Tracking Camera Quick Start Guide
Package Contents
Camera unit
Battery
AAA
AAA
Overview
1. PTZ camera
2. Panoramic camera
3. Power indicator
4. RJ-45 port
5. 3G-SDI 2 port
6. 3G-SDI 1 port
7. HDMI port
8. Audio in port*
*Audio input level: 1Vrms(max.)
Power adapter
Quick Guide
9. RS-232 port
10. Power jack
11. Camera select
12. Enter
13. Camera direction control
14. White balance
15. OSD menu
16. Back light control
Power cord
Remote Controller
17. Zoom in/out
18. Exposure compensation
19. Home position
20. Tracking on/off
21. Number buttons
22. Profile
23. Preset
RS-232 to D-Sub 9 cable
P/N: 300AU9P1-ECV
Advertisement
Table of Contents
Related Manuals for AVer Tracking Camera
Summary of Contents for AVer Tracking Camera
-
Page 1: Package Contents
Tracking Camera Quick Start Guide Package Contents Camera unit Power adapter Power cord RS-232 to D-Sub 9 cable Battery Quick Guide Remote Controller Overview 1. PTZ camera 9. RS-232 port 17. Zoom in/out 2. Panoramic camera 10. Power jack 18. Exposure compensation 3. - Page 2 Dimension Connections Installation Suggestion: Install height: 2~3m (6.56~9.84 feet). 2.4m (7.87 feet) is recommended. If the camera height is too low, tracking may be compromised. Distance from podium: TR320: 4~10m (13~33 feet) TR530: 4~15m (13~49 feet) Power RJ-45 cable Adaptor...
- Page 3 Setup IP Address There are two ways to setup IP address of the camera. Please follow the steps below to setup the IP address. Static IP Address After starting-up, press button on remote control to call setup menu. Use ▲ and ▼ buttons to select the Camera > Static IP > IP, then press button to enter IP address.
- Page 4 Use ▲ and ▼ buttons go to “Information” to check the IP address information. Camera Setup Guide A more comprehensive HOW-TOs, video guides can be found here: https://www.averusa.com/pro-av/support/ For the best experience, we recommend using the Google Chrome browser to access the camera. ...
- Page 6 Do not mix and use different types of batteries: alkaline, standard (carbon -zinc) or rechargeable (nickel-cadmium). Do not dispose of batteries in a fire. Do not attempt to short circuit the battery terminals. ©2019 AVer Information Inc. All rights reserved. Contact Information AVer Information Inc. 668 Mission Ct Fremont, CA 94539 pro.averusa.com...
