Quantum Scalar i500 Installation Manual page 3
Rackmount kit
Hide thumbs
Also See for Scalar i500:
- User manual (575 pages) ,
- Reference manual (156 pages) ,
- Getting started manual (148 pages)
Table of Contents
Advertisement
Preparing for Installation
Component
Quantum Scalar i500: Rackmount Kit Installation
Description
Large ferrule — Used
in racks with square
holes
Thumbnut — Secures
the rack shelves to
the rack
M5 thumbscrew —
Secures the rack ears
Rack ear, left —
Holds the modules in
the rack
Rack ear, right —
Holds the modules in
the rack
6-01492-04 Rev A
December 2013
Quantity
10
(8 required;
2 spares)
8
4
1
1
3
