5700-E Neutralizer Installation & Start-Up Guide
Thank you for purchasing a Clean Water System! With proper installation and a little
routine maintenance your system will be providing neutral pH water for many years.
Please review this start‐up guide entirely before beginning to install your system, and
follow the steps outlined for best results.
CALCITE MEDIA CONTAINS DUST. USE PAPER MASK AND VENTILATE TO AVOID BREATHING
DUST.
Questions?
Call us toll-free: 1-888-600-5426 or 1-831-462-8500
Email us:
support@cleanwaterstore.com
See more information on our website:
Clean Water Made Easy
www.cleanwaterstore.com/resources
www.cleanwaterstore.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 5700-E and is the answer not in the manual?

Questions and answers

Related Manuals for Clean Water Systems 5700-E

Summary of Contents for Clean Water Systems 5700-E

  • Page 1 Clean Water Made Easy www.cleanwaterstore.com 5700-E Neutralizer Installation & Start-Up Guide Thank you for purchasing a Clean Water System! With proper installation and a little routine maintenance your system will be providing neutral pH water for many years. Please review this start‐up guide entirely before beginning to install your system, and follow the steps outlined for best results.

  • Page 2: Table Of Contents

    Fig 1 - Neutralizer Filter Tank Water Flow .................... 5 Fig 2 - Typical Neutralizer 5700-E piping installation with ball valve and hose bib after the filter .... 6 Fig 3: 5700-E from the rear showing the inlet (left) and outlet (right) end-connector fittings 3/4” or 1”...

  • Page 3: Packing List

    5700-E Neutralizer Installation & Startup Guide Packing List Neutralizer 1.0 cubic foot size 5700-E Backwash Control Valve w/ Bypass Assembly and Pipe connector kit (1”or ¾”) 10” x 44” filter tank with distributor tube Blue media funnel for adding the Calcite media 12lbs.

  • Page 4: Pre-Installation

    1. See typical installation on page 7 (Fig 2). The Neutralizer is installed after the pressure tank. 2. Make sure to connect the IN pipe to the 5700-E inlet and the OUT pipe to the outlet (see Fig 3). As you face the 5700-E control from the front, the water enters on the right and exits on the left.

  • Page 5: How Your Neutralizer Works

    7. The drain line tubing (not supplied) is connected to a drain from the drain outlet using flexible ½” ID tubing. Note that the drain can run up above the 5700-E control and into a drain, it does not have to drain down, as the filter backwashes under line pressure from your well pump. Most plumbing codes require an air-gap connection, so that if your sewer or septic tank backs up, it cannot cross connect with the drain tubing.

  • Page 6: Fig 2 - Typical Neutralizer 5700-E Piping Installation With Ball Valve And Hose Bib After The Filter

    5700-E Neutralizer Installation & Startup Guide Fig 2 - Typical Neutralizer 5700-E piping installation with ball valve and hose bib after the filter Page 6 www.cleanwaterstore.com Rev 120215...

  • Page 7: Npt In Noryl Plastic. Brass End-Connectors Are Also Available For Connecting To Copper Tubing

    5700-E Neutralizer Installation & Startup Guide Fig 3: 5700-E from the rear showing the inlet (left) and outlet (right) end- connector fittings 3/4” or 1” NPT in Noryl plastic. Brass end-connectors are also available for connecting to copper tubing. Fig 4 5700-E Bypass/Service Mode Knob Positions Page 7 www.cleanwaterstore.com...

  • Page 8: Assembly And Installation Instructions

    Assembly and Installation Instructions 1. By hand, unscrew the entire 5700-E control valve from the top of the tank if it was shipped screwed on. Place distributor tube in tank if not already inside. If not already done, make sure the blue cap is on top of distributor tube, or wrap the top of distributor tube with electrical or duct tape.

  • Page 9: Fig 5 5700-E Bypass And Service Mode Positions

    It is OK to run the drain line up and over the 5700-E Neutralizer up to 4 feet above the top of the tank. If the drain line will be more than 20 feet, use larger diameter tubing such as ¾”...

  • Page 10: Programming Instructions

    5700-E Neutralizer Installation & Startup Guide 14. Plug your 5700-E control valve into an outlet. After being plugged in, the screen may display “WAITING PLEASE” while it finds the service position. By default, the control valve will be set to work like a Water Softener, but that’s not correct for this application.
  • Page 11 5700-E Neutralizer Installation & Startup Guide The advanced menus should have already been programmed for you, but it is a good idea to verify the programming before you put the filter into service. To enter the advanced menus, press both the Gear and Regen button at the same time. All mode types will be flashing.

  • Page 12: Starting The Initial Backwash

    5700-E Neutralizer Installation & Startup Guide Starting the Initial Backwash 1. Now you can start the initial manual backwash. Press and hold the Regen button (Button with 3 arrows) until BW flashes and the number of minutes that you programmed (10 is default) will display.

  • Page 13: How To Add Calcite Media To The 5700-E Neutralizer Filter

    6. Put the top fill plug back in. You can lubricate the threads with some vegetable oil or silicone grease, but do not use Teflon tape or plumbing grease. 7. Plug the control valve back in and press the Regen button so the 5700-E control is in a backwash cycle.

  • Page 14: How To Mix And Use Calcite Blends

    5700-E Neutralizer Installation & Startup Guide For most residential well applications, a 90% Calcite and 10% Corosex is best. However, in some cases an 80%/20% mix or even a 70%/30% is used. It is always better to start with a 90%/10% mix at first as this solves the majority of low pH problems in the range of 4.5 to 5.9.

  • Page 15: Maintenance

    5700-E Neutralizer Installation & Startup Guide Maintenance Immediate Regeneration Starting an While in service position, hold the Regen button in for 5-6 second to initiate an immediate regeneration. Pressing the Regen button again will jump to the next cycle phase. Holding the two arrow buttons together will terminate Immediate Regeneration and return the unit to service position.

  • Page 16: White Spots On Fixtures And Glasses

    Neutralizer filter is a drop in water pressure, due to fouling of the media from rust or sediment. You can verify the backwash flow rate by running the drain line into a bucket and timing it when the 5700-E is in backwash.

  • Page 17: Changing Or Adjusting The Drain Line Fitting

    5700-E Neutralizer Installation & Startup Guide Changing or Adjusting the Drain Line Fitting Step 1: Begin by shutting off the water before the system. Depressurize it by opening a faucet after the system or in the house, then close the faucet after there is no more water coming out. Now the pressure has been relieved from the system, however some water will come out as you do the following steps.
  • Page 18 5700-E Neutralizer Installation & Startup Guide How To Remove Media From Control Head Sometimes, when doing the Initial Backwash, the media gets lifted up into the control head. You can tell this happened because you will have little or no flow, either going out to drain while in the backwash positon, or when in the service positon.

Table of Contents
