O V E R A L L D I M E N S I O N S

Undercounter Wine Storage

606 mm
597 mm
DOOR FRAME
273 mm
864
CENTERED
mm*
VERTICALLY
FRONT VIEW
13 mm + _ ADJUSTMENT IN LEVELING LEGS
*
M O D E L I 4 2 4
Built-In
Width 606 mm
Height 864 mm
Depth 610 mm
Note the location of pre-drilled
holes for optional handle hardware.
I N S T A L L A T I O N S P E C I F I C A T I O N S
Undercounter Models
Model I424
A) Rough Opening Width 610 mm
B) Rough Opening Height 876 mm
C) Min Door Clearance 644 mm
D) Min Clearance at 90˚ 660 mm
Model I424FS*
C) Min Door Clearance 644 mm
D) Min Clearance at 90˚ 660 mm
*Free-standing Model I424FS requires no
surrounding cabinetry.
Dimensions are for finished rough openings.
Door swing clearances are based on
stainless steel door and handle dimensions.
587 mm
(CABINET DIMENSION)
767
mm
DOOR
FRAME
102 mm
SIDE VIEW
64 mm
616 mm
868
mm*
102
mm
TOE KICK
FRONT VIEW
13 mm + _ ADJUSTMENT IN LEVELING LEGS
*
M O D E L I 4 2 4 F S
Free-Standing
Width 616 mm
Height 868 mm
Depth 625 mm
610 mm
ROUGH
OPENING
DEPTH
TOP VIEW
A
ROUGH OPENING
WIDTH
LOCATE ELECTRICAL
WITHIN SHADED AREA
114
mm
394 mm
E
FRONT VIEW
625 mm
(CABINET DIMENSION)
U N D E R C O U N T E R
Model I424
Built-In
Model I424FS
Free-Standing
SIDE VIEW
B
ROUGH
OPENING
HEIGHT TO
FINISHED
FLOORING
90˚
C
D
51
