UPDATE DEVICE USB:

By pressing the "Update Device
necessary, using the USB port.
In order to load the parameters or update the firmware in the device, follow these
instructions:
Connect the USB cable from your PC to the Converter;
Select the "COM port";
Select which operations you want to do.
Press the "Execute update
When all the operations are "OK", disconnect the USB cable.
ADFweb.com Srl – IT31010 – Mareno – Treviso
USB" button it is possible to load the created Configuration into the device, and also the Firmware if is
firmware" button to start the upload;
User Manual J1939 / Modbus Slave
Document code: MN67432_ENG Revision 1.100
Figure 9: "Update Device" windows
