3.2 Connectors

The EVM has twenty three (23) connectors providing interfaces to various peripherals.
These connectors are described in the following sections.
* Not populated
3-4
Table 1: Connectors
Connector Size
J1 RCA
J2 RCA
J3 RCA
J4 RCA
J5 RCA
J6 14
J10 RCA
J16 2.5 mm
J20 2 x 62
J501 Mini USB
P1 4 Pin DIN
P2 4 Pin DIN
P3 RJ-45
P4 PCI
P7 9 Pin D-sub
P8 9 Pin D-sub
P10 3.5 mm
P11 3.5 mm
P12 3.5 mm
P13 3.5 mm
P14 Optical
DC_P1 2x50
DC_P2 2x45
DC_P3 2x10
Function
DAC A *
DAC B
DAC C
DAC D
Video In
External
Emulation Header
S/PDIF Out
+5V In
Mini PCI Interface
Embedded USB
Emulation Interface
S-Video Out
S-Video In
Ethernet
PCI
CAN
RS-232 UART
Stereo Line In
Microphone In
Headphone Out
Stereo Line Out
S/PDIF Out
Expansion
Expansion
Expansion
