  • Page 1 CAM130 Content Camera User Manual...
  • Page 2 Federal Communications Commission Statement NOTE: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radiofrequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications.
  • Page 3 © 2021 AVer Information Inc. All rights reserved. All rights of this object belong to AVer Information Inc. Reproduced or transmitted in any form or by any means without the prior written permission of AVer Information Inc. is prohibited. All information or specifications are subject to change without prior notice.
  • Page 4 WARNING  To reduce risk of fire or electric shock, do not expose this appliance to rain or moisture. Warranty will be void if any unauthorized modifications are done to the product.  Do not drop the camera or subject it to physical shock. ...
  • Page 5 Tel: +81 (0) 3 5989 0290 テクニカル・サポート: VCInfo.JP@aver.com Vietnam Branch Office Công ty TNHH AVer Information (Việt Nam) Tầng 5, 596 Nguyễn Đình Chiểu, P.3, Quận 3, Thành phố Hồ Chí Minh 700000, Việt Nam Tel: +84 (0)28 22 539 211...

  • Page 6: Table Of Contents

    Control Fill Light via Device Buttons ............3 Control Fill Light via Remote Control ............3 Installation ....................... 7 How to Install Whiteboard Mount and CAM130 Content Camera ... 8 How to Set CAM130 Content Camera as Content Camera in Teams Rooms ....................12 How to Set CAM130 Content Camera as Content Camera in Desktop Teams ....................
  • Page 7 Use PTZApp 2 with USB Devices ..............17 PTZ Control ....................22 Setting > Camera Settings ................24 Tracking Mode ..................24 Framing Speed ..................26 Home Position ..................26 On Screen Menu ................... 26 Save Preset ................... 26 Fill Light ....................27 Setting >...
  • Page 8 Enlarge Total Zoom Up To 5x ..............31 System ......................32 Firmware Update ................... 32 Factor Default ..................32 Trouble Shooting ................... 33 Information ..................... 33 Audio ......................34 Microphone .................... 34 Keystone Correction Configuration ............... 35 EZLive ........................38 Use AVer EZLive ................... 38...

  • Page 9: Content Camera Bundle Kit Package

    * The power plug will vary depending on the standard power outlet of the country where it is sold. * The power adapter will be required to support the fill-light function only when connecting CAM130 Content Camera to PC USB 2.0 port.

  • Page 10: Product Introduction

    Light Level Button * The fill light function is set “Manual mode” as default. Please use PTZApp 2 to change the settings. ** The built-in microphone of CAM130 Content Camera is disabled as default. Please use PTZApp 2 to change the settings.

  • Page 11: How To Control Fill Light

    If you want to unplug the power adapter while USB video streaming is on, please turn off fill light first to avoid system shut down. Power adapter will be required to support fill light function only when connecting CAM130 Content Camera to PC USB 2.0 port.
  • Page 12 Remote Control (Optional)  Name Function 1. SmartFrame One-click automatic FOV adjustment to fit all participants. Press for 1~2 sec. to switch the SmartFrame function among Manual Framing/Auto Framing/Preset Framing modes. A message (as figures shown) will display on the middle bottom of the screen to indicate the mode.
  • Page 13 Name Function  Camera will track people while moving. It will start to focus and zoom in once people stop moving for 1~5 seconds, depending on the framing speed you choose via PTZApp 2. The default framing speed is “Middle” speed. “High” speed is more suitable for one person tracking.
  • Page 14 Name Function  Microphone: Press and then to enable/disable microphone function. This setting will force system reboot. It will take 20 seconds for system reboot.  Long press the number button to set the preset point. 14. Number Buttons/Preset  One-click the number button to load the preset point. Position ...

  • Page 15: Installation

    Installation The CAM130 Content Camera can be mounted onto the wall or ceiling using the Whiteboard Mount (refer to Bundle Kit Package). Wall Mount Mode Ceiling Mount Mode Make sure that the camera has captured the frames of whiteboard completely.

