE-VTSA-44-EN en 1202g...
Page 128: Connecting The Pneumatic Lines
It is possible to mount the 90°-connection plate with the exit for the working ports in the direction of the valve base level, but this is not supported by Festo because the desig- nation of the ports no longer applies in this direction of mounting.
Page 129 For external pilot air supply connect the pilot air as follows: – for widths up to 52 mm in the adapter plate. – for width 65 mm in the right end plate. 3-39 Festo P.BE-VTSA-44-EN en 1202g...
Page 130 Important information about this can be found in the assembly instructions VABV-S6-1Q-... First mount the seals and then the fittings and/or silencer (position of the ports Fig. 3/12, Fig. 3/13 and Fig. 3/14. Port size following tables). Then lay the tubing. 3-40 Festo P.BE-VTSA-44-EN en 1202g...
Page 131 – G1", 1" NPT – in the adapter plate 1) Depending on what you have ordered, the valve terminal will already be equipped with threaded connectors. Tab. 3/4: Supply and disposal ports, standard operation 3-41 Festo P.BE-VTSA-44-EN en 1202g...
Page 132 Width 42 mm: – GÅ, Å”NPT Width 52 mm: – G½”, ½”NPT 1) Depending on what you have ordered, the valve terminal will already be equipped with threaded connectors. Tab. 3/5: Supply and disposal ports, reversible operation 3-42 Festo P.BE-VTSA-44-EN en 1202g...
Page 133 2) The external pilot air is supplied as standard via port (14). 3) Requirement: The valve terminal must be equipped with Festo valves (except reversible 2x3/2-way valves). Observe the correct position of the seals below the valves section 5.5.1, also observe the information in the section “Common lines”...
Page 134 – GÅ”, Å”NPT Width 52 mm: – G½“, ½”NPT Width 65 mm: – G½“, ½”NPT 1) Depending on what you have ordered, the valve terminal will already be equipped with threaded connectors. Tab. 3/7: Working ports 3-44 Festo P.BE-VTSA-44-EN en 1202g...
Page 135 Width 18 ... 52 mm Working ports of the valve terminal and supply ports for the valve terminal with selector end plate (3/5) Fig. 3/12: Position of the pneumatic ports, part 1 (width 18 … 52 mm) 3-45 Festo P.BE-VTSA-44-EN en 1202g...
Page 136 Supply ports for valve terminals valve terminal with soft-start valve with axial ports in the right end plate (3/5) (14) (12) (12) Fig. 3/13: Position of the pneumatic ports, part 2 (width 18 … 52 mm) 3-46 Festo P.BE-VTSA-44-EN en 1202g...
Page 137 Note In the case of several systems with centrally ducted ex- haust air: Use non-return valves in the exhaust tubing or pilot air • tubing in order to prevent functional impairment due to back pressures. 3-47 Festo P.BE-VTSA-44-EN en 1202g...
Page 138 3. Installation Valve terminal 1 Exhaust tubing 3/5 Central pilot exhaust tubing Central exhaust line 3/5 Valve terminal 2 Pilot air exhaust tubing Fig. 3/15: Centrally ducted exhaust air with non-return valves 3-48 Festo P.BE-VTSA-44-EN en 1202g...
Page 139: Connecting The Electric Cables
STOP (e.g. switching off the operating voltage for the valves and output modules, switching off the compressed air). Caution Long signal lines reduce the resistance to interference. Do not exceed the maximum permitted signal line length of 30 m. 3-49 Festo P.BE-VTSA-44-EN en 1202g...
Page 140 3. Installation Note For valves with ident. code SO, SQ, SP and SN (valves with switching position sensing via sensor), Festo recommends using lines with straight plugs. VTSA... valve terminal with CPX terminal: Instructions on connecting the operating voltage can be found in the CPX system description, chapter 3.
Page 141 VTSA... valve terminal with FB 21 (type 03): • Please note the earthing instructions in chapter 2 of the FB 21 electronics system manual. This prevents interference from electromagnetic sources and ensures electromagnetic compatibility in accordance with EMC directives. 3-51 Festo P.BE-VTSA-44-EN en 1202g...
Page 142 Valve terminal with M23 round Valve terminal with multi-pin multi-pin node plug multi-pin node node IC connections Earth terminal Internal earth terminal in the cage clamp multi-pin node Fig. 3/16: Earth terminals of the VTSA... valve terminal 3-52 Festo P.BE-VTSA-44-EN en 1202g...
Page 143: Address Assignment Of The Valves
The following assignment applies: – solenoid coil 14 occupies the lower-value address – solenoid coil 12 occupies the higher-value address. Identification features: – Colour of the solenoid coil contact housing in the manifold sub-base: black 3-53 Festo P.BE-VTSA-44-EN en 1202g...
