ZiLOG eZ80F91 Quick Start Manual page 4

eZ80F91 Modular Development Kit
<ZDS II Installation Directory>\device drivers\USB
<ZDS II Installation CD>\Device Drivers\USB
The Windows Security dialog box is displayed.
6. Select Install this driver software anyway.
7. When the software has been installed, click Closed.
For Windows XP
1. Connect the USB Smart Cable to the host PC. The Found New Hardware Wizard
should activate automatically.
2. In the Wizard, select Install from a list or specific location (Advanced); then click
Next.
Note: If the Windows Logo testing dialog appears, select Continue Anyway.
3. Select Search for the best driver in these locations and Include this location in
search.
4. Browse to one of the following driver directory:
<ZDS II Installation Directory>\device drivers\USB
<ZDS II Installation CD>\Device Drivers\USB
5. Click Next to locate the appropriate driver.
6. Click Next and then Click Finish to complete the installation.
For Windows 2000
1. Connect the USB Smart Cable to the host PC for the first time.
The Found New Hardware Wizard should activate automatically.
2. In the Wizard, click Next.
3. Select Search for a suitable driver for my device (Recommended); then click Next.
4. Select Specify a location; then click Next.
5. Browse to the driver directory, one of the following:
<ZDS II Installation Directory>\device drivers\USB
<ZDS II Installation CD>\Device Drivers\USB
6. Click OK, and then click Next after the appropriate driver is found.
7. Click Finish to complete the installation.
QS004609-0707 Page 4 of 10