  • Page 16: How To Install Whiteboard Mount And Cam130 Content Camera

    How to Install Whiteboard Mount and CAM130 Content Camera 1. Mount the bottom case of the Box to the wall 3cm above the center line of whiteboard/IFP space (or mount It to the ceiling). [Note] Please prepare three screws before mounting (not included in the package). The diameter of the three screw holes on the bottom case is Ø...
  • Page 17 3. Align the top case with the bottom case of the Box, insert the rod into the hole of both cases, and then rotate the rod to get it tightened with the box. Wall Wall 4. Connect the USB Type A side to the female connector of USB3.1 Extender Cable and house the joins inside the Box.
  • Page 18 6. Install CAM130 Content Camera to another end of the rod and turn the wheel to lock it. 7. Connect USB Type C to the Type C port located on the back of camera. 8. Rotate the rotating ring on the rod to adjust the rod length and rotate it again in the opposite direction to lock.
  • Page 19 10. Connect HDMI out of MTR system to TV monitor and use preview function to see the content camera image. Adjust the camera clip to ensure the camera capture the frames of the whiteboard. 11. The rod of whiteboard mount can be adjusted in length from 80cm to 120cm as required. Rod Length vs.

  • Page 20: Rooms

    To set up CAM130 Content Camera as a “Content Camera” in Teams Room: 1. Tap “More” to open the sidebar. From here, tap “Settings”. 2. Select Peripherals and then CAM130 Content Camera in Content camera item. Select Rotate content camera 180 degrees and suggest to enable Content enhancements. Save and exit.
  • Page 21 4. Select screen share function to show the view of content camera to remote site. Please connect HDMI out to monitor to see local site content camera view. 5. After setting (make sure you have enabled “Content enhancements”), the keystone correction function in teams room will take effect automatically to auto find, crop and enlarge whiteboard to full screen.
  • Page 22 How to Set CAM130 Content Camera as Content Camera in Desktop Teams Connect CAM130 content camera to PC or laptop. Make a call and then choose it as camera source in Device settings. When the call starts, click the Share button. Access “Content from camera” and select “Document”.
  • Page 23 The auto detect starts to capture the whiteboard with four frames. When you see the green rectangle, it means the detection is successful and it will enlarge the whiteboard content into full screen. Remember to select “Whiteboard” in Content type to enable people translucent effects. Click the Share button to share the whiteboard content to the teams meeting.

  • Page 24: Teams

    Operating the Camera Make a Video Call in MTR CAM130 Content Camera is a certified content camera in Teams room. However, it also can be used as a video conference camera in Teams room. If you connect only one CAM130 Content Camera in MTR and choose it as content camera, it will be occupied and can’t be used as a...

  • Page 25: Ptzapp 2

    In PTZApp 2, user can configure the parameters of the camera, set up AI tracking functions and some advanced image settings, pan, tilt, and zoom the camera. Install PTZApp 2 Please go to https://www.aver.com/download-center (Headquarters & Europe) or https://www.averusa.com/business/support/ (USA) to download the PTZApp 2. After downloading, double-click on the file and follow the on-screen instructions to complete the installation.
  • Page 26  Language: Select the desired language and click the check icon to confirm the selection.  Hotkey Control: User can control the camera by using keyboard. This is a general list for all AVer USB Cameras. Backlight Control equals to WDR function in CAM130 Content Camera.
  • Page 27  PTZApp Update: Get current PTZApp 2’s version number and do auto update here. Information: Click the drop-down triangle icon to review the information of camera. To minimize the information, click the triangle or the bottom area of the information icon. Camera: Click the camera icon to view the camera live view.
  • Page 28  Full Screen: PTZApp 2 can switch to full screen mode. Click “ ” icon and video screen will switch to full screen mode. In full screen mode, user can use direction panel to control camera direction. Click “ ” icon to go back to normal screen view. The resolution of full screen mode is 1080p.
  • Page 29 Setting: Click “Setting” button to set up parameters of the camera. Click arrow icon to leave and return to Home page. PTZApp 2 Quit & Restore: To quit the application, right-click the icon on the system tray and select “Quit”. If you can’t launch PTZApp 2 right after installation, please right –click the icon and choose “Restore”.

  • Page 30: Ptz Control

    PTZ Control Set Up Preset Positions Users can set up to 10 preset positions and when clicking on the pre-configured preset numbers, the camera view will turn to the positions. To set up preset positions: Click the Set button to start the configuration. Use the zoom in/out buttons to have a close-up view and the ▲, ▼, , ...
  • Page 31 Follow Step 2 and Step 3 to set up more preset numbers. After the set up process is complete, click the Load button to perform the Preset Position function. Click the preset number (0~9) and the camera will turn to the preset positions.

