Tynetec ENTEL ULTRA User Manual

How to use the Entel Ultra Video Door Entry System
THE VISITOR PRESSES THE THE VIDEO PHONE IN YOUR FLAT
1 2
BUTTON FOR YOUR FLAT NUMBER WILL RING AND A PICTURE OF YOUR
ON THE MAIN ENTRANCE PANEL. VISITOR WILL APPEAR ON THE
SCREEN.
7 8 9
5 6
1 2 3
IF YOU WISH TO ADMIT A VISITOR PRESS THE "LOCK RELEASE" BUTTON ONCE
4
AND THEN REPLACE THE HANDSET. THE RED LIGHT WILL FLASH WHEN THE LOCK
IS RELEASED.
IF THE LIGHT ILLUMINATES CONSTANT RED THEN THE DOOR HAS BEEN LEFT OPEN.
RINGER VOLUME CONTROL
"LOCK RELEASE" BUTTON
"PRIVACY" BUTTON
GREEN LED (PRIVACY ON)
RED LED (DOOR OPEN)
RED LED
FLASHING - LOCK RELEASED
CONSTANT - DOOR LEFT OPEN
PLEASE TELL YOUR VISITORS TO IF YOU DO NOT WANT TO BE DISTURBED PRESS THE "PRIVACY" BUTTON ONCE.
6
7
ENSURE THE MAIN ENTRANCE DOOR THE GREEN LIGHT WILL COME ON.
CLOSES BEHIND THEM. PLEASE NOTE: YOU WILL NOT RECEIVE ANY CALLS WHEN THE GREEN LIGHT IS ON.
WHEN YOU WANT TO RECEIVE CALLS AGAIN PRESS THE "PRIVACY" BUTTON ONCE.
THE GREEN LIGHT WILL GO OFF.
REMEMBER: IT'S UPTO YOU TO FOR YOUR ENTRY INTO THE
8 9
TO CONTROL WHO ENTERS INTO BUILDING PLACE YOUR TOKEN TO
THE BUILDING. ONLY LET PEOPLE THE READER AND OPEN THE DOOR.
IN IF YOU ARE SURE OF THEIR IDENTITY.
IF YOU DO NOT WANT TO TALK TO THEM
SIMPLY REPLACE THE HANDSET.
7 8 9
5
4
1 2
www.tynetec.co.uk
PICK UP THE TELEPHONE AND ASK
3
"WHO IS THERE?"
THE MAIN ENTRANCE PANEL WILL
5
BEEP. YOUR VISITOR CAN NOW
ENTER.
7 8 9
4 5 6
1 2 3
TO LEAVE THE BUILDING, PUSH
10
THE "EXIT" BUTTON AND OPEN
THE DOOR.
PRESS TO
EXIT
Doc No. FM0745 ISSUE B
User Guide
For Your
ENTEL ULTRA
VIDEO DOOR ENTRY PHONE
Telephone Model No. ZVT455
