and ground, install jumpers between pins JP6-1 and JP6-2.
Close Hermes / ANAN-100/D+ housing.
Refer to
http://svn.tapr.org/repos_sdr_hpsdr/trunk/Hermes/Documentation/Hermes_User_Manual_V1. 9 .pdf
to set jumpers for other intended uses.
5. Connect radio to dummy load or suitable antenna.
Power up radio.
6. Plug PC mic into one side of RS 274-375.
Left and right, or tip and ring are not marked on RS adapter.
7. If radio keys up or no mic audio is seen with mic plugged
in,move PC Mic to other mono jack on adapter.
8. Adjust modulation level as needed using P*SDR equalizer or
equivalent.
Note: P*SDR keyboard commands could be used to key
Hermes / ANAN-100/D+ and to adjust modulation.
P*SDR must have Windows focus or these
commands will not work.
Toggle MOX (PTT) or space bar
Mic gain increase
Mic gain decrease
VOX Threshold increase
VOX Threshold decrease
Adding a Hand or foot operated Push-To-Talk switch for use with a PC
microphone:
Standalone Push-To-Talk (PTT) switches are available from a
number of Vendors and suppliers. Several hand and foot
operated switches are available. Most can be supplied with
1/4" male plugs.
Some PTT Switch suppliers:
http://www.pttpro.com/
http://heilsound.com/amateur/products/index.php
http://www.mfjenterprises.com/Product.php?productid=MFJ-1709
1. Obtain either a hand held, or foot operated Push To Talk
Switch. Typical PTT switches come with 1/4" mono plugs,
or RCA plugs. The following assumes the PTT switch is
equipped with a 1/4" mono plug.
2. Obtain RS274-047 1/4" mono female to 1/8" Mono Male adapter.
Plug the 1/4" PTT plug into the RS 274-047 adapter and then
plug 1/8" plug into RS 274-375 mono to stereo adapter used
for the PC microphone as outlined above for PC microphones.
3. Remove DC power from Hermes / ANAN-100/D+.
4. Open Hermes / ANAN-100/D+ housing using grounded wrist
strap and an anti-static mat. Locate jumper JP6.
5. Install jumpers between JP6-1 and JP6-2 to enable PTT on
the stereo plug Ring. Close Hermes / ANAN-100/D housing.
6. Connect radio to dummy load or suitable antenna. Power
up radio.
7. Plug adapter into Hermes / ANAN-100/D+ Stereo mic plug.
8. Plug PTT switch into one side of RS 274-375.
Revision v1.8 April 23, 2013
Apache Labs ANAN-100/D
CTRL + M
ALT + up arrow
ALT + down arrow
ALT + right arrow
ALT + Left arrow
38 of 70 authors N9VV and KC9XG
