How to use the Entel Ultra Video Door Entry System
THE VISITOR PRESSES THE
THE VIDEO PHONE IN YOUR FLAT
1
2
BUTTON FOR YOUR FLAT NUMBER
WILL RING AND A PICTURE OF YOUR
ON THE MAIN ENTRANCE PANEL.
VISITOR WILL APPEAR ON THE
SCREEN.
7
8
9
5
6
3
1
2
IF YOU WISH TO ADMIT A VISITOR PRESS THE "LOCK RELEASE" BUTTON ONCE
4
AND THEN REPLACE THE HANDSET. THE RED LIGHT WILL FLASH WHEN THE LOCK
IS RELEASED.
IF THE LIGHT ILLUMINATES CONSTANT RED THEN THE DOOR HAS BEEN LEFT OPEN.
BRIGHTNESS ADJUST
COLOUR ADJUST
IF YOU DO NOT WANT TO BE DISTURBED PRESS THE
7
"PRIVACY" BUTTON ONCE. THE GREEN LIGHT WILL COME ON.
PLEASE NOTE: YOU WILL NOT RECEIVE ANY CALLS WHEN
THE GREEN LIGHT IS ON. WHEN YOU WANT TO RECEIVE CALLS
AGAIN PRESS THE "PRIVACY" BUTTON ONCE. THE GREEN LIGHT
WILL GO OFF.
REMEMBER: IT'S UPTO YOU TO
FOR YOUR ENTRY INTO THE
9
10
TO CONTROL WHO ENTERS INTO
BUILDING PLACE YOUR TOKEN TO
THE BUILDING. ONLY LET PEOPLE
THE READER AND OPEN THE DOOR.
IN IF YOU ARE SURE OF THEIR IDENTITY.
IF YOU DO NOT WANT TO TALK TO THEM
SIMPLY REPLACE THE HANDSET.
7
8
9
4
5
1
2
www.tynetec.co.uk Doc No. FM0745 ISSUE A
PICK UP THE TELEPHONE AND ASK
3
"WHO IS THERE?"
THE MAIN ENTRANCE PANEL WILL
5
BEEP. YOUR VISITOR CAN NOW
ENTER.
7
8
9
4
5
6
1
2
3
RED LED
FLASHING
- LOCK RELEASED
CONSTANT
- DOOR LEFT OPEN
RED LED (DOOR OPEN)
PLEASE TELL YOUR VISITORS TO
6
"LOCK RELEASE" BUTTON
ENSURE THE MAIN ENTRANCE DOOR
CLOSES BEHIND THEM.
GREEN LED (PRIVACY ON)
"PRIVACY" BUTTON
YELLOW LED (NO FUNCTION)
"PREVIEW" BUTTON
(TAKES APPROX. 1 SECOND
TO ACTIVATE MONITOR).
PRESS AND HOLD TO VIEW
PICTURE (OPTIONAL).
TO DISPLAY A VIEW FROM THE MAIN ENTRNCE CAMERA
8
PRESS AND HOLD THE "PREVIEW" BUTTON.
NOTE: THIS IS AN OPTIONAL FACILITY AND MAY NOT BE
AVAILABLE.
TO LEAVE THE BUILDING, PUSH
11
THE "EXIT" BUTTON AND OPEN
THE DOOR.
PRESS TO
EXIT
User Guide
For Your
ENTEL ULTRA
VIDEO DOOR ENTRY PHONE
Telephone Model No. ZVT450
