TOOL OPTIONS

The following options are available for the AM tools as noted.
SKID HOOK WITH ADAPTER
All AM tools can be equipped to hang off the side of a load to apply vertical straps. This option
frees the operator to use the tool with both hands. The hook can be ordered in varying lengths to
place the final strap joint as close as possible to the center of the load.
DESCRIPTION PART NO.
Skid hook, 8" 005228
Skid hook, 11" 005195
Skid Hook, 15" 005230
Adapter 005595
AM-3431 CONVERSION, Kit No. 306815
The AM-34 tool can be converted to use 3/4" (19mm) Magnus strap up to .031" (.78mm) thick. AM-
34 tools converted to AM-3431 continue to use 34AMP type seals.
When using 3/4 x .031 (19 x 0.79mm) strapping, tool conversion kit, part #306815, must be
installed. Failure to install this kit could result in poor performance, component failure or an
improperly formed seal which does not have four (4) good notches.
The conversion kit contains the following components which are to be substituted for existing
components:
KEY QTY PART NO.
78 2 306814
95 1 015767
98 1 286369
DESCRIPTION
Jaw
Sealer handle
AM-3431 Nameplate
17
