B. If your Hermes/ANAN-* MAC and IP address are not shown as indicated above, your OpenHpSDR
Hermes/ANAN-* cannot be found on your network. Please check your Ethernet connections and try again.

Upgrading OpenHPSdr firmware using HPSDRProgrammer:

1. Download new firmware by visiting http://openhpsdr.org/download.php . Find the appropriate .rbf firmware
file for your SDR. For example, the current firmware file for Hermes/ANAN-* radios should be listed as Hermes
V_2.x.rbf. Download and save the appropriate .rbf for your SDR to a convenient location on your computer, for
later recall.
2. Press the "Browse" button in the "Programmer" section of HPSDRProgrammer and locate the *.rbf firmware
file you downloaded previously and select it in the browse "Open" dialog and then press the "OK" button.
3. The Hermes_v2.x.rbf or whatever firmware filename you selected previously must now be displayed in the
"Programmer", "RBF file" text box.
4. Press the "Program" button to load the .rbf file into your OpenHpSDR Hermes/ANAN-* SDR.
5. HPSDRProgrammer should display the progress of the firmware loading process.
6. Upon successful completion of loading the new firmware, the Device text box should contain the new version
number.

Assigning an IP address using HPSDRProgrammer:

1. Click on Menu Selection "Tools", "IP", or simply click on the IP text just below the menu selections.
2. The "Address Dialog window will appear.
3. An IP address can be assigned by placing 8 bit values in each of the 4 text boxes.
A. 8 bit values are numbers which can range from 0 to 255.
B. Each of the 4 text boxes must have a valid value entered.
C. If you do not know what IP address to use, just enter 0's in each box to revert to automatic IP
assignment (DHCP).
D. Press the Write IP button to write the entered IP address to your Hermes/ANAN-*
4. Entering 0's in all 4 text boxes will revert your Hermes/ANAN-* to DHCP or dynamic IP address assignment.
5. After entering a new IP address, close the "Address Dialog" window.
6. Hit the "Discover" button again to verify the IP address you just wrote.
