Digital Manager Option Switch Settings
Switches are located on bottom of Digital Manager
Option
Switch
Description
1
Low Return Temp.
2
Inducer/Chimney
3
N/A
4
N/A
5
Zone 1 Purge Time
6
Zone 2 Purge Time
7
Zone 3 Purge Time
8
Zone 4 Purge Time
9
High Return Temp.
10
Hot Water Priority
For a typical oil fired boiler with a sound chimney, supplying domestic hot water and properly sized heat zones, all
option switch settings will be "OFF". Turn switch 1 on to provide increased condensing protection (recommended for gas
fired boilers). Switches 5 through 8 are usually off, but can be turned on if the heat zone tends to overheat during energy
recovery. Switch 9 is usually off, but can be turned on to supply higher temperature water to under-radiated heating
zones or during very cold weather. Switch 10 is usually off, but when turned on the Manager will close heat zones 1
through 4 during a hot water call for up to 25 minutes.
SECURITY SYSTEM INTERFACE WIRING
The System Manager features a monitor interface system, which allows the Manager to alert a security system or
other signal light or device when a problem is detected. A three-terminal connector is supplied with each Manager. The
wiring detail is shown in figure below. NOTICE: Some security systems may require an "abort delay" of one second to
avoid a transient signal on Manager power-up. If an abort delay is not available, use Energy Kinetics System Monitor
(provided separately part # 10-0168). Alarm contacts are "dry" (no voltage is provided).
EK3 Frontier Boiler Manual
ON = DOWN
o
o
ON = 130
/ 150
F. (Gas)
N/A
N/A
N/A
ON = max 5 minutes energy recovery
ON = max 5 minutes energy recovery
ON = max 5 minutes energy recovery
ON = max 5 minutes energy recovery
o
o
ON = 190
/175
F.
ON = Priority
STANDARD MANAGER DIP SWITCHES
1
2
3
4
5
6
7
8
9
ALARM LEADS
COMMON
NORM. OPEN
NORM. CLOSED
SYSTEM MONITOR
(COVER REMOVED)
COM 1
N/O 2
N/C 3
24 VAC
ALARM CONN. 4
FROM
A1 5
MANAGER
Function
OFF = UP
OFF = 120
OFF = Chimney Venting
N/A
N/A
OFF = max 20 minutes energy recovery
OFF = max 20 minutes energy recovery
OFF = max 20 minutes energy recovery
OFF = max 20 minutes energy recovery
OFF = 170
OFF = No Priority
EXPANDED MANAGER DIP SWITCHES
1
0
1 2 3 4
5
6
ZONE:
5
6
7
8
9
10 11 12 13 4
NOTE: "ON" is DOWN position
DIGITAL MANAGER
THW
1
T1
2
T2
T3
3
A1
4
A2
B
S
R
T4
CAUTION
24 VAC CONNECTION ONLY.
READ INSTRUCTIONS BEFORE
MAKING ANY CONNECTIONS
N/C N/O C
15
Seventh Edition- October 2015
o
o
/140
F. (Oil)
o
o
/155
F. (Normal)
7 8 9
1
0
1
HOT WATER
Z4
1
ZHW
2
Z1
3
Z2
Z3
4
24VAC
CHIMNEYLESS
INDUCER
ONLY
IND
BURNER
B1
CIRCULATOR
B2
POWER
CIRC
190
170
160
150
140
130
120
100
MONITOR
MONITOR CONNECTOR
