Retransfer Series Printers

Use the Adhesive Cleaning Card

Use the adhesive cleaning card to remove particles that result from the
retransfer process. Refer to "Additional Cleaning Tasks" on page 5
information about when to use the adhesive cleaning card.

Single-Hopper Printer

1. Remove the ink ribbon and retransfer film cartridges. Refer to
You Begin" on page 6.
2. Unlock and open the input hopper.
3. Remove the unprinted cards. Handle the
cards by the edges or wear card inspection
gloves.
4. Peel off the center strips on both sides of the adhesive cleaning card.
Leave the side strips in place.
Peel Off Center
Strips Only
5. Load the adhesive cleaning card in the input hopper.
If the cleaning card appears
bowed, insert it as shown.
Card Without Bow
Card With Bow
6. Close and lock the input hopper.
7. Continue with "Run the Adhesive Cleaning Card" on page
10
Multi-Hopper Printer
1. Remove the ink ribbon and retransfer film cartridges. Refer to
You Begin" on page
for
2. Unlock the multi-hopper.
a. Unlock the multi-hopper door lock (a).
"Before
b. Slide the lock bar release button (B1)
c. Rotate the center lock bar to the left
3. Press the cartridge release button at the top of the H2 cartridge and
open the cartridge door (d).
4. Lift the card weight to the top of the cartridge and gently pull it
forward until it locks in position (e).
5. Remove the unprinted cards from the H2 cartridge (f). Handle the
cards by the edges or wear card inspection gloves.
13.
527983-001_B 527983-001_B
6.
to the left to release the hopper lock
bars (b).
to provide access to the H2 and H5
multi-hopper input cartridges (c).
f
Cleaning Guide
"Before
a
b
c
e
d
11