Page 144 (identifier: rating plate with black dot) Manifold sub-base (width 42 mm or 52 mm) which occupies two addresses Fig. 3/17: Example: Address assignment of VTSA... valve terminal with 8 valve positions, width 18 ... 52 mm (top view) 3-54 Festo P.BE-VTSA-44-EN en 1202g...
Page 145 VIGM-...) or two addresses (manifold sub-base VIGI-...), irrespective of whether it is fitted with a valve or a blanking plate. The following allocation applies in this case: – Coil 14: lower-value address – Coil 12: higher-value address 3-55 Festo P.BE-VTSA-44-EN en 1202g...
Page 146 Spare position with blanking plates on manifold sub-base VIGI-04-D-3 Intermediate solenoid plate MUH MUH with one solenoid coil on mani- fold sub-base VIGM-04-D-3 Fig. 3/18: Example: Address assignment of VTSA... valve terminal, width 65 mm, 8 valve positions (top view) 3-56 Festo P.BE-VTSA-44-EN en 1202g...
Page 147 CPX terminal can be found in the manual for the CPX I/O modules. Instructions on addressing the VTSA... valve terminal with FB21 (type 03) can be found in the corresponding description of the fieldbus. 3-57 Festo P.BE-VTSA-44-EN en 1202g...
Page 148 3. Installation 3-58 Festo P.BE-VTSA-44-EN en 1202g...
Page 149: Commissioning
Commissioning Chapter 4 Commissioning Festo P.BE-VTSA-44-EN en 1202g...
Page 150 ........4-17 4.5.2 Operating states of the pneumatic system ....4-18 Festo P.BE-VTSA-44-EN en 1202g...
Page 151: Commissioning
The commissioning procedure for the CPX terminal is de- scribed in the corresponding manual for the CPX bus node. The commissioning procedure for the FB21 (type 03) is de- scribed in the FB 21 electronics manual. Festo P.BE-VTSA-44-EN en 1202g...
Page 152: General Notes
Operate the valve terminal with external pilot air • corresponding to the pressure specified in appendix A, Tab. A/6. The pilot air is to be branched in front of the soft-start valve for gradual pressure build-up image). Festo P.BE-VTSA-44-EN en 1202g...
Page 153 82/84 12/14 12/14 Externally supplied pilot air, branched in front of the soft-start valve Soft-start valve of complete supply Fig. 4/1: Example of valve-cylinder combination with slow pressure build-up of the complete system Festo P.BE-VTSA-44-EN en 1202g...
Page 154: Manual Override (Mo)
By actuating the manual override, you can switch the valve without an electric signal. You only need to switch on the compressed air supply. Festo P.BE-VTSA-44-EN en 1202g...
Page 155: Manual Override, Width 18
4.2.1 Manual override, width 18 … 52 mm Note If the VTSA... valve terminal is used in a dusty environ- ment, Festo recommends you protect the manual overrides against dirt and dust after commissioning with cover caps of type VAMC-S6-CS. At the same time the manual over- rides are protected against incorrect use.
Page 156: Manual Override, Width 65 Mm
The position of the manual overrides on the intermediate plate and the valve terminal can be seen in the following im- ages: non-detenting manual override Tab. 4/3: Position of the manual overrides on the intermediate plate Festo P.BE-VTSA-44-EN en 1202g...
Page 157 4. Commissioning LED and manual override for valve LED and manual override for valve solenoid coil 14 solenoid coil 12 Tab. 4/4: Position of the solenoid coils and manual overrides on the valve terminal Festo P.BE-VTSA-44-EN en 1202g...
Page 158: Checking The Valves And The Valve/Actuator Combination
Tab. 4/5: Commissioning variants Commissioning the pneumatic components by means of the manual override is described below. The commissioning procedure for the CPX terminal is de- scribed in the corresponding manual for the CPX bus node. 4-10 Festo P.BE-VTSA-44-EN en 1202g...
Page 159 A valve that is reversed by an applied electrical signal can- not be switched back by actuating the manual override. The electric signal is dominant in this case. Reset the electric signal before actuating the manual • override. 4-11 Festo P.BE-VTSA-44-EN en 1202g...
Page 160 If the manual override is in the actuated state, it is not pos- sible to reset the valve to its neutral position with an elec- tric signal. The manual override is dominant in this case. 4. Switch off the compressed air supply after testing the valves. 4-12 Festo P.BE-VTSA-44-EN en 1202g...
Page 161 – returns to the rest spring resets the plun- position (not for ger of the manual over- bistable 5/2-way ride to the initial posi- valves (ident. tion). code J, D) Tab. 4/6: Non-detenting operation of the manual override 4-13 Festo P.BE-VTSA-44-EN en 1202g...
Page 162 – returns to the rest position (not wise through 90° as far as its for bistable 5/2-way valves stop. (ident. code J, D) • Then release the plunger. Tab. 4/7: Detenting operation of the manual override 4-14 Festo P.BE-VTSA-44-EN en 1202g...
