8. TEST MODE
A test mode is available to allow a lone worker to check the line connection to all telephones, record and playback
door panel & telephone audio and to adjust the telephone ring tone volume.
TO ENTER TEST MODE
Press the RESET button on the PCB inside the door panel
Wait for the door panel to announce the firmware version e.g. "One Zero Zero A" followed by "Ready"
Press the ENTER button on the PCB inside the door panel
The door panel will announce "Test Mode Enabled" followed by the first option "Test 1 – Handset Test"
Use the UP/DOWN buttons to step through the test mode options
Press the ENTER button to select an option
Press the EXIT button to quit the option
Test menu options are listed below;
TEST No. TEST TYPE
1 Handset Test
2 Handset Audio Record
3 Door Audio Record
4 Door Audio Playback
5 Handset Audio Playback
6 Handset Ring Level
If a test option is not selected for 60 seconds the door panel will announce "Test Mode Disabled"
When a test option is selected you have 15 minutes to perform the test.
8.01 TEST 1 – HANDSET TEST
Press ENTER and the door panel will announce "Handset Test – Please Wait"
After a short delay the door panel should announce "Zero Faults" followed by "Test 1 – Handset Test"
If faults exist the telephone ID's with faults will be announced
Check the wiring/ID settings in these telephones
Press UP to select the next test
8.02 TEST 2 – HANDSET AUDIO RECORD
Press ENTER and the door panel will announce "Handset Audio Record – Press Lock Key to Start"
Go to a telephone in a flat, lift the handset and press the lock button
You will hear a message in the earpiece "3‐2‐1 Record Start"
Speak a short test message into the telephone in a normal voice
After 5 seconds you will hear a message in the earpiece "Record Stop"
Hang‐up the telephone, return to the door panel and press EXIT
The door panel will announce the current test mode
Press UP to select the next test
8.03 TEST 3 – DOOR AUDIO RECORD
Press ENTER and the door panel will announce "Door Audio Record – Press Entrance Key to Start"
Temporarily refit the door panel into the backbox and press any button
The door panel will announce the message "3‐2‐1 Record Start"
Speak a short test message into the door panel in a normal voice
After 5 seconds the door panel will announce "Record Stop"
Remove the door panel from the backbox and press EXIT
The door panel will announce the current test mode
Press UP to select the next test
Doc No. FM0589 issue A Page 16
DESCRIPTION
Tests wiring connection to telephones and reports any faults
Allows a message to be recorded from the telephone
Allows a message to be recorded from the door panel
Listen to the message from Test 2 at the door panel
Listen to the message from Test 3 at the telephone
Allows the telephone ring volume to be set
