4. Plug the cable into the Host Port, then attach the scanner with the table mount.
5. Tightly secure the scanner and table mount with two (M3) mechine screws.
6. Connect the cable to the terminal's communication port. Plug the power supply
into the power jack on the interface cable if host can not provide sufficient power.
Use only an AC/DC power adapter approved for the scanner. Use of other
power supplies may cause damage to the scanner, and void the factory
warranty.