Page 163: Led Display Of The Valves
– the pilot exhaust is blocked or – Servicing required *) With double-solenoid valves the LED lights up only when the electric pulse is present. Tab. 4/8: LED display of the solenoid coil (width 18 … 52 mm 4-15 Festo P.BE-VTSA-44-EN en 1202g...
Page 164: Valves, Widths 65 Mm
– the pilot exhaust is blocked or – Servicing required *) With double-solenoid valves the LED lights up only when the electric pulse is present. Tab. 4/9: LED display for the switching status of the solenoid coil (width 65 mm) 4-16 Festo P.BE-VTSA-44-EN en 1202g...
Page 165: Fault Finding
For valve terminals that are operated with external pilot air: • after switching on again, check the pilot pres- sure (adjust in accordance with the operating pressure if necessary, Chapter 3) Tab. 4/10: Function impairment of the pneumatic system 4-17 Festo P.BE-VTSA-44-EN en 1202g...
Page 166: Operating States Of The Pneumatic System
Width 65 mm: section 5.5.5) through isolating discs. Vacuum or external pilot air, pressure range Please observe the requirements for low-pressure operating the valve terminal with Tab. A/6. operation vacuum or low pressure section 3.9). 4-18 Festo P.BE-VTSA-44-EN en 1202g...
Page 167 Slow start-up after if control signals are applied, the EMERGENCY STOP pilot air must be present immediately after activation with the pilot pressure specified in Tab. A/6 at the very least Tab. 4/11: Pneumatic operating states 4-19 Festo P.BE-VTSA-44-EN en 1202g...
Page 168 4. Commissioning 4-20 Festo P.BE-VTSA-44-EN en 1202g...
Page 169: Conversion And Maintenance
Conversion and maintenance Chapter 5 Conversion and maintenance Festo P.BE-VTSA-44-EN en 1202g...
Page 170 Adding a soft-start valve ........5-43 Festo P.BE-VTSA-44-EN en 1202g...
Page 171: Conversion And Maintenance
Information for mounting/dismounting and connecting the electric components can be found in the FB21 electronics manual. VTSA... valve terminals with multi-pin: Instructions on connecting the electric components can be found in the information supplied with the product. Festo P.BE-VTSA-44-EN en 1202g...
Page 172: General Preventive Action
• Secure the components free of distortion and mechanic- • al tension. Check seals for damage (IP 65). • Make sure mounting surfaces are clean and dry (sealing • effect, prevention of leakage and contact faults). Festo P.BE-VTSA-44-EN en 1202g...
Page 173: Dismantling The Valve Terminal
– Valves – Pressure regulators – Exhaust plates – Cover plates – Flow control valves – Exhaust port cover – Soft-start valve – Vertical pressure shut-off plates – Vertical supply plates Tab. 5/1: Pneumatic components Festo P.BE-VTSA-44-EN en 1202g...
Page 174 Disconnecting the electrical connections Disconnecting the pneumatic connections The procedure for disconnecting the pneumatic connections is described in chapter 3.2.1. Dismantling the valve terminal The procedure for dismantling the valve terminal is described in chapter 2.2.1 and 2.2.2. Festo P.BE-VTSA-44-EN en 1202g...
Page 175: Replacing The Solenoid Coil Fuse, Width 65 Mm
3. Carefully remove the fuse from its base. ( Fig. 5/3), – right: fuse for solenoid coil 14 – left: fuse for solenoid coil 12. 4. Insert the new fuse 5. Close the cover. 6. To replace additional fuses repeat procedure 1 to 5. Festo P.BE-VTSA-44-EN en 1202g...
Page 176 5. Conversion and maintenance Loosen the fastening screws in the Carefully remove the fuse from its cover base. Right fuse for solenoid coil 14 Left fuse for solenoid coil 12 Fig. 5/3: Replacing a solenoid coil fuse Festo P.BE-VTSA-44-EN en 1202g...
Page 177: Replacing Valve Terminal Components
Dismounting Proceed as follows: Use a screwdriver with a narrow blade to loosen the • mounting screws and remove the component from the manifold sub-base ( Fig. 5/1). Festo P.BE-VTSA-44-EN en 1202g...
Page 178 Valve width 18 mm (VSVA-...-A2): 1.0 Nm (±10 %) – Valve width 26 mm (VSVA-...-A1): 2.0 Nm (±10 %) – Valve width 42 mm (VSVA-...-D1): 3.0 Nm (±20 %) – Valve width 52 mm (VSVA-...-D2): 6.5 Nm (±20 %) 5-10 Festo P.BE-VTSA-44-EN en 1202g...
Page 179: Replacing The Cover Plate With A Valve, Width 65 Mm
3. Place the intermediate solenoid plate on the manifold sub-base. 4. If applicable, place additional components on the inter- mediate solenoid plate and screw these components tight. 5. Fasten the valve. 5-11 Festo P.BE-VTSA-44-EN en 1202g...
