Quick Start Instructions

please refer to front and back panel illustrations above
Warning: these "Quick Start" instructions only apply to the ANAN-100/D Apache Transceiver board with the
jumpers set to the factory defaults.
Please refer to the OpenHPSDR webpage for the most recent documentation by Phil Harman VK6APH for details
of the TAPR Hermes Transceiver http://svn.tapr.org/repos_sdr_hpsdr/trunk/Hermes/Documentation
also put this in your bookmarks as an excellent resource site: http://openhpsdr.org/wiki/index.php?
title=HPSDRwiki:Community_Portal

Hardware Setup

Note: DO NOT TURN ON THE RADIO AT THIS! TIME The ANAN-100/D Apache Radio will not operate without
properly configured software.
WARNING: If a mono plug or a shorted stereo plug is inserted into the rear panel Speaker jack, damage will
occur to the audio output IC. Do NOT short these stereo pins or connect either side to ground!
DO NOT TURN THE ANAN-100/D RADIO ON until P*SDR software is properly installed.
The following connection instructions assume the ANAN-100/D jumper settings are at factory
defaults.
1. Install the 4 supplied rubber feet.
The ANAN-100/D transceiver should be placed to allow unobstructed airflow around and beneath the housing.
Damage can occur if the ventilation openings on the bottom or rear panel of the ANAN-100/D are blocked. Allow
room for airflow between the housing and other equipment.
2. Connect the supplied 13.8VDC cable to the rear panel power connector and to a filtered 13.8VDC +/- 5%,
power supply capable of providing up to 25A.
3. Connect a suitable ground cable to the rear panel ground terminal and to a suitable RF ground, in
accordance with good amateur practices.
4. Connect a 50 ohm transmission line between the rear panel ANT1 BNC connection and a 50 ohm dummy
load capable of dissipating 100 watts for at least 5 minutes.
5. Connect powered stereo speakers, or a stereo headset to the front panel 1/8"/3.5mm stereo jack. Note: Do
NOT connect powered stereo speakers or headsets to the rear panel speaker jack! This is a balanced output
and damage can result if either tip or ring is connected to ground.
6. Optional. Connect a dynamic PC microphone equipped with a 1/8"/3.5mm mono plug into the front panel
mic jack. See appendix for interfacing other mics.
7. Connect a CAT 5 Ethernet cable between the front panel RJ45 LAN jack and your router or PC Ethernet port.
Note: find minimum detailed Ethernet requirements beginning on page 8 of this document.
Do Not install a microphone or CW key at this time. DO NOT TURN THE RADIO AT THIS TIME!.
Insure that your PC is properly connected and communicating over your network (LAN) to the Internet.
