7. Close cutterbar doors (A).

Removing Large Driven Drums and Driveline

DANGER
To avoid bodily injury or death from unexpected start-up or fall of a raised machine, stop engine, remove key, and
engage windrower lift cylinder safety props before going under machine for any reason.
WARNING
Exercise caution when working around the blades. Blades are sharp and can cause serious injury. Wear gloves when
handling blades.
NOTE:
Illustrations show the left drum and driveline.
1. Open cutterbar doors (A). Refer to
Doors – North America, page 64
215009
MAINTENANCE AND SERVICING
3.7.1 Opening Cutterbar
for instructions.
136
A
Figure 4.76: Cutterbars
A
Figure 4.77: Cutterbar Doors
Revision A