Page 180 5. Conversion and maintenance ISO valve If applicable components for vertical stacking Intermediate solenoid plate Manifold sub-base Fig. 5/1: Fitting the valve 5-12 Festo P.BE-VTSA-44-EN en 1202g...
Page 181: Replacing/Adding Components For Vertical Stacking, Width 18
The printed part number on the regulator plate only refers to the standard configuration. When reordering pressure regulators with additional features, such as a lockable rotary knob, extended design etc., only use the VABF configurator. 5-13 Festo P.BE-VTSA-44-EN en 1202g...
Page 182 The following component sequence is recommended for valve positions with vertical stacking: Manifold sub- base Optional Vertical supply plate Optional vertical pressure shut-off plate Optional flow control plate Optional pressure regulator plate Valve Fig. 5/2: Assembly sequence for vertical stacking 5-14 Festo P.BE-VTSA-44-EN en 1202g...
Page 183 Appendix A, Tab. A/6 and Fig. A/1). – Combining reversible valve terminals with the following vertical stacking components is not permitted: – reversible pressure regulator plates – Flow control plates – Vertical pressure shut-off plates – Vertical supply plates 5-15 Festo P.BE-VTSA-44-EN en 1202g...
Page 184 1. Check the seals for damage. Replace any damaged seals. 2. Place the new component at the valve position, possibly on a component that is already mounted. 3. Fasten the new component. Width across flats for the Allen key Tab. 5/3. 5-16 Festo P.BE-VTSA-44-EN en 1202g...
Page 185 Vertical stacking with pressure regulator plate Item Width across flats of the Allen key Valve width 18 mm 26 mm 42 mm 52 mm Tab. 5/3: Vertical stacking 4. Fit the removed components in the same manner as before. 5-17 Festo P.BE-VTSA-44-EN en 1202g...
Page 186: Replacing/Adding Components For Vertical Stacking, Widths 65 Mm
1. Check the seals for damage. Replace the seals if they are damaged. 2. Place the new component on the intermediate solenoid plate or, if applicable, onto a component already fitted. 3. Fasten the new component. 4. Re-assemble the dismantled components in reverse order. 5-18 Festo P.BE-VTSA-44-EN en 1202g...
Page 187: Replacing The Exhaust Plate Or Exhaust Port Cover, Widths 18
An overview is provided by table Tab. 1/3. Dismounting Proceed as follows: 1. Disconnect the electrical and pneumatic connections and then remove the valve terminal from its mounting surface section 5.2). 5-19 Festo P.BE-VTSA-44-EN en 1202g...
Page 188 Fig. 5/4: Position of the screw connectors with example of the right end plate 5. Disconnect the corresponding component from the adja- cent component Mounting Proceed as follows: 1. Make sure the seals are not damaged. Replace the seals if they are damaged. 5-20 Festo P.BE-VTSA-44-EN en 1202g...
Page 189 2. Place the sealing plate on the guide pins of the manifold sub-base or pneumatic supply plate (sealing plates with duct separation section 3.6). Manifold sub-base Guide pins Sealing plate (optionally with duct separation) Fig. 5/5: Mounting manifold sub-bases 5-21 Festo P.BE-VTSA-44-EN en 1202g...
Page 190 3.0 Nm (±10 %). (Posi- tion of the fittings Fig. 5/4). 4. Mount the valve terminal on the mounting surface section 2.2.1 and 2.2.2). 5. Then install the electrical and pneumatic connections section 3.10 and 3.11). 5-22 Festo P.BE-VTSA-44-EN en 1202g...
Page 191: Replacing The Manifold Sub-Base Or Right End Plate, Size 65 Mm
3. Loosen the fuse covers for all of the manifold sub-bases that are to be dismantled. Doing this will create more space to dismantle the fittings. Tilt the covers downwards. 5-23 Festo P.BE-VTSA-44-EN en 1202g...
Page 192 5. Conversion and maintenance Fig. 5/7: Loosening the fuse cover 4. Loosen the screws from the corresponding components Fig. 5/8). 5-24 Festo P.BE-VTSA-44-EN en 1202g...
Page 193 1. Make sure the seals are not damaged. Replace the seals if they are damaged. 2. Insert the seals into the grooves of supply ducts 1, 3, 5, 12, and 14 in the manifold sub-bases ( Fig. 5/9 and Fig. 5/10). 5-25 Festo P.BE-VTSA-44-EN en 1202g...
Page 194 5. Conversion and maintenance Manifold sub-base Seals Groove for seal (duct 3 here) Fig. 5/9: Mounting manifold sub-bases Manifold sub-base Seals right end plate Groove for seal (duct 3 here) Fig. 5/10: Mounting the right end plate 5-26 Festo P.BE-VTSA-44-EN en 1202g...
Page 195 4. Then screw the right end plate to the last manifold sub- base. When doing this use the original socket head screws and spring washers. Tighten the screws lightly in turn to begin with and then tighten with 9 Nm ±10 % (pos- ition Fig. 5/12). 5-27 Festo P.BE-VTSA-44-EN en 1202g...
