Models I700Tr, I700Tfi And I700Tci - Sub-Zero Manual

O V E R A L L D I M E N S I O N S

Models I700TR, I700TFI and I700TCI

686 mm
(UNIT DIMENSION)
356 mm
21
mm
DOOR
MOUNTING
DETAIL
10 mm
337
DRAWER
mm
13
MOUNTING DETAIL
mm
876
mm*
260
mm
518 mm
FRONT VIEW
13 mm + _ ADJUSTMENT IN LEVELING LEGS
*
I N S T A L L A T I O N
S P E C I F I C A T I O N S
Models I700TR, I700TFI and I700TCI
Models without an ice maker will not
require the water line connection.
*PLACEMENT OF THE
ANTI-TIP BRACKET
SHOULD BE 610 mm
FROM THE FRONT OF THE
UNIT WITHOUT PANELS
TO THE BACK OF THE
ANTI-TIP BRACKET.
LOCATE ELECTRICAL WITHIN
SHADED AREA – ORIENT GROUND
PRONG TO RIGHT AS SHOWN
ANTI-TIP LOCATE WATER LINE
BRACKET (REAR ENTRY) WITHIN
114
mm
330 mm
6
mm
64 mm
394 mm
NOTE: ANTI-TIP BRACKET MUST BE INSTALLED TO
PREVENT UNIT FROM TIPPING FORWARD
610 mm
TOP OF
(UNIT DIMENSION)
ROUGH
OPENING
2032
mm*
1995
mm*
248
mm
102
mm
SIDE VIEW
TOP VIEW
ANTI-TIP
38
BRACKET*
mm
343 mm
635 mm
394 mm
WATER LINE
BOTTOM ENTRY
LOCATION
686 mm
SHADED AREA
76
mm
229 mm
19
mm
FRONT VIEW
610 mm
DOOR/ DRAWER
CLOSED
495
90˚
mm*
648
mm*
90˚ DOOR OPENING
TOP VIEW
*
DOOR/DRAWER PANEL THICKNESS NOT INCLUDED – DIMENSION WILL VARY WITH INSTALLATION
TOP VIEW
152
mm
343 mm
686 mm
229
WATER LINE
mm
SIDE ENTRY
LOCATIONS
38 mm
2032 mm
SIDE VIEW
DOOR/ DRAWER
CLOSED
105˚
657 mm
117 mm*
MAXIMUM DOOR OPENING
ANTI-TIP
BRACKET
686 mm
38 mm
635 mm
WATER LINE
SIDE ENTRY
ANTI-TIP LOCATION
BRACKET
A L L R E F R I G E R A T O R
A L L F R E E Z E R
Model I700TR
All Refrigerator
Model I700TFI
All Freezer
with Ice Maker
O V E R - A N D - U N D E R
Refrigerator | Freezer
Model I700TCI
with Ice Maker
M O D E L I 7 0 0 T R
M O D E L I 7 0 0 T F I
M O D E L I 7 0 0 T C I
Overall Dimensions
Width 686 mm
Height 2032 mm
Depth 610 mm
Finished Opening
Width 686 mm
Height 2032 mm
Depth 635 mm*
*The depth of the unit
is 610 mm from the
front of the unit to its
back. Your design may
necessitate moving the
unit back or cabinets
forward to achieve a
flush fit. This will
require a minimum
rough opening depth
of 635 mm.
33
