JOINT FORMATION

Before using this tool, read its Operation and Safety Instructions contained in this manual.
This tool is a double notch type sealer. Each
joint must be inspected to make certain it has
four (4) good notches. A properly formed
joint will appear as shown in the illustration.
If the joint does not appear as shown, then
the operator must proceed as follows:
1. Make certain that the tool's operating instructions are being followed before applying
another strap.
2. Cut the strap off and apply a new strap and seal.
3. An improperly formed seal which does not have four (4) good notches, could result in
strap separation. Before moving any package be certain that the seal is formed as shown.
Inspect the joint to make certain it appears as shown in the illustration. If not, remove the
strap and check the tool for worn or broken parts. Repair the tool before applying another
strap.
NEVER HANDLE OR SHIP ANY LOAD WITH IMPROPERLY FORMED JOINTS. Misformed
joints may not secure the load and could cause serious injury. Follow the joint inspection
procedures in each sealers's manual.
7
