Quantum Scalar i500: Rackmount Kit Installation
6-01492-04 Rev A
December 2013
Table 2 Rack Ear Kit Contents
4
Component
Component
Description
Rack shelf, left —
Secures the modules
in the rack
Rack shelf, right—
Secures the modules
in the rack
Description
Nut clip — Used in
racks with square
holes
Cage nut — Used in
racks with round
holes
M5 thumbscrew —
Secures the rack ears
Preparing for Installation
Quantity
1
1
Quantity
4
4
4
