- Page 1 Installation Guide ® RTK Bridge Integration with: ® ® Raven Phoenix 300 Intuicom, Inc. 4900 Nautilus Ct. Ste. 100 Boulder, CO 80301 (303) 449-4330 www.intuicom.com...
- Page 2 Intuicom reserves the right to make changes to this document without notice. Unless otherwise agreed to in writing, Intuicom assumes no responsibility or liability for the use of this document or for the infringement of any copyright or other proprietary right and Intuicom shall deem nothing contained in this document a warranty or guarantee.
-
Page 3: Required Information
1 Requirements for Installation Required Information In order to operate an Intuicom RTK Bridge–X, you are required to have the necessary information to access and log in to the Real-Time Network. This information is entered into the RTK Bridge–X and stored in a profile. More details on setting up an RTK Bridge–X is available in the RTK Bridge-X manual. -
Page 4: Installation Instructions
Section 2: Installation Instructions 2 Installation Instructions Below is the installation Diagram for the recommended installation of the Intuicom RTK Bridge–X utilizing the equipment noted above. Diagram 1 Configuration • Configure the Intuicom RTK Bridge–X to connect to GPS/GNSS Reference network and obtain CMR/CMR+ or RTCM correction data stream from an appropriate single reference station, such as a VRS. - Page 5 Section 2: Installation Instructions • Using the Intuicom RTK Bridge-X to Phoenix 300 data/power cable and the null modem adapter, connect the RTK Bridge-X serial port to the B Port on the Phoenix 300 wiring harness. • Connect the SAE power connector to the supplied DC power adapter which is connected to Battery power.
- Page 6 • Return to the Home Display screen, then navigate to the Output Config screen and verify the Port B Baud Rate matches what is set in the Intuicom RTK Bridge-X (38400 recommended) • Set the GGA message to output at an Interval of 001.00...
- Page 7 Section 2: Installation Instructions Version 1.0 Intuicom, Inc.
