Strong Razor Series Instruction Manual page 9

13.3 Adjusting Home Position (Fully Retracted)
The mount includes a home position latch that secures the arm
to the wall mount. This prevents the display from being pushed
away from the wall due to cabling.
Note: Only the TV Plate side of the latch is pre-installed. The
home position latch clip requires installation and adjustment.
1. Extend the arm out away from the wall.
2. A ttach the home position latch (Y) to the wall arm assembly using
the three screws (Z) as shown in Figure 15. Use a #2 Phillips
screwdriver to adjust the screws.
3. L eave the screws loose enough to be able to adjust the latch and
set it at the top of its travel.
4. Push the display back to the wall.
5. I f no "click" is heard as the arm is pushed flat, adjust the latch
downward and test again.
6. R epeat these steps until a "click" is heard and the display latches completely to the wall mount.
7. A fter the latch is set correctly, tighten the screws completely.
13.4 Tilt Adjustments
Tilt adjustments usually do not require loosening any
bolts or screws. The tilt plate fasteners have been pre-
adjusted for easy adjustment with most TVs. However,
heavier TVs may sag due to the extra weight.
If this occurs, evenly tighten the lock nuts on each side
of the end plate using the small 4mm Allen Wrench (T1)
until the display no longer sags. (Figure 16)
www.snapav.com Support: (866) 838-5052
Figure 15.
(Y) x1
(Z) x3
Figure 16.
5°
11°
Tilt Adjustment Nuts
(2 per side)
Pg. 9
