3.2.11 P2, Video In

Connector P2 is a four pin mini din S-video connector which interfaces to the
TVP5146M2 encoder. This connector brings in a video signal (LUMA) to pin 9 on the
TVP5146M2. Do NOT plug into this connector with the power on. The figure below
shows this connector as viewed from the card edge.
3.2.12 P3, Ethernet Interface
The P3 connector is used to provide an 10/100 Mbps Ethernet interface. This is a
standard RJ-45 connector. The pinout for the P3 connector is shown in the table below.
Two LEDs are embedded into the connector to report link status.
3-10
Pin 3
Pin 1
Figure 3-10, P2,Front View, Mini Din Connector
Table 7: J11, Video In, Mini Din Connector
Pin #
1
2
3
4
Table 8: P3, Ethernet Interface
Pin # Signal
1 LXT_TDP
3 LXT_RDP
5 NC
7 NC
Table 9: Ethernet LEDs
LED #
LED1
LED2
Pin 4
Pin 2
Signal Name
GND
GND
LUMA
Chroma
Pin # Signal
2 LXT_TDM
4 LXT_TDCT
6 LXT_RDM
8 GND
Color
Green
Yellow
