All Wine Storage – Model I430 - Sub-Zero Manual

O V E R A L L D I M E N S I O N S
All Wine Storage – Model I430
762 mm
719 mm
DOOR FRAME
2134
mm
273
mm
FRONT VIEW
*
13 mm ADJUSTMENT IN LEVELING LEGS
I N S T A L L A T I O N S P E C I F I C A T I O N S
All Wine Storage – Model I430
Dimensions are for finished rough openings.
Door swing clearances are based on
stainless steel door and handle dimensions.
90˚
765 mm
838 mm
DOOR CLEARANCE
606 mm
1724
mm
DOOR
FRAME
105
TOE
mm
KICK SIDE VIEW
606 mm
BEHIND
FRAME
130˚
MAXIMUM
DOOR SWING
765 mm
ROUGH OPENING
1270 mm
DOOR CLEARANCE
610 mm
ROUGH
OPENING
DEPTH
TOP VIEW
ANTI-TIP BLOCK
178
mm
LOCATE ELECTRICAL
WITHIN SHADED AREA
2127 mm 749 mm
ROUGH OPENING WIDTH
HEIGHT
TO FINISHED
FLOORING WITH
STANDARD
279 mm GRILLE
2108 mm
MIN HEIGHT
REQUIRED
(LEVELERS IN)
FRONT VIEW
A L L W I N E
S T O R A G E
Model I430
Built-In
O V E R A L L
D I M E N S I O N S
Model I430
Width
Height 2134 mm
Depth
Note the location of
pre-drilled holes for
optional handle
hardware.
I N S T A L L A T I O N
Refer to the
installation instruc-
tions shipped with
each Sub-Zero
product for detailed
specifications.
E
152
mm
1918 mm
762 mm
610 mm
53