Page 196 End plate Fig. 5/12: Fitting the end plate 5. Tilt all loosened fuse covers upwards: tighten the screws of the covers using 1 Nm ±20 %. (Position Fig. 5/7). Fig. 5/13: Mounting manifold sub-bases 5-28 Festo P.BE-VTSA-44-EN en 1202g...
Page 197 5. Conversion and maintenance 6. Mount the valve terminal on the mounting surface section 2.2.2). 7. Then install the electrical and pneumatic connections section 3.10 and 3.11). 5-29 Festo P.BE-VTSA-44-EN en 1202g...
Page 198: Converting The Vtsa
1. Please observe the general safety measures in the section 5.1. 2. Use a screwdriver with a narrow blade to loosen the mounting screws for all the valves. Remove the valves from the manifold sub-bases ( Fig. 5/1). 5-30 Festo P.BE-VTSA-44-EN en 1202g...
Page 199 4. If necessary, turn all of the valve seals according to the desired exhaust air variant ( Fig. 5/14). Identification label The seal is visible in the inspection window on control side 14 Inspection window on control side 12 Fig. 5/14: Turning the valve seal 5-31 Festo P.BE-VTSA-44-EN en 1202g...
Page 200: Conversion, Internal Or External Pilot Air Supply, Width 18
In addition, you can also specify whether the pilot exhaust air should be vented via port (12) (deviating from the ISO standard). End plates with axial supply ports type VABE...R-... or VABE-...RZ-... Replacing the end plates is described in section 5.4.6. 5-32 Festo P.BE-VTSA-44-EN en 1202g...
Page 201: Conversion, Internal Or External Pilot Air Supply, Widths 65 Mm
For internal pilot air supply: • Seal the ports 12 and 14 on the right end plate with blanking plugs (these need to be ordered separately). Changing the position of the plug pins 1. Loosen the valve. 5-33 Festo P.BE-VTSA-44-EN en 1202g...
Page 202 14 and P1 Turning the code seal Note The code seal may only be turned on valves with pneumat- ic spring. This can be found under the cover on the pneu- matic spring side of the ISO-C-valve. 5-34 Festo P.BE-VTSA-44-EN en 1202g...
Page 203 Fasten the cover with the two slotted head screws. • Code seal Position of the code seal Position of the code seal with external pilot air with internal pilot air Cover Fig. 5/16: Code seal 5-35 Festo P.BE-VTSA-44-EN en 1202g...
Page 204: Conversion, Vtsa
– Sealing plate with duct separation type VABD-...-10-P...-C – A pneumatic supply plate with exhaust plate or exhaust cover type VABF-...-1P1A... for each pressure zone 5-36 Festo P.BE-VTSA-44-EN en 1202g...
Page 205 2. Mount the manifold sub-base ( section 5.4.6). 3. Mount the valve terminal on the mounting surface section 2.2.1 for H-rail mounting or section 2.2.2 for wall mounting). 4. Then install the electrical and pneumatic connections section 3.3). 5-37 Festo P.BE-VTSA-44-EN en 1202g...
Page 206 Supply plate with port (1) for supplying compressed air to the 2nd pressure zone Supply plate with port (1) for supplying compressed air to the 1nd pressure zone Fig. 5/17: Example of VTSA... valve terminal with 3 pressure zones 5-38 Festo P.BE-VTSA-44-EN en 1202g...
Page 207: Conversion, Valve Terminal With 2 Pressure Zones, Widths 65 Mm
Exhaust duct 3 Fig. 5/18: Mounting the isolating disc for pressure zone separation (width 65 mm) The supply and exhaust is effected on the left-hand side via the adapter plate and via the right end plate. 5-39 Festo P.BE-VTSA-44-EN en 1202g...
Page 208: Adding Valve Positions, Widths 18 ... 52 Mm
– Cover plate VABB...-WT Tab. 5/5: Valve position extension Note If a manifold sub-base is inserted between existing mani- fold sub-bases, the address assignment of all the valves to the right of the inserted manifold sub-base changes. 5-40 Festo P.BE-VTSA-44-EN en 1202g...
Page 209: Adding Valve Positions, Widths 65 Mm
5.5.7 Adding valve positions, widths 65 mm You can easily adapt the VTSA... valve terminal to the require- ments of your machine or system by adding valve positions. The smallest expansion unit is a manifold sub-base with one valve position. 5-41 Festo P.BE-VTSA-44-EN en 1202g...
Page 210 5.4.7). 2. Mount the corresponding components, such as vertical stacking components, valve or cover plate to the added valve position (mounting vertical stacking components section 5.4.4, mounting the valve or cover plate section 5.4.2). 5-42 Festo P.BE-VTSA-44-EN en 1202g...
