F R A M E D C A B I N E T R Y –
B E A D E D I N S E T A P P L I C A T I O N
The illustration below shows a 686 mm wide
Integrated base or tall unit installed within a
framed cabinetry, beaded inset application.
Review, giving particular attention to the overall
panel specifications. Also refer to the full-scale
illustrations at the end of this section for
specifics on door openings.
SUB-ZERO
CABINET DOOR UNIT
A A
686 mm
TOP VIEW
SHADED AREA
INDICATES STATIONARY
STYLES AND RAILS
610 mm
TO WALL
DOOR PANEL
679 mm
PANEL WIDTH
686 mm
38 mm
38 mm
FRONT VIEW
A) ALL REVEALS ARE 3 mm
B) DRAWER RAILS ARE ATTACHED TO DRAWER FRONTS
C) BOTTOM RAIL MUST BE REMOVABLE
*DIMENSIONS MAY VARY
38
mm
2624
1216
mm mm
2032
mm*
A
B
345 mm
876
A
B
mm*
383 mm
38
mm
A
C
102 mm*
6 8 6 m m
W I D E M O D E L S
Installation of a
686 mm wide
Integrated base or
tall unit within
framed cabinetry.
*Dimensions may vary.
Dimensions are based
on a 3 mm reveal. A
reveal of up to 6 mm
is possible, but panel
dimensions need to be
adjusted accordingly.
I N S T A L L A T I O N
To install integrated
panels, see the
detailed procedures
outlined in the
Sub-Zero Integrated
Installation Guide.
102 mm
610 mm
SIDE VIEW
