Specifications; Functions Of Components; Installation; Distance Indicator - OPTEX FA CD33 SERIES Instruction Manual

nnection diagram
N type
(Analogue/Voltage/Dual)
P type
(Analogue/Voltage/Dual)
NPN type (RS422)
PNP type (RS422)
ns configuration
Caution for connection
g ground wire is not equipped for connector type. Therefore connect the analog
d terminal of analog input equipment and the 0V terminal of power supply.
F (multi functional ) input
multi functional) input activates when connected to GND(-) for NPN type,
when connected to (+) for PNP type.
nnect the lead wires correctly. The analog output wire must not be in contact
any other wire. Do not turn on the power while wiring.
e blue wire（0V） and shield wire（analog GND） are internally connected.
he blue wire（0V） for the power supply and use the shield wire（analog GND） for
g output.
Ramco Innovations

Specifications

●Specifications of Measuring Range
① CD33-30N(P) CD33-50N(P)
② CD33-30N(P)A CD33-50N(P)A
Cable type
③ CD33-30N(P)V CD33-50N(P)V
④ CD33-30N(P)-422 CD33-50N(P)-422 CD33-85N(P)-422 CD33-120N(P)-422 CD33-250N(P)-422
Type
① CD33-30CN(P) CD33-50CN(P)
② CD33-30CN(P)A CD33-50CN(P)A
Connector type
③ CD33-30CN(P)V CD33-50CN(P)V
④ CD33-30CN(P)-422 CD33-50CN(P)-422 CD33-85CN(P)-422 CD33-120CN(P)-422
Center 30mm
Measuring ｒange
±4mm
Light source
Peak power
IEC/JIS
Laser Class
FDA
Spot size Near 0.15×0.15mm 0.6×1.2mm
(approx.
Middle
0.1×0.1mm 0.5×1.0mm
volume)
*1 Far 0.15×0.15mm 0.4×0.9mm
±0.1% F.S. ±0.1% F.S.
Linearity *2
(F.S.=8mm) (F.S.=20mm)
2μm
Resolution *3
(Fast：4μm) (Fast：8μm)
Fast averaging: 1 time 5ms max.
Response
Standard averaging: 16 times 12.5ms max.
time
High resolution averaging: 64 times 36.5ms max.
Sampling period
Temperature Drift

Distance Indicator

Indicators
Output Indicator
Laser off、Remote teaching､Sample Hold (choose one function)
MF (multi functional) input
Circuit protection
Protection Category
Operating temp./humidity -10～+45℃/35～85%RH (No condensation or freezing)
Storage temp./humidity -20～+60℃/35～95%RH (No condensation or freezing)
Ambient Light Sun light: 10,000 lx max. / Incandescent lamp: 3,000 lx max.
Vibration resistance 10 to 55 Hz, Double amplitude 1.5 mm, 2 h for XYZ axes
Shock resistance
Warm up period
Material
Cable type
Weight
Connector type
●Specifications of Output
Dual output
Type
CD33- ① CD33- ②
DC12～24V
Supply Voltage
(+10%/-5%)
85mA max. (DC24V)
Current Consumption 55mA max. (DC24V)
including analog output
Control output NPN/PNP Open collector 100mA max. /30V DC
Q1 (Residual voltage 1.8 V max.)
Control output NPN/PNP Open collector 100mA max. /30V DC
Outputs
Q2
Analog output － 4～20ｍA
Interface
φ5 5core 2m
Cable type *4 φ5 6core 2m cable(PVC) AWG24
cable(PVC) AWG24
Connection
Connector type
*1 Defined with center strength 1/e2(13.5％ ). There may be leak light other than the specified spot size.
The sensor may be damaged when there is a highly reflective object around the targets.
*2 Averaging: 64(High resolution), Sampling period:500μs, Object: white ceramic.
*3 Middle of measuring range, Object: white ceramic.
*4 Diameter of min bend cable is 40mm.

Installation

Install the sensor and adjust the light spot onto the measuring point so that the distance indicator turns ON ( orange ) at
the middle of measuring range.
Use M4 screw (tightening torque need to be under 0.8N･m).
Distance indicator
shows orange when
object exists in the middle of
measuring range
8.2
Middle of
measuring
range
・Adjust the sensor position so that it is set parallel to the surface of object obtain reliable measurement (see above).
・If there is any foreign object around the spot that is glossier than the measuring object, it may cause incorrect
measurement.
800-280-6933
CD33-85N(P) CD33-120N(P) CD33-250N(P)
CD33-85N(P)A CD33-120N(P)A CD33-250N(P)A
CD33-85N(P)V CD33-120N(P)V CD33-250N(P)V
CD33-85CN(P) CD33-120CN(P) CD33-250CN(P)
CD33-85CN(P)A CD33-120CN(P)A CD33-250CN(P)A
CD33-85CN(P)V CD33-120CN(P)V CD33-250CN(P)V
CD33-250CN(P)-
422
50mm 85mm 120mm
±10mm ±20mm ±60mm ±150mm
Red laser Diode (wave length 655nm)
Max. output 1mW
CLASS2
CLASSⅡ
0.9×1.5mm 1.2×1.8mm 1.5×2.5mm
0.75×1.25mm 1.0×1.5mm 1.75×3.5mm
0.6×1.0mm 0.5×0.8mm 2.0×4.5mm
±0.1% F.S. ±0.1% F.S. ±0.3% F.S.
(F.S.=40mm) (F.S.=120mm) (F.S.=300mm)
5μm 10μm 30μm
(Fast：15μm) (Fast：45μm) (Fast：150μm)
7.5ms max.
18ms max.
54ms max.
500 ,750(250mm type) /1000 /1500 /2000μs
±0.08% F.S./℃
Bar graph LED
ON status : Orange
Response time ：3ms max.
Reverse polarity､Over current
IP67
2
50G (500m/s )
15min max.
PBT (Case) PMMA (Front window)
Approx. 65g (without cable)
Approx. 70g
Analogue Voltage RS422
CD33- ③ CD33- ④
DC18～24V DC12～24V
(+10%/-5%) (+10%/-5%)
55mA max. (DC24V)
value
－
(Residual voltage 1.8 V max.)
0～10V －
－
RS422
φ5 8core 2m
cable(PVC) AWG24
M12 8pin
43.2
47 5
Surface of the object.
（unit：mm）

Functions of components

Control panel
Emitting part
250mm
Receiving part
75μm
●Control panel
･Distance indicator
･Laser emission indication
(ON during laser emission)
Run indicator
Into Teach mode:
function indicator
Control output1
Control output2
MF indicator
Avg indicator
LED lights up , if receiving RS422 command.
Voltage
Distance indicator
Distance indicator has seven LEDs. LED indicate distance by moving at near to
Status of LED
www.optex-ramco.com
Fixture Hole
Analogue
Teach in
Select b
Set butt
Dual Output R
Status of measurement
Out of range.
Both
*This LED indicate when due to too
lights
high/low reflection
Near
Object is near of range.
lights
Far s
Object is far of range.
lights
Far s
Object is some far of range.
lights
Middl
Object is middle of range.
