StarTech.com STARVIEW SV231DDUSB Instruction Manual page 7

LOCK, CAPS, ESC, F12 or NUM LOCK keys are available for selection) and you'll
hear a beep for selection confirmation. The new preceding sequence can now be used
to execute hotkey commands.
Switcher Software
Right-click the KVM Switcher icon (shown below) to launch the operation menu, then
select whichever PC is available for switching. Once you select a PC channel, it will
immediately switch to that PC. Please note that the unconnected port(s), or the active port
will be grayed-out and hence be non-selectable.
The following icons can be located in the Windows Taskbar, and provide access to the KVM
Switcher Software:
On Windows-based computers:
No live connection detected
Current active PC channel is on Port 1
Current active PC channel is on Port 2
On Mac computers:
No live connection detected
Current active PC channel is on Port 1
Current active PC channel is on Port 2
Please Note! Each keystroke within a hotkey sequence should be pressed
within two seconds. Otherwise, the hotkey sequence will not be validated.
Switch to PC x by Operation Menu
Right-click the KVM Switcher icon to evoke the operation menu, then select whichever PC
is available for switching. Once you select a PC channel, it will immediately switch to that
PC. Note that the unconnected port(s) or the active port will be grayed-out and hence non-
selectable.
Switch to PC x by Keyboard Hotkeys
Hit the hotkey according to your current hotkey definition:
Hotkey sequence = Ctrl - Alt - [command key]*
* The factory default hotkey setting is Ctrl + Alt + 1/2/3/4 for PC 1/2/3/4. You can also
use ScrLk + ScrLk + 'x' to switch PC x.
Please note: The three keys should be pressed and held together. Upon the release of
all three keys, the switching action will be executed.
Instruction Manual
4
