O V E R A L L D I M E N S I O N S
All Refrigerator | All Freezer Models
A L L R E F R I G E R A T O R
A L L F R E E Z E R
Model I601R
All Refrigerator
Model I601RG
All Refrigerator
with Glass Door
Model I601F
All Freezer
Model I601R
All Refrigerator
Width
Height 1854 mm
Depth
Illustrations shown in stainless steel design.
I N S T A L L A T I O N
I N S T A L L A T I O N S P E C I F I C A T I O N S
Refer to the
All Refrigerator | All Freezer Models
installation instruc-
tions shipped with
each Sub-Zero
Models I601R and I601RG, which do not
product for detailed
have an ice maker, will not require the water
specifications.
line connection.
Refer to the full-
Dimensions are for finished rough openings.
scale illustrations at
Door swing clearances are based on
the end of this
stainless steel door and handle dimensions.
section for specifics
on door openings
and other
specifications.
14
1854 mm
914 mm
Model I601RG
All Refrigerator
with Glass Door
914 mm Width
Height 1854 mm
610 mm Depth
606 mm
10 mm
BEHIND
FRAME
FRAME
EXTENSION
90˚
916 mm
1854 mm
914 mm
Model I601F
All Freezer
914 mm Width
Height 1854 mm
610 mm Depth
610 mm
ROUGH
OPENING
DEPTH
1848 mm
ROUGH OPENING
HEIGHT TO
FINISHED
FLOORING
WITHIN ENTIRE SHADED AREA
279
mm
1854 mm
914 mm 610 mm
914 mm
610 mm
EXTEND
WATER LINE
APPROX 914 mm
FROM BACK WALL
(I601F ONLY)
SHUT-OFF
VALVE
TOP VIEW
902 mm
ROUGH OPENING WIDTH
1848 mm
MINIMUM HEIGHT
REQUIRED TO
FINISHED
FLOORING
(LEVELERS IN)
LOCATE ELECTRICAL
LOCATE WATER SUPPLY
WITHIN BOTTOM SHADED
AREA ONLY (I601F ONLY)
152
610 mm
mm
76
mm
E
W
FRONT VIEW
