STUDER INNOTEC

4.2 Light Emitting Diodes

LED Marking
1 AC IN
2 CHARGER
3 SOLAR
CHARGE
4 Program
5 Contact active
6 Contact manual Aux. Cont. manually activated
7
8 AC OUT
9 INVERTER
10 Over Temp.
11 Overload
12 Batt. Low/High
13 OFF
14
15–18
25 CURRENT
MONITOR

4.3 Push buttons

19 ON/OFF
20 RESET
21 Aux. Contact

4.4 Turning Knobs

22 CHARGER
23 TRANSFER
24 STANDBY
26 INPUT LIMIT
User manual
LED lit
Voltage corresponding to self-
adjusted values is at the AC IN
input.
Battery Charger is working
Connected solar modules are
delivering energy
Programming mode
Contact
Auxiliary Contact is activated
Transfersystem is
coming voltage is being sent
directly to AC OUT outlet
There is voltage at the AC OUT
outlet
Inverter is working
For the time being the COMPACT
is out of service because of
overheating.
The COMPACT is out of service
because of overload or short-
circuit
Battery voltage is too low
COMPACT is turned off. Turning it
back on is only possible manually.
Battery Charger and or
Charge Controller are doing an
equalization cycle
Charge condition of Battery
Display the value of the output power in % of Pnom (in Inverter Mode)
and the charge current in Amps. (in Charger Mode) In this mode the
200% LED indicate that power sharing is in use.
Turning the COMPACT on and off (Help Button for Programming)
Alarm Signal off (Help Button for Programming)
Control Aux. contact (Help Button for Programming)
Adjustment for max. Charging Current (Not for Solar charge controller)
Adjustment for Transfer Voltage Threshold (TRANSFER – INVERTER)
Adjustment for „Standby" system
Must be adjusted to the maximal available current of your AC INPUT
supply (see on chap. 4.6.3)
COMPACT V4.0 E
LED blinks
Voltage,
adjusted values is at the AC IN
input.
The input voltage is out value
(voltage or frequency)
for Aux.
active. In-
The Inverter is in Standby-Mode
Forced -Inverter Mode
Battery voltage is too high
COMPACT is for the time being
turned off. Turning it back on will
follow automatically!
Solar
LED 15 – Absorption time is
running
COMPACT
outside of the self-
13
