2 Port SuperSpeed USB 3.0 VGA / Dual-Link DVI /
DisplayPort® / HDMI® KVM Switch with Audio and Cables
SV231U3A
SV231DLU3A
SV231DPU3A
SV231HDU3A
DE: Bedienungsanleitung - de.startech.com
FR: Guide de l'utilisateur - fr.startech.com
ES: Guía del usuario - es.startech.com
IT: Guida per l'uso - it.startech.com
NL: Gebruiksaanwijzing - nl.startech.com
PT: Guia do usuário - pt.startech.com
For the most up-to-date information, please visit: www.startech.com
Manual Revision: 09/28/2012
*SV231U3A Shown
Advertisement
Table of Contents
Related Manuals for StarTech.com SV231U3A
Summary of Contents for StarTech.com SV231U3A
- Page 1 DE: Bedienungsanleitung - de.startech.com FR: Guide de l'utilisateur - fr.startech.com ES: Guía del usuario - es.startech.com IT: Guida per l'uso - it.startech.com NL: Gebruiksaanwijzing - nl.startech.com PT: Guia do usuário - pt.startech.com For the most up-to-date information, please visit: www.startech.com Manual Revision: 09/28/2012...
-
Page 2: Fcc Compliance Statement
StarTech.com. Where they occur these references are for illustrative purposes only and do not represent an endorsement of a product or service by StarTech.com, or an endorsement of the product(s) to which this manual applies by the third-party company in question. Regardless of any direct acknowledgement elsewhere in the body of this document, StarTech.com hereby... -
Page 3: Table Of Contents
Table of Contents Introduction ....................1 Packaging Contents ..........................1 System Requirements ..........................1 Installation ....................4 Hardware Installation ..........................4 Driver Installation ............................4 Operation ....................5 Front Panel ..............................5 Hotkey Control ............................5 Specifications ..................8 Technical Support ..................10 Warranty Information ................10 Instruction Manual... -
Page 4: Introduction
Introduction The SV231xxU3A 2 Port SuperSpeed USB 3.0 VGA / Dual-Link DVI / DisplayPort® / HDMI® KVM Switch with Audio and Cables lets you control 2 VGA / Dual-Link DVI / DisplayPort® / HDMI®, USB 3.0 equipped PCs with a single monitor, keyboard, mouse and audio peripheral set. -
Page 5: Front View
Front View USB Hub Selection LED Port Selection Button / LED *SV231U3A Shown Rear View - SV231U3A Console VGA USB Keyboard/Mouse connectors Connector (output) Connectors DC Power 3.5mm Audio USB 3.0 HUB Connector Speaker/Mic connectors Instruction Manual... - Page 6 Rear View - SV231HDU3A Console HDMI® USB Keyboard/Mouse connectors Connector (output) Connectors DC Power 3.5mm Audio USB 3.0 HUB Connector Speaker/Mic connectors Rear View - SV231DPU3A Console DisplayPort® USB Keyboard/Mouse connectors Connector (output) Connectors DC Power 3.5mm Audio USB 3.0 HUB Connector Speaker/Mic connectors...
-
Page 7: Installation
Installation Hardware Installation 1. Connect a VGA / DVI / DisplayPort® / HDMI® monitor into the Console’s video connector; plug a USB keyboard and a USB mouse into the dedicated USB keyboard and mouse ports on the KVM switch. If using audio, also connect speakers with 3.5mm mini-jack plugs. -
Page 8: Operation
Operation Front Panel The front-panel Smart Touch button allows you a direct control over KVM switching operation. Simply press the button to switch to the respective PC port. For more operation about Smart Touch button, please refer to “Quick Reference Sheet”. Hotkey Control A Hotkey command is a short keyboard sequence for selecting a computer, activating computer scan, etc. - Page 9 Quick Reference Sheet Front-Panel Command Hotkeys Smart Touch Description Button Select Audio&Mic Port (Jointly select PC port ScrLk + ScrLk + Move audio&mic and audio&mic, F5~F6/F5~F8 port if binding is enabled) Bind PC and Hub Bind PC Port with Port Control ScrLk + ScrLk + Z Device Hub Port Switching...
- Page 10 Quick Reference Sheet Front-Panel Command Hotkeys Smart Touch Description Button Previous active PC ScrLk + ScrLk + Previous active port [Backspace] PC Port Toggle Beeper Beeper ScrLk + ScrLk + B On/Off Press and hold down last button (Button 2/ Select Hotkey ScrLk + ScrLk + Define Hotkey...
-
Page 11: Specifications
Specifications SV231U3A SV231DLU3A SV231DPU3A SV231HDU3A 1 x VGA (15 1 x DisplayPort® pin; High 1 x DVI-I (29 1 x HDMI® (19 (20 pin) Density pin) Female pin) Female Female D-Sub) Female 2 x USB A (4 2 x USB A (4... - Page 12 SV231U3A SV231DLU3A SV231DPU3A SV231HDU3A On Screen Display Cascadable Rack- Mountable Enclosure Steel Type Operating 0°C to 40°C (32°F to 104°F) Temperature Storage -20°C to 40°C (4°F to 104°F) Temperature Humidity 0~90% RH Non-Condensing Dimensions 165 x 89 x 46mm (LxWxH)
-
Page 13: Technical Support
Limitation of Liability In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their officers, directors, employees or agents) for any damages (whether direct or indirect, special, punitive, incidental, consequential, or otherwise), loss of profits, loss of business, or any pecuniary loss, arising out of or related to the use of the product exceed the actual price paid for the product. - Page 14 StarTech.com is an ISO 9001 Registered manufacturer of connectivity and technology parts. StarTech.com was founded in 1985 and has operations in the United States, Canada, the United Kingdom and Taiwan servicing a worldwide market.
