Summary of Contents for ANTAIRA FCU-6001-SFP+
- Page 1 FCU-6001-SFP+ 10G/5G/2.5G/1G Copper to 10GBASE-X SFP+ Media Converter Version 1.0 User Manual...
- Page 2 Trademark Information Antaira is a registered trademark of Antaira Technologies, LLC., Microsoft Windows and the Windows logo are the trademarks of Microsoft Corp. NetWare is the registered trademark of Novell Inc. WMM and WPA are the registered trademarks of Wi-Fi Alliance.
- Page 3 Revision Antaira 10G/5G/2.5G/1G Copper to 10GBASE-X SFP+ Media Converter User's Manual MODEL: FCU-6001-SFP+ REVISION: 1.0 (JANUARY, 2019) This document is the current official release manual. Please check our website (www.antaira.com) for any updated manual or contact us by e-mail (support@antaira.com).
-
Page 4: Table Of Contents
Antaira Technologies - Media Converter FCU-6001-SFP+ User Manual V 1.0 Table of Contents Overview ............5 Key Features ......... 6 Package Contents ......... 6 Hardware Description ........7 Physical Dimensions ......7 Front Panel ..........8 Rear View ..........9 Power Information ......... -
Page 5: Overview
1. Overview Flexible and Reliable Network Distance Extension Solution Antaira’s FCU-6001-SFP+ media converter is equipped with one 10G/5G/2.5G/1G BASE-T auto- negotiation port and one 10GBASE-X SFP+ slot. It supports 10Gigabit Ethernet media conversion from copper 10GBASE-T to fiber multi-mode or single-mode, utilizing 10GBASE-SR or 10GBASE- LR SFP+ transceiver installed in the SFP+ slot to extend distances to servers, switches, and patch panels. -
Page 6: Key Features
Antaira Technologies - Media Converter FCU-6001-SFP+ User Manual V 1.0 1.1 Key Features FCU-6001-SFP+ Physical Port One 10G/5G/2.5G/1G BASE-T RJ45 interface with auto MDI/MDI-X function One 10GBASE-X SFP+ slot Layer 2 Features IEEE 802.3ab/802.3bz/802.3ae Ethernet standard compliant Supports auto-negotiation and 1/2.5/5/10Gbps full duplex mode Prevents packet loss with back pressure (half-duplex) and IEEE 802.3x pause frame flow control... -
Page 7: Hardware Description
Antaira Technologies - Media Converter FCU-6001-SFP+ User Manual V 1.0 2. Hardware Description 2.1 Physical Dimensions Figure 2.1, below, shows the physical dimensions of Antaira Technologies’ FCU-6001-SFP+: (W x D x H) is 94mm x 70mm x 26mm Figure 2.1 FCU-6001-SFP+ Physical Dimensions... -
Page 8: Front Panel
Antaira Technologies - Media Converter FCU-6001-SFP+ User Manual V 1.0 2.32.2 Front Panel The front panel of the FCU-600-SFP: Ethernet media converter (Figure 2.2). Figure 2.2 Front Panel of the FCU-6001-SFP+ System Color Function Lit: Power is active Green Off: Power is inactive Per 10G/5G/2.5G/1G BASE-T Port... -
Page 9: Rear View
The central pole of the media converter’s power jacks measures 2.5mm wide that require +5VDC power input. It conforms to the bundled AC-DC adapter and Antaira’s media chassis. Should you have the issue of power connection, please contact your local sales representative. - Page 10 Antaira Technologies - Media Converter FCU-6001-SFP+ User Manual V 1.0 need be active at all times, please consider using UPS (Uninterrupted Power Supply) for your device. It will prevent you from network data loss or network downtime. In some areas, installing a surge suppression device may also help protect your media converter...
-
Page 11: Mounting Installation
Antaira Technologies - Media Converter FCU-6001-SFP+ User Manual V 1.0 3. Mounting Installation 3.1 Stand Alone Step 1: Please find a secure location to lay the media converter. Step 2: Refer to Chapter 2.4 Power Information on power supply to the media converter. -
Page 12: Media Chassis Installation
Antaira Technologies - Media Converter FCU-6001-SFP+ User Manual V 1.0 3.3 Media Chassis Installation To install the media converter in a 19-inch standard rack, follow the instructions described below. Step 1: Place your media converter on a hard, flat surface with the front panel positioned towards your front side. -
Page 13: Hardware Installation
SFP+ port without having to power down the media converter. It is recommended to use Antaira SFP+s on the media converter. If you insert an SFP+ transceiver that is not supported, the media converter will not recognize it. - Page 14 Antaira Technologies - Media Converter FCU-6001-SFP+ User Manual V 1.0 ◼ 10G/5G/2.5G/1G BASE-T The 10G/5G/2.5G/1G BASE-T port comes with auto-negotiation capability. It automatically supports 1GBASE-T, 2.5GBASE-T, 5GBASE-T and 10GBASE-T networks. Users only need to plug a working network device into the 10G/5G/2.5G/1G BASE-T port, and then turn on the media converter. The port will automatically run at 1000Mbps, 2500Mbps, or 5000Mbps and 10000Mbps after the negotiation with the connected device.
-
Page 15: Cabling
Antaira Technologies - Media Converter FCU-6001-SFP+ User Manual V 1.0 4.2 Cabling This section describes the functionalities of the media converter’s components and guides you to how to install it on the desktop. Basic knowledge of networking is assumed. Please read this chapter completely before continuing. -
Page 16: Trouble Shooting
Antaira Technologies - Media Converter FCU-6001-SFP+ User Manual V 1.0 5. Trouble Shooting This chapter contains information to help you solve issues. If the media converter is not functioning properly, make sure the media converter is set up according to instructions in this manual. -
Page 17: Technical Specifications
Antaira Technologies - Media Converter FCU-6001-SFP+ User Manual V 1.0 6. Technical Specifications Table 6.1 has the technical specifications for Antaira Technologies’ FCU-6001-SFP+: Model FCU-6001-SFP+ Hardware Specifications 1 x 1G/2.5G/5G/10GBASE-T RJ45 Copper Interface Auto-MDI/MDI-X, auto-negotiation Fiber Optic Interface 1 x 10GBASE-X R SFP+ interface... - Page 18 Antaira Customer Service and Support (Antaira US Headquarter) + 844-268-2472 (Antaira Europe Office) + 48-22-862-88-81 (Antaira Asia Office) + 886-2-2218-9733 Please report any problems to Antaira: www.antaira.com support@antaira.com www.antaira.eu info@antaira.eu www.antaira.com.tw info@antaira.com.tw Any changes to this material will be announced on the Antaira website.
