3.2.23 DC_P3, VLYNQ Connector

The DC_P3 connector allows the user to connect the VLYNQ interface to other logic.
The pinout for the DC_P3 connector is shown in the table below.
Pin #
1 HD00_VLYNQ_SCRUN_GP[58]
3
5 HD01_VLYNQ_RXD0_GP[59]
7 HD02_VLYNQ_RXD1_GP[60]
9
11
13 HD03_VLYNQ_RXD2_GP[61]
15 HD04_VLYNQ_RXD3_GP[62]
17
19
3.3 Jumpers
The DM6437 EVM has four (4) jumpers which are used to make certain logic or feature
determinations on the board. The function of each jumper is described in the table
below.
* Not populated
Table 16: DC_P3, VLYNQ Header
Signal Conn
GROUND
GROUND
VCC_3V3
GROUND
VCC_5V
Table 17: Jumpers
Jumper #
JP1 NTSC/PAL Select
JP2
JP3 *
JP4 * Power Up Reset
Pin #
2 VLYNQ_CLOCK_GP[57]
4
6 HD05_VLYNQ_TXD0_GP[63]
8 HD06_VLYNQ_TXD1_GP[64]
10
12 DC_P3_VLYNQ_RESETn
14 HD07_VLYNQ_TXD2_GP[65]
16 HD08_VLYNQ_TXD3_GP[66]
18
20
Function Size
1x3
CS2 Select 2x4
Reset 1x2
1x2
Spectrum Digital, Inc
Signal Conn
GROUND
GROUND
GROUND
VCC_5V
3-19
