1. Symbols used in this document
Warning
Page If these safety instructions are not observed, it may
result in personal injury.
2
2
Warning
3
If these instructions are not observed, it may lead to
3
electric shock with consequent risk of serious
3
personal injury or death.
3
3 If these safety instructions are not observed, it may
Caution
4 result in malfunction or damage to the equipment.
5
Notes or instructions that make the job easier and
6
Note
ensure safe operation.
8
8
2. Product introduction
8
8
8
9
9
10
10
12
14
14
18
24
26
60
62
62
62
63
64
64
64
64
64
64
64
64
Fig. 1

Control MPC

64
Grundfos Control MPC is used for control and monitoring of
booster systems and circulation systems.
Control MPC consists of a control cabinet with a built-in controller,
the CU 352.
The control cabinet contains all necessary components such as
main switch, contactors, IO modules and cabling.
In systems with external frequency converters, the frequency
converters can be installed in the cabinet.
The control cabinet is for wall or floor mounting.