Page 211: Adding A Soft-Start Valve
5. Conversion and maintenance 5.5.8 Adding a soft-start valve The procedure for adding a soft-start valve is described in the assembly instructions VABV-S6-1Q-… 5-43 Festo P.BE-VTSA-44-EN en 1202g...
Page 212 5. Conversion and maintenance 5-44 Festo P.BE-VTSA-44-EN en 1202g...
Page 213: A. Technical Appendix
Technical appendix Appendix A Technical appendix Festo P.BE-VTSA-44-EN en 1202g...
Page 214 ........... . A-28 Festo P.BE-VTSA-44-EN en 1202g...
Page 215: A.1 Technical Data
The valves can be operated at temperatures down to -5 °C. In order to prevent the condensate and the humidity from freezing, we recommend that you install a dryer with which condensate and humidity can be removed. Festo P.BE-VTSA-44-EN en 1202g...
Page 216 – Operation +50 °C … – Medium +50 °C Protection class IP 65 per DIN 60 529 (with cable from Festo accessories) Type 4 as per NEMA Relative air humidity 90 % at 40 °C Corrosion protection CRC 0 (per FN940070)
Page 217 General technical data for the VTSA... valve terminal (continued) Note – In the case of wall mounting, additional mountings (angle brackets) must be mounted after every 2 or max. 4 manifold sub-bases, depending on the vibration/shock stress ( Tab. A/5). Festo P.BE-VTSA-44-EN en 1202g...
Page 218 1000 shocks per direction 0.35 mm travel at 10-60 Hz; ±30 g at 11 ms duration, 5 g acceleration at 60-150 Hz 5 shocks per direction Tab. A/4: Values for vibration and shock as per DIN/IEC68 Festo P.BE-VTSA-44-EN en 1202g...
Page 219 1) all widths: a max. of one vertical stacking component per valve position is permissible. 2) Mounting bracket type: VAME-S6-W-M46. 3) Mounting bracket type: VAME-S6-10-W Tab. A/5: Additional mountings for severity level 2 for the VTSA/VTSA-F valve terminal Festo P.BE-VTSA-44-EN en 1202g...
Page 220 Port (1): same pressure as at port (14) – reversible 2x3/2-way valves Port (3) or (5): –0.9 … 10 (ident. code P, Q, R): Port (14): diagram Fig. A/1 Port (12): same pressure as at port (14) Festo P.BE-VTSA-44-EN en 1202g...
Page 221 – all pressure regulators: 0 … 10 Manual override – Width 18 … 52 mm – Non-detenting or turning with detent – 65 mm – Non-detenting Tab. A/6: Medium and pressure range of the VTSA... valve terminal Festo P.BE-VTSA-44-EN en 1202g...
Page 222 Fig. A/1: Required pilot pressure of the external pilot air supply for 2x2/2- and 2x3/2-way valves (ident. code VC, VV, K, H, N, P, Q and R) Note The fittings of the pneumatic ports cause a reduction in the nominal flow rate of the valves. A-10 Festo P.BE-VTSA-44-EN en 1202g...
Page 223 5/2-way valves (M, O, J, D, SO, SQ) 1100 1350 5/3-way mid-position valves – Closed (G) 1000 1350 – Exhausted, pressurized (E, SA, B) 1000 (700) 1350 (700) – Exhausted/pressurized (SB) 700 (700) 700 (700) A-11 Festo P.BE-VTSA-44-EN en 1202g...
Page 224 – pressurised, exhausted (E, B) 3800 (3500) Soft-start valve Pressurisation Exhaust VABF-S6-1-... 3000 3300 1) Ident. code = Identification code 2) Values of the mid-position are indicated in brackets Tab. A/7: Nominal flow rates of valves of type VSVA-B-... A-12 Festo P.BE-VTSA-44-EN en 1202g...
Page 225 1) Measuring method 0 - 10 %, as per FN 942032 Tab. A/8: Valve switching times, valve type VSVA-B-..., widths 18 mm and 26 mm, nom- inal voltage 24 V DC and 110 V AC A-13 Festo P.BE-VTSA-44-EN en 1202g...
Page 226 5/3-way, pressurised 16 / 1) 2) Measuring method 0 - 10 %, as per FN 942032 Tab. A/9: Valve switching times, valve type VSVA-B-..., widths 42 mm and 52 mm, nom- inal voltage 24 V DC A-14 Festo P.BE-VTSA-44-EN en 1202g...
Page 227 Tab. A/10: Valve switching times, valve type VSVA-B-..., widths 42 mm and 52 mm, nom- inal voltage 110 V AC Soft-start valve Switching times [ms] Identifier in the type code VABF-S6-1-P5A4-... Valve Sensor Tab. A/11: Valve switching times, soft-start valve A-15 Festo P.BE-VTSA-44-EN en 1202g...
