Command 0x14. GET _ INT _ STATUS
Updates bits 6:0 of the status byte. This command should be called after any command that sets the STCINT,
RSQINT, SAMEINT (Si4707 only), or ASQINT bits. When polling this command should be periodically called to
monitor the status byte, and when using interrupts, this command should be called after the interrupt is set to
updated the status byte. The CTS bit (and optional interrupt) is set when it is safe to send the next command. This
command may only be sent when in powerup mode.
Command arguments: None
Response bytes: One
Command
Bit D7
CMD
Response
Bit D7
STATUS CTS
D6 D5
ERR X
0 0
Name
Always returns 0.
[7:0] Property Value High Byte.
H
This byte in combination with PROPV
property value.
[7:0] Property Value High Byte.
L
This byte in combination with PROPV
property value.
D6 D5
0 0 0
D6 D5
ERR X
