Table 49 provides an example for the WB Receiver. The table is broken into three columns. The first column lists
the action taking place: command (CMD), argument (ARG), status (STATUS) or response (RESP). For
SET_PROPERTY commands, the property (PROP) and property data (PROPD) are indicated. The second column
lists the data byte or bytes in hexadecimal that are being sent or received. An arrow preceding the data indicates
data being sent from the device to the system controller. The third column describes the action.
Note that in some cases the default properties may be acceptable and no modification is necessary. Refer to
Section "5. Commands and Properties" for a full description of each command and property.
Table 49. Programming Example for the WB/SAME Receiver
Action
CMD
ARG1
ARG2
STATUS
CMD
STATUS
RESP1
RESP2
RESP3
RESP4
RESP5
RESP6
RESP7
RESP8
CMD
ARG1
ARG2 (PROP)
ARG3 (PROP)
ARG4 (PROPD)
ARG5 (PROPD)
STATUS
CMD
ARG1
ARG2 (PROP)
ARG3 (PROP)
ARG4 (PROPD)
ARG5 (PROPD)
STATUS
CMD
ARG1
ARG2 (PROP)
ARG3 (PROP)
ARG4 (PROPD)
ARG5 (PROPD)
STATUS
Data
0x01 POWER_UP
0xC3 Set to weatherband receive. Enable interrupts.
0x05 Set to Analog Out.
→0x80 Reply Status. Clear-to-send high.
0x10 GET_REV
→ 0x80 Reply Status. Clear-to-send high.
→ 0x25 Part Number, HEX (0x25 = 37 dec. = Si4737)
→ 0x30 Firmware Major Rev, ASCII (0x30 = 0)
→ 0x41 Firmware Minor Rev, ASCII (0x41 = A)
→ 0x13 Patch ID MSB, example only
→ 0x36 Patch ID LSB, example only
→ 0x30 Component Firmware Major Rev, ASCII (0x30 = 0)
→ 0x41 Component Firmware Minor Rev, ASCII (0x41 = A)
→ 0x42 Chip Rev, ASCII (0x42 = revB)
0x12 SET_PROPERTY
0x00
0x00 GPO_IEN
0x01
0x00 Set STCIEN, ERRIEN, CTSIEN, ASQIEN, SAMEIEN
0xC7
→ 0x80 Reply Status. Clear-to-send high.
0x12 SET_PROPERTY
0x00
0x02 REFCLK_FREQ
0x01
0x80 REFCLK = 32768 Hz
0x00
→ 0x80 Reply Status. Clear-to-send high.
0x12 SET_PROPERTY
0x00
0x02 REFCLK_PRESCALE
0x02
0x00 Divide by 1
0x01
→ 0x80 Reply Status. Clear-to-send high.
