Retransfer Series Printers
Multi-Hopper Printer (cont.)
6. Peel off the center strips on both sides of the adhesive cleaning card.
Leave the side strips in place.
Peel Off Center
Strips Only
7. Load the adhesive cleaning card in the H2 cartridge and close the
cartridge door (g).
If the cleaning card appears
bowed, insert it as shown.
Card Without Bow
Card With Bow
Do not insert the adhesive cleaning card in the exception
slide of the multi-hopper.
8. Lock the multi-hopper.
d. Rotate the center lock bar to the right to the lock position.
e. Slide the lock bar release button to the right to lock the lock bars
into place.
f. Lock the multi-hopper door lock.
9. Continue with "Run the Adhesive Cleaning Card" on page
12
g
13.
527983-001_B

Run the Adhesive Cleaning Card

1. Use the LCD panel to run the adhesive cleaning card.
1
2
3
4
5
When the cleaning cycle completes, the adhesive cleaning card is
ejected into the printer reject tray (RT1).
2. Continue with "Prepare the Printer for Use After Cleaning" on
page 14.
527983-001_B
Cleaning Guide
6
7
If you are cleaning a single-
hopper printer, the following
message displays.
8
OR
If you are cleaning a
multi-hopper printer, the
following message displays.
8