Page 228 0.5 … 10 bar R7-...-6 ZN, ZNY Reversible A-pressure regulator plate for port (4) 0.5 … 6 bar R7-...-10 Reversible A-pressure regulator plate for port (4) 0.5 … 10 bar Tab. A/12: Pressure ranges of the pressure regulators A-16 Festo P.BE-VTSA-44-EN en 1202g...
Page 229 10 bar P-pressure regulator in width 18 mm Fig. A/3: Diagram: flow rate as a function of the output pressure of the 10 bar P-pressure regulator in widths 18 mm and 26 mm (identifier R1-...-10) A-17 Festo P.BE-VTSA-44-EN en 1202g...
Page 230 P-pressure regu- lator in width 52 mm Flow rate Fig. A/5: Diagram: flow rate as a function of the output pressure of the 6 bar and 10 bar P-pressure regulator in widths 52 mm (identifier R1-...) A-18 Festo P.BE-VTSA-44-EN en 1202g...
Page 231 18 mm Fig. A/7: Diagram: flow rate as a function of the output pressure of the 10 bar A-, B- and AB-pressure regulator in widths 18 mm and 26 mm (identifier R2-...-10, R3-...-10, R4-...-10) A-19 Festo P.BE-VTSA-44-EN en 1202g...
Page 232 Flow rate Fig. A/9: Diagram: flow rate as a function of the output pressure of the 6 bar and 10 bar A-, B- and AB-pressure regulator in widths 52 mm (identifier R2-..., R3-... and R4-...) A-20 Festo P.BE-VTSA-44-EN en 1202g...
Page 233 18 mm Fig. A/11: Diagram: flow rate as a function of the output pressure for the reversible 10 bar A-, B- and AB-pressure regulator in widths 18 mm and 26 mm (identifier R7-...-10, R6-...-10 and R5-...-10) A-21 Festo P.BE-VTSA-44-EN en 1202g...
Page 234 Flow rate Fig. A/13: Diagram: flow rate as a function of the output pressure of the reversible 6 bar and 10 bar A-, B- and AB-pressure regulator in width 52 mm (identifier R7-..., R6-... and R5-...) A-22 Festo P.BE-VTSA-44-EN en 1202g...
Page 235 4 to 5 Rotations of the adjusting screw Fig. A/15: Diagram: flow rate as a function of flow control, width 42 mm (flow control plate identifier F1B1) A-23 Festo P.BE-VTSA-44-EN en 1202g...
Page 236 F1B1) Flow Characteristic curve of flow con- trol plate Rotations of the adjusting screw Fig. A/17: Diagram: flow rate as a function of flow control, width 65 mm (flow control plate type GRO-ZP-3) A-24 Festo P.BE-VTSA-44-EN en 1202g...
Page 237 2) The maximum length of the signal cable for VTSA... valve terminals with a CPX terminal is 30 m Tab. A/13: Technical data for the electric components A-25 Festo P.BE-VTSA-44-EN en 1202g...
Page 238 – The maximum number of controllable solenoid coils is limited to 32 addresses for VTSA... valve terminals with a CPX terminal. – The maximum number of controllable solenoid coils is limited to 26 addresses for VTSA... valve terminals with FB21 (type 03). A-26 Festo P.BE-VTSA-44-EN en 1202g...
Page 239 2) Manifold sub-base with one valve position (width 42 mm and 52 mm) 3) Note: 7 manifold sub-bases are not possible, as valve position 14 would not be addressable (address 27 and 28). There are 26 addresses available. Tab. A/14: Maximum number of possible manifold sub-bases A-27 Festo P.BE-VTSA-44-EN en 1202g...
Page 240: A.2 Accessories
A. Technical appendix Accessories Accessories www.festo.com\catalogue A-28 Festo P.BE-VTSA-44-EN en 1202g...
Page 241 Supplementary overview of components Appendix B Supplementary overview of components Festo P.BE-VTSA-44-EN en 1202g...
Page 242 ..........B-15 Festo P.BE-VTSA-44-EN en 1202g...
Page 243 – Dominant at control side 14 Ident. code: M Function: – One monostable 5/2-way valve – Pneumatic spring return NOTE: The number of addresses assigned to this valve depend on the type of manifold sub-base section 3.4). Festo P.BE-VTSA-44-EN en 1202g...
Page 244: B. Supplementary Overview Of Components
– Valve with ident. code: SQ: Switching position sensing via inductive sensor with NPN output NOTE: The number of addresses assigned to this valve depend on the type of manifold sub-base section 3.4). Tab. B/1: 5/2-way valves Festo P.BE-VTSA-44-EN en 1202g...
Page 245 – 5/3-way valve – Normally open 12/14 (14) Ident. code: SB (12) Function: – 5/3-way valve – Normally open from 1 > 2 12/14 (14) – Switching position 14 with memory function Tab. B/2: 5/3-way mid-position valves Festo P.BE-VTSA-44-EN en 1202g...
