Spectrum Digital TMS320DM6437 Technical Reference page 27

This chapter describes the physical layout of the DM6437 EVM and its
interfaces.
Topic
3.1 Board Layout
3.2 Connectors
3.2.1 J1, DAC A Video Out
3.2.2 J2, DAC B Video Out
3.2.3 J3, DAC C Video Out
3.2.4 J4, DAC D Video Out
3.2.5 J5, Video In
3.2.6 J10, S/PDIF Out
3.2.7 J16, +5V Input
3.2.8 J20, Mini PCI Interface
3.2.9 J501, Embedded Mini USB Emulation Interface
3.2.10 P1, Video Out
3.2.11 P2, Video In
3.2.12 P3, Ethernet Interface
3.2.13 P4, PCI Connector
3.2.14 P7, CAN Connector
3.2.15 P8, RS-232 UART
3.2.16 P10, Stereo Line In
3.2.17 P11, Microphone In
3.2.18 P12, Headphone Out
3.2.19 P13, Stereo Line Out
3.2.20 P14, S/PDIF Out (Optical)
3.2.21 DC_P1, Memory/Video Expansion
3.2.22 DC_P2, Peripheral Expansion
3.2.23 DC_P3, VLYNQ Connector
Physical Description
Chapter 3
Page
3-3
3-4
3-5
3-5
3-5
3-6
3-6
3-7
3-7
3-8
3-9
3-9
3-10
3-10
3-11
3-13
3-15
3-15
3-15
3-15
3-16
3-16
3-17
3-18
3-19
3-1
