Anan-100/D Back Panel - Apache Labs ANAN-100/D Manual

1 2
11
1. 13.8VDC Power connector
2. Balanced Speaker Out
3. Rx-2
4. ANT-3
5 ANT-2
6. ANT-1
7. Bypass
8. Ext-2
Revision v1.8 April 23, 2013
Apache Labs ANAN-100/D

ANAN-100/D back panel

3 4 5
12 13 14
13 of 70
6 7 8
15
9. Transverter Rx
10. Ext-1
11. Ground Lug
12. Transverter Tx
13. 10Mhz input
14. Push to Talk OUT
15, Accessory I/O connector
10
9
authors N9VV and KC9XG