Page 246 – on control side 12, one monostable 3/2-way valve (normally open) 12/14 – Pneumatic spring return (14) Ident. code: N Function: (14) (12) – Two monostable 3/2-way valves – normally open – Pneumatic spring return 12/14 (14) Tab. B/3: 2x3/2-way valves Festo P.BE-VTSA-44-EN en 1202g...
Page 247 – On control side 14, one reversible monostable 3/2-way valve (normally closed) – On control side 12, one reversible monostable 3/2-way valve (normally open) 33/55 110/114 (12) – Pneumatic spring return (14) Tab. B/4: Reversible 2x3/2-way valves Festo P.BE-VTSA-44-EN en 1202g...
Page 248 1) Note: The 2/2-way valves with ident. code VV are to be operated in a separate pressure zone with separate exhaust ducts (3) and (5) if the VTSA/VTSA-F valve terminal is equipped with other valve functions. Tab. B/5: 2x2/2-way valve Festo P.BE-VTSA-44-EN en 1202g...
Page 249 – with external pilot air supply (ident. code PM) 114/ Versions: 12 (11) – Sensor with NPN output – with internal pilot air supply (ident. code PO) – with external pilot air supply (ident. code PK) Tab. B/6: Soft-start valves Festo P.BE-VTSA-44-EN en 1202g...
Page 250 N, K) is not permitted. Reversible 2x3/2-way valves (ident. code: P, Q, R) do not need a separate pressure zone in com- bination with these pressure regulators. Tab. B/7: Pressure regulator plates for regulating outputs (2) and (4) B-10 Festo P.BE-VTSA-44-EN en 1202g...
Page 251 – Restricts the exhaust air after the valve in ducts (3) and (5). Note: On reversibly operated valve terminals, the sup- ply air in ducts (3) and (5) is restricted in front of the valve. Tab. B/8: Flow control plate B-11 Festo P.BE-VTSA-44-EN en 1202g...
Page 252 Function: – Plate for branching of the pilot air (14) from duct (1) – 5/2-way valve (preferably with sensor) for switching the pilot air Tab. B/9: Vertical pressure supply plate and vertical pressure shut-off plate B-12 Festo P.BE-VTSA-44-EN en 1202g...
Page 253 – Control block with ident. code: SP: Switching position sensing via inductive sensor with PNP output – Control block with ident. code: SN: Switching position sensing via inductive sensor with NPN output Tab. B/10: Control block B-13 Festo P.BE-VTSA-44-EN en 1202g...
Page 254 B. Supplementary overview of components Pilot air Identifier VABF-S4-…-S Function: Module for switching the pilot air from – duct 1 to 14. – mechanical spring return – Switching position query via inductive sensor with PNP output Tab. B/11: B-14 Festo P.BE-VTSA-44-EN en 1202g...
Page 255 2. Slacken the fittings between the pneumatic interface and manifold sub-base or pneumatic supply plate of the VTSA… valve terminal in a crosswise direction (position of the fittings Fig. B/2). 3. Then loosen the fittings. B-15 Festo P.BE-VTSA-44-EN en 1202g...
Page 256 CPX system description. Mounting Proceed as follows: 1. Make sure the seals are not damaged. Replace the seals if they are damaged. 2. Place the seal onto the guide pins of the pneumatic inter- face. B-16 Festo P.BE-VTSA-44-EN en 1202g...
Page 257 Fig. B/3: Mounting the VTSA... valve terminal to the pneumatic interface 3. Push the pneumatic interface together with the pneumatic manifold sub-bases, or the pneumatic supply plate. Make sure that the seal and the components are correctly posi- tioned. B-17 Festo P.BE-VTSA-44-EN en 1202g...
Page 258 CPX system description for the electric compon- ents of the VTSA valve terminal with CPX terminal – in the section on electric components for VTSA valve terminal with FB 21 in the FB 21 (type 03) electronics description B-18 Festo P.BE-VTSA-44-EN en 1202g...
Page 259 Index Appendix C Index Festo P.BE-VTSA-44-EN en 1202g...
Page 260: C. Index
............Festo P.BE-VTSA-44-EN en 1202g...
Page 261 ........5-11 Cover plate for vacant valve position, dismantling/mounting ..... . 5-9, 5-11 Festo P.BE-VTSA-44-EN en 1202g...
Page 262 ........mounting/dismounting ......Festo P.BE-VTSA-44-EN en 1202g...
Page 263 Wall mounting ........Festo P.BE-VTSA-44-EN en 1202g...
Page 264 ......3-19 Types of pilot control ... . 1-13, 1-36, 3-13, 3-19 Festo P.BE-VTSA-44-EN en 1202g...
Page 265 ......Supply, Main and additional supply ....Supply plate (pneumatic), dismantling/mounting 5-19, 5-23 Festo P.BE-VTSA-44-EN en 1202g...
Page 266 ........Festo P.BE-VTSA-44-EN en 1202g...
Page 267 ......... Festo P.BE-VTSA-44-EN en 1202g...
