GEIGER GJ56 E14-1002 Series Original Assembly And Operating Instructions

Hide thumbs Also See for GJ56 E14-1002 Series:

Advertisement

Quick Links

Venetian blind motor:
GEIGER GJ56.. E14-1002 with electronic end stop
for Venetian blinds, exterior blinds and terrace shading
Original-Montage- und
DE
Betriebsanleitung
Original assembly and
EN
operating instructions
Notice originale de montage
FR
et d'utilisation
Instrucciones originales de
ES
instalación y funcionamiento
Istruzioni originali di installazione
IT
e funzionamento
Návod na montáž
CZ
a obsluhu
Originele montage- en
NL
bedrijfshandleiding
www.geiger.de
EN
1
EN

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GJ56 E14-1002 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for GEIGER GJ56 E14-1002 Series

  • Page 1 Venetian blind motor: GEIGER GJ56.. E14-1002 with electronic end stop for Venetian blinds, exterior blinds and terrace shading Original-Montage- und Betriebsanleitung Original assembly and operating instructions Notice originale de montage et d’utilisation Instrucciones originales de instalación y funcionamiento Istruzioni originali di installazione e funzionamento Návod na montáž...
  • Page 2 1. General information Dear customer, By purchasing a GEIGER motor you have decided on a quality product from GEIGER. Thank you very much for your decision and the confidence placed in us. Before you put this drive into operation please observe the following safety instructions. It serves for the prevention of danger and for the avoidance of personal injury and damage to property.
  • Page 3 The height of installation must be at least 1.5 m above the floor. f Permanently installed control devices must be attached visibly. f In case of devices extending horizontally, a horizontal distance of at least 0.4 m must be respected between the fully extended part and any other fixed element. www.geiger.de...
  • Page 4 A plug for the disconnection of the motor from the power supply must be accessible after installation. f Damaged connecting cables must be replaced by GEIGER connecting cables of the same type. f The device must be mounted as described in the installation instructions. Fixations shall not be made with adhesives since they are regarded as unreliable.
  • Page 5 UP/DOWN command. In this case, the UP/DOWN keys must be activated simultaneously instead of the programming key. Article number / GEIGER setting switch M56F152 with service terminal (D), 5 wires, SMI compatible...
  • Page 6 After an obstacle detection (e.g. obstacle or blind frozen to the window sill), the direction in which the obstacle was detected is blocked. A short command in the opposite direction releases the driving direction. Gerhard Geiger GmbH & Co. KG | 100W1583 V000 0323...
  • Page 7 Storage temperature T = -15°C .. +70°C Subject to technical modifications. Please find information to the ambient temperature range of our GEIGER motors under www.geiger.de 16. Notes on waste disposal Recycling of packaging materials In the interest of environmental protection, please contact your local government’s recycling or solid waste management department to learn more about the services it provides.
  • Page 8 Gerhard Geiger GmbH & Co. KG Schleifmühle 6 | D-74321 Bietigheim-Bissingen Phone +49 (0) 7142 9380 | Fax +49 (0) 7142 938 230 | info@geiger.de | www.geiger.de Sitz Bietigheim-Bissingen | Amtsgericht Stuttgart HRA 300591 | USt-IdNr. DE145002146 Komplementär: Geiger Verwaltungs-GmbH | Sitz Bietigheim-Bissingen | Amtsgericht Stuttgart HRB 300481 Geschäftsführer: Roland Kraus | WEEE-Reg.-Nr.
