Spectrum Digital TMS320DM6437 Technical Reference page 52

Spectrum Digital, Inc
Test Point
#
TP1
TP2
TP6
TP7
TP8
TP10
TP12
TP13
TP14
TP15
TP16
TP17
TP18
TP19
TP20
TP21
TP25
TP26
Input1
TP4
TP22
TP33
TP37
TP42
TP47
TP48
TP52
TP54
3-26
Table 23: DM6437 EVM Test Points
Signal
RESETOUTn
RSV4
RSV5
GND
GND
GND
Ethernet PHY Interrupt Pin
CAN Driver Output B_CANH
CAN Driver Output B_CANL
Codec MFP2 Pin
Codec MPF3 Pin
Codec GPIO1 Pin
Codec GPIO2 Pin
VIDEO DECODER AVID/GPIO Pin
VIDEO DECODER INTREQ Pin
CORE_PWR_OK
GND
GND
Table 24: Power Pair Test Points
Power Pairs
Power Domain
Input2
TP5
TP23 DSP_CORE_VDD
TP34
TP38
TP43
TP46
TP49
TP53
TP55
Test Point
#
TP27
TP28
TP29
TP30
TP31
TP32
TP36
TP40
TP41
TP52
TP53
TP58 VIDEO DECODER GLCO/I2C Pin
TP59
TP61
TP64
TP69
TP70
Resistance Between
DDR_VDDL
0.025 ohms
VCC_3V3 0.025 ohms
VCC_1V8 0.025 ohms
DVD_3V3 0.025 ohms
DVDD_1V8 0.025 ohms
PLLPWR18
VDDA_1P1V
VDDA_1P8V
DM6437 EVM Technical Reference
Signal
GND
GND
GND
GND
VCC_5V
3V3_PWR_OK
1V8_PWR_OK
DM6437 I2CCLK
DM6437 I2CDATA
VDD_1P1V
VDD_1P1V
VIC INPUT CLOCK
DM6437 HECC_RX
DM6437 HECC_TX
DM6437 PWM1
DM6437CLK_OUT
Inputs
0.1 ohms
0.1 ohms
0.1 ohms
0.1 ohms
