Intuicom RTK Bridge-X Installation Manual
Hide thumbs
Also See for RTK Bridge-X:
- Installation manual (19 pages) ,
- Installation manual (16 pages) ,
- Installation manual (17 pages)
Related Manuals for Intuicom RTK Bridge-X
Summary of Contents for Intuicom RTK Bridge-X
- Page 1 Installation Guide ® RTK Bridge Integration with: ® ® Trimble 252/262/372 Intuicom, Inc. 4900 Nautilus Ct. Ste. 100 Boulder, CO 80301 (303) 449-4330 www.intuicom.com...
- Page 2 Intuicom reserves the right to make changes to this document without notice. Unless otherwise agreed to in writing, Intuicom assumes no responsibility or liability for the use of this document or for the infringement of any copyright or other proprietary right and Intuicom shall deem nothing contained in this document a warranty or guarantee.
-
Page 3: Requirements For Installation
GPS/GNSS reference network. The intended audience for this document is a dealer or integrator familiar with the 252/262/372 and generally familiar with the Intuicom RTK Bridge- X. The Intuicom RTK Bridge-X User Guide covers the steps necessary for its configuration. 1 Requirements for Installation Required Information In order to operate an Intuicom RTK Bridge–X, you are required to have the necessary... -
Page 4: Installation Instructions
Section 2: Installation Instructions 2 Installation Instructions Below is the installation Diagram for the recommended installation of the Intuicom RTK Bridge–X utilizing the equipment noted above. Diagram 1 Configuration • Configure the Intuicom RTK Bridge–X to connect to GPS/GNSS Reference network and obtain CMR/CMR+ correction data stream from an appropriate single reference station, such as a VRS. - Page 5 (DTM06-12S) pinout • Using the Intuicom RTK Bridge–X to 252/262/372 data/power cable (XRTKCAB- DD15), connect the RTK Bridge–X data port to the B Port on the 252/262/372. • Connect setup data/power cabling to the 252/262/372 Port A and a serial port on a PC running AgRemote or connect to the receiver using a monitor with AgRemote or RDI configuration software.
- Page 6 Section 2: Installation Instructions • Configure Port C – configure the input format to be “CMR” or “RtkLnk” at a baud rate of 38400. Version 1.0 Intuicom, Inc.
- Page 7 Section 2: Installation Instructions • Confirm operation – Confirm the Intuicom RTK Bridge-M is correctly configured and its antennas are connected and within cellular coverage. The main status view in AgRemote should report that it is receiving RTK corrections. • A capital R indicates an RTK Fix, a lower case r indicates RTK float. The age is typically between 1-2 seconds.
- Page 8 It may be desired to send the corrected position of the receiver to the network in order to view the position quality on the network. The RTK Bridge-X can be configured to accept a GGA position on the serial port and use that position to send to the network. To be able to send the GGA position from the receiver: 2.2.1 RTK Bridge–X setup...
- Page 9 Trimble 252/262/372 to the Intuicom RTK Bridge–X. For Technical Support of the RTK Bridge-X, Intuicom recommends “Intuicom Remote Support”, please contact Intuicom for details on this real- time support program. For general technical support, please contact us at support@intuicom.com...