  • Page 32: Setting > Camera Settings

    Setting > Camera Settings Tracking Mode Select Setting > Camera > Tracking Mode > Off, Manual Frame, Auto Frame, or Preset Framing.  Off (default): Tracking mode is disabled.  Manual Frame: User one-click SmartFrame button and camera will adjust view angle to fit all participants in screen for once.
  • Page 33 *The default framing speed is “Middle” speed. “High” speed is more suitable for one person tracking. [Note] CAM130 Content Camera frames people in masks or any facial profile up to 5 meters away!  Preset Framing: Set up preset points in advance. (Only for Preset points 1~9. Preset 0 is for home position).

  • Page 34: Framing Speed

    Framing Speed Select Setting > Camera > Framing Speed > Slow Speed, Middle Speed (default), or High Speed. When in auto framing or preset framing mode, camera will automatically frame people if they stand still without moving for 1~5 seconds. ...

  • Page 35: Fill Light

    Fill Light Select Setting > Camera > Fill Light > Intelligent Lighting or Manual Lighting.

  • Page 36: Setting > Image Settings

    [Note] To enable this option, please switch off AI functions. Image Flip If the CAM130 Content Camera is installed in the upside down position, please enable the "Flip". Select Setting > Image > Image Flip > Off or On. Image Mirror To mirror the camera image.

  • Page 37: True Wdr

    True WDR In back light environment, enable WDR to improve the brightness of image. Select Setting > Image > True WDR > Off or On. The frame rate will be limited to 30fps while WDR is on. If user enables this function in a normal light condition, the image will become over exposure and encounter image blur.

  • Page 38: White Balance

    White Balance Select the white balance setting for various light conditions or color temperature. Select Setting > Image > White Balance > Auto or Manual. Noise Reduction To reduce the noise from the signal. Select Setting > Image > Noise Reduction > Off, Low, Middle, or High. Brightness Adjust the value of brightness.

  • Page 39: Low Resolution Under 720P

    Low Light Compensation Select Setting > Image > Low Light Compensation > Off or On. Please notice that the frame rate will drop to 10~15 fps. Low resolution under 720p Select Setting > Image > Low resolution under 720p > Disable or Enable. Resolution Mode Select Setting >...

  • Page 40: System

    Update the camera’s firmware. Select System > FW Update > Auto Update or Manual Update.  Auto Update: The system will check firmware version from AVer server and request to update.  Manual Update: To update the firmware from specific location.

  • Page 41: Trouble Shooting

    Trouble Shooting Output log to save in local PC. Select System > Trouble Shooting > Start. Select Output. Information Display the information of Model Name, Firmware Version, Serial Number, and MAC Address. Select System > Information.

  • Page 42: Audio

    Audio Microphone Enable/disable microphone function. The default setting is off. Select Audio > Microphone > Off or On. While changing the microphone status, the system requires 20 sec to reboot.

  • Page 43: Keystone Correction Configuration

    Keystone Correction Configuration CAM130 Content Camera is not limited to teams room system. It can also be used in all VC software. Please set up AVer keystone correction function via PTZApp 2. If AI function and keystone function are both enabled, keystone function (whiteboard/IFP capturing) will be a higher priority.
  • Page 44 Launch video conference software (e.g. Zoom, Teams, Skype) and choose AVer USB VCam as the video source to start collaborating. [Note] You will find both “camera model name” and “AVer USB VCam” as video sources in the VC software. Please choose “AVer USB VCam”.
  • Page 45 frame within four edges of the whiteboard. Click Next to proceed. If you want to resize the area, click Edit. If the area is just fine, click Save. To automatically configure the Keystone Correction function: Select Auto Detection in the Keystone Correction Mode field, the PTZApp 2 will automatically detect the graphic card driver of your computer and the Keystone Correction package.

  • Page 46: Ezlive

    EZLive Please go to https://www.aver.com/download-center to download the AVer EZLive software. After downloading, double-click on the file and follow the on-screen instructions to complete the installation. Use AVer EZLive During a video call, EZLive can help user to do: (1) Camera ePTZ (2) Volume control for the speaker connected (3) Capture camera’s still images...
