IC-KP-B17-AIDA1
Commands
quit (QU)
Command:
Byte
1)
Byte 0
1)
Byte 1
Byte 2
Byte 3
1)
Response:
Byte
1)
Byte 0
1)
Byte 1
Byte 2
Byte 3
Byte 4
Byte 5
1)
The command running on this channel is interrupted.
62
Contents
Telegram length, high byte
Telegram length, low byte
Command code (02h)
Reserved/Channel/Toggle bit
This byte is only used with the TCP/IP and MODBUS TCP/IP protocol.
Contents
Telegram length, high byte
Telegram length, low byte
Command code (02h)
Reserved/Channel/Toggle bit
Status
Reply counter
This byte is only used with the TCP/IP and MODBUS TCP/IP protocol.
Bit no.
7 6 5 4 3
0 0 0 0 0
0 0 0 0 0
0 0 0 0 0
0 0 0 0 <Channel>
Bit no.
7 6 5 4 3
0 0 0 0 0
0 0 0 0 0
0 0 0 0 0
0 0 0 0 <Channel>
<Status>
<ReplyCounter>
2 1 0
0 0 0
1 0 0
0 1 0
<T>
2 1 0
0 0 0
1 1 0
0 1 0
<T>
