Keyboard Hotkey Commands

Command Name
Select active computer
Select USB hub control
Select Audio/Mic output
Bind computer and USB hub
control (default)
Unbind computer and USB
hub control
Bind computer and Audio/Mic
control (default)
Unbind computer and
Audio/Mic output control
Select next/previous port
Select previous port
Beep sound on/off
Define new hotkey sequence [ScrLk]+[ScrLk]+[H]+[ y ]
Auto-scan
Auto-scan with programmable
delay
Stop Auto-scan
Notes:
1. The USB keyboard hotkeys allow you faster and broader control of KVM switching operation, in addition to the
front-panel buttons. If you have configured a hotkey preceding sequence other than two consecutive scroll locks,
you should change your hotkey sequence accordingly.
2. When the binding of PC & USB hub port control switching is enabled by the hotkey sequence: ScrLk + ScrLk +
Z, PC and hub port control switching are bound together. To remove this binding, use the hotkey sequence:
ScrLk + ScrLk + X.
3. When the binding of PC, Audio and Mic switching is enabled by the hotkey sequence: ScrLk + ScrLk + Q, any
PC, audio and mic switching are bound together. To remove this binding, use the hotkey sequence: ScrLk +
ScrLk + W.
LED Information
Green LED indicates PC port status: solid green – active port; flashing green – PC not connected;
Red LED indicates hub port control status: solid red – that PC has the control of all hub ports.
Important Note: The USB hub control status LED (red) indicates not the connected status of each USB device, but
indicates which PC port has the control of all hub ports and their connected devices. For example, when USB LED
1 is lit, it means PC port 1 has the current control of all hub ports and their connected USB devices.
Instruction Manual
Hotkey Sequence
Switches access to the computer connected to the
[ScrLk]+[ScrLk]+[ x ]
Switches which corresponding port number has access
[ScrLk]+[ScrLk]+[F x ] to the to the devices connected to the KVM's USB hub.
([F x ] = Function key: F1=Port 1, F2=Port 2, etc.)
Switches which port's speaker and microphone output is
[ScrLk]+[ScrLk]+[F y ]
([F y ] = Function key: F5=Port 1, F6=Port 2, etc.)
When either the select active computer or select USB
[ScrLk]+[ScrLk]+[Z] hub control commands are executed, both functions are
The computer control and USB hub control can be
[ScrLk]+[ScrLk]+[X] executed separately; KVM control and USB hub control
control can be assigned to different ports at one time.
When either the select active computer or select
[ScrLk]+[ScrLk]+[Q] audio/mic output control commands are executed, both
The computer control and USB hub control can be
executed separately; KVM control and Audio/Mic output
[ScrLk]+[ScrLk]+[W]
control control can be assigned to different ports at one
Selects the next (up arrow key) or previous (down arrow
[ScrLk]+[ScrLk]+[ , ]
[ScrLk]+[ScrLk]+[BkSp]
[ScrLk]+[ScrLk]+[B] Enables/disables audible responses from the KVM.
Change the standard [ScrLk] hotkey to a new value (see
Automatically switch active ports in sequence every 10
[ScrLk]+[ScrLk]+[S]
Auto-scan with a delay other than 10 seconds (see
[ScrLk]+[ScrLk]+[S]+[ z ]
Press any key on
keyboard
7
Description
corresponding port number on the KVM.
([ x ]= a number on the keyboard)
active at the console.
switched to the selected port.
functions are switched to the selected port.
time.
key) numbered port for control.
Selects the most recent previously active port.
below).
seconds. (Press any key to cancel.)
below). Press any key to cancel.
Terminate Auto-scan activity
